Brake: Removal & Installation Scion tC I

Mechanical - Hydraulic 19 illustrations ~1439 words

REPLACEMENT

HINT

  1. Use the same procedures for the RH side and LH side.
  2. The procedures listed below are for the LH side.

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. REMOVE FRONT WHEEL
  2. REMOVE FRONT FENDER LINER LH
  3. REMOVE SPEED SENSOR FRONT LH Disengage the clamp and disconnect the connector. Remove the 2 bolts and separate the speed sensor front from the body. Remove the bolt and speed sensor front. NOTE: Prevent foreign matter from attaching to the sensor tip.
  4. INSTALL SPEED SENSOR FRONT LH Install the speed sensor front with the bolt. Torque: 9.0 N.m (92 kgf.cm, 80 in.lbf) NOTE: Prevent foreign matter from attaching to the sensor tip. Install the speed sensor front with the 2 bolts. Torque: Bolt A: 9.0 N.m (92 kgf.cm, 80 in.lbf) Bolt B: 29 N.m (296 kgf.cm, 21 ft.lbf) Connect the connector and engage the clamp.
  5. INSTALL FRONT FENDER LINER LH
  6. INSTALL FRONT WHEEL Torque: 103 N.m (1,050 kgf.cm, 76 ft.lbf)
  7. CHECK ABS SPEED SENSOR SIGNAL (See «DTC CHECK/CLEAR»(ref-224755-S01853767152006031100000) )

HINT

  1. Use the same procedures for the RH side and LH side.
  2. The procedures listed below are for the LH side.

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23
  1. REMOVE REAR WHEEL
  2. DISCONNECT SKID CONTROL SENSOR WIRE (See «REPLACEMENT»(ref-224777-S16651955412006031100000) )
  3. SEPARATE REAR DISC BRAKE CALIPER ASSY LH (See «REPLACEMENT»(ref-224777-S16651955412006031100000) )
  4. REMOVE REAR DISC (See «OVERHAUL»(ref-224778-S24188500742006031100000) )
  5. REMOVE REAR AXLE HUB & BEARING ASSY LH (See «REPLACEMENT»(ref-224777-S16651955412006031100000) )
  6. REMOVE SKID CONTROL SENSOR Install the 4 hub nuts to the 4 rear axle hub bolts. Placing an aluminum plate below the rear axle hub & bearing assy, place them into a vise. NOTE: Replace the rear axle hub & bearing assy if it is dropped or receives a strong shock. Remove the 2 pins from the SST (09520-00031) and separate the attachment (09521-00010) using a pin punch (3 mm) or hammer. Remove the skid control sensor from the rear axle hub & bearing assy using the SST and 2 bolts (90101-12007). SST 09520-00031 (09520-00040), 09521-00020, 09950-00020 NOTE: Pull the skid control sensor off straight, being careful not to make contact with the skid control sensor rotor. If the speed sensor rotor is damaged or deformed, replace the rear axle hub & bearing assy. Do not scratch the area where the skid control sensor contacts the rear axle hub & bearing assy. Do not attach foreign matter to the speed sensor rotor.
  7. INSTALL SKID CONTROL SENSOR Wipe off sealant attached to the skid control sensor's fitting surface with white gasoline. NOTE: Prevent foreign matter from attaching to the sensor rotor. Install a new skid control sensor to the rear axle hub & bearing assy. The skid control sensor connector should be placed in the lowest position. HINT: The rear axle hub & bearing assy should be placed with the narrow side facing the lower side. Press the skid control sensor so that it becomes flat with the rear axle hub & bearing using the SST and a press. SST 09214-76011 NOTE: Do not use a hammer on the skid control sensor. Check that there is no foreign matter such as iron chips on the skid control sensor's detecting portion. Slowly press the skid control sensor in straight.
  8. INSTALL REAR AXLE HUB & BEARING ASSY LH (See «REPLACEMENT»(ref-224777-S16651955412006031100000) )
  9. INSTALL REAR DISC (See «OVERHAUL»(ref-224778-S24188500742006031100000) )
  10. INSTALL REAR DISC BRAKE CALIPER ASSY LH (See «REPLACEMENT»(ref-224777-S16651955412006031100000) )
  11. CONNECT SKID CONTROL SENSOR WIRE (See «REPLACEMENT»(ref-224777-S16651955412006031100000) )
  12. INSTALL REAR WHEEL Torque: 103 N.m (1,050 kgf.cm, 76 ft.lbf)
  13. INSPECT AND ADJUST REAR WHEEL ALIGNMENT (See «REAR WHEEL ALIGNMENT»(ref-224775-S38914298142006031100000) )
  14. CHECK ABS SPEED SENSOR SIGNAL (See «DTC CHECK/CLEAR»(ref-224755-S01853767152006031100000) )

Note. When disconnecting the battery terminal, initialize the following system after the terminal is reconnected.

SystemSee
Power window control systemINITIALIZATION
Sliding roof systemINITIALIZATION

SYSTEM SPECIFICATION

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27
  1. PRECAUTION (See «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-224786-S11593879692006031100000) )
  2. DISCONNECT BATTERY NEGATIVE TERMINAL (See «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-224786-S11593879692006031100000) )
  3. REMOVE SHIFT LEVER KNOB SUB-ASSY (MANUAL TRANSAXLE) (See «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  4. REMOVE CONSOLE PANEL SUB-ASSY UPR FR (See «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  5. REMOVE CONSOLE UPPER REAR PANEL SUB-ASSY (See «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  6. REMOVE CONSOLE BOX ASSY RR (See «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  7. REMOVE PARKING BRAKE LEVER SUB-ASSY (See «REPLACEMENT»(ref-224778-S30247658902006031100000) )
  8. REMOVE FRONT DOOR SCUFF PLATE RH (See «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  9. REMOVE COWL SIDE TRIM SUB-ASSY RH (See «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  10. REMOVE FRONT SEAT ASSY RH (See «OVERHAUL»(ref-224793-S36693401512006031100000) )
  11. REMOVE EXHAUST PIPE ASSY CENTER (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224769-S00988693982006031100000) )
  12. REMOVE PARKING BRAKE CABLE HEAT INSULATOR Remove the 2 nuts and parking brake cable heat insulator.
  13. REMOVE PARKING BRAKE CABLE ASSY NO.1 Disconnect the parking brake cable assy No.1 from the parking brake equalizer. Turn back the floor carpet, and remove the 2 bolts and parking brake cable assy No.1.
  14. INSTALL PARKING BRAKE CABLE ASSY NO.1 Install the 2 bolts and parking brake cable assy No.1. Torque: 12.5 N.m (128 kgf.cm, 9 ft.lbf) Install the floor carpet. Connect the parking brake cable assy No.1 to the parking brake equalizer and install the parking brake cable assy No.1.
  15. INSTALL PARKING BRAKE CABLE HEAT INSULATOR Install the 2 nuts and parking brake cable heat insulator. Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf
  16. INSTALL EXHAUST PIPE ASSY CENTER (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224769-S00988693982006031100000) )
  17. INSTALL PARKING BRAKE LEVER SUB-ASSY (See «REPLACEMENT»(ref-224778-S30247658902006031100000) )
  18. INSTALL FRONT SEAT ASSY RH (See «OVERHAUL»(ref-224793-S36693401512006031100000) )
  19. INSTALL COWL SIDE TRIM SUB-ASSY RH (See «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  20. INSTALL FRONT DOOR SCUFF PLATE RH (See «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  21. INSPECT PARKING BRAKE LEVER TRAVEL (See «ADJUSTMENT»(ref-224778-S12577752942006031100000) )
  22. ADJUST PARKING BRAKE LEVER TRAVEL (See «ADJUSTMENT»(ref-224778-S12577752942006031100000) )
  23. INSTALL CONSOLE BOX ASSY RR (See «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  24. INSTALL CONSOLE UPPER REAR PANEL SUB-ASSY (See «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  25. INSTALL CONSOLE PANEL SUB-ASSY UPR FR (See «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  26. INSTALL SHIFT LEVER KNOB SUB-ASSY (MANUAL TRANSAXLE) (See «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  27. CONNECT BATTERY NEGATIVE TERMINAL
  28. INSPECT SRS WARNING LIGHT (See «DTC CHECK/CLEAR»(ref-224757-S05390184222006031100000) )

Scheme 28

Scheme 28: COMPONENTS
Scheme 28: COMPONENTS

HINT

For the parking brake cable No.2, employ the same procedures as for the parking brake cable No.3.

Scheme 29

Scheme 29: REPLACEMENT
Scheme 29: REPLACEMENT

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32
  1. REMOVE REAR WHEEL
  2. DISCONNECT REAR DISC BRAKE CALIPER ASSY LH (See «OVERHAUL»(ref-224778-S24188500742006031100000) )
  3. REMOVE REAR DISC (See «OVERHAUL»(ref-224778-S24188500742006031100000) )
  4. REMOVE PARKING BRAKE SHOE STRUT LH (See «OVERHAUL»(ref-224778-S10290197352006031100000) )
  5. REMOVE PARKING BRAKE SHOE ADJUSTING SCREW SET (See «OVERHAUL»(ref-224778-S10290197352006031100000) )
  6. REMOVE PARKING BRAKE SHOE ASSY LH NO.1 (See «OVERHAUL»(ref-224778-S10290197352006031100000) ) SST 09718-00010
  7. REMOVE PARKING BRAKE SHOE ASSY LH NO.2 (See «OVERHAUL»(ref-224778-S10290197352006031100000) ) SST 09718-00010
  8. DISCONNECT PARKING BRAKE CABLE ASSY NO.3 Remove the bolt and separate the parking brake cable assy No.3 from the backing plate.
  9. REMOVE EXHAUST PIPE ASSY CENTER (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224769-S00988693982006031100000) )
  10. REMOVE PARKING BRAKE CABLE HEAT INSULATOR (See «REPLACEMENT»(ref-224778-S04586622122006031100000) )
  11. REMOVE FUEL TANK PROTECTOR NO.1 Remove the 5 bolts and fuel tank protector No.1.
  12. REMOVE PARKING BRAKE CABLE ASSY NO.3 Remove the 4 bolts and cable retainer from the body. Disconnect the parking brake cable assy No.3 from the parking brake equalizer, and remove the parking brake cable assy No.3.
  13. INSTALL PARKING BRAKE CABLE ASSY NO.3 Connect the parking brake cable assy No.3 to the parking brake equalizer. Install the parking brake cable assy No.3 with the 4 bolts. Torque: 6.0 N.m (61 kgf.cm, 53 in.lbf (bolt A) 5.4 N.m (55 kgf.cm, 48 in.lbf (bolt B)
  14. INSTALL FUEL TANK PROTECTOR NO.1 Install the fuel tank protector No.1 with the 5 bolts. Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf
  15. INSTALL PARKING BRAKE CABLE HEAT INSULATOR (See «REPLACEMENT»(ref-224778-S04586622122006031100000) )
  16. INSTALL EXHAUST PIPE ASSY CENTER (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224769-S00988693982006031100000) )
  17. CONNECT PARKING BRAKE CABLE ASSY NO.3 Connect the parking brake cable assy No.3 to the backing plate with the bolt. Torque: 8.0 N.m (82 kgf.cm, 71 in.lbf
  18. APPLY HIGH TEMPERATURE GREASE Apply high temperature grease to the shoe attaching surface of the backing plate.
  19. INSTALL PARKING BRAKE SHOE LEVER LH (See «OVERHAUL»(ref-224778-S10290197352006031100000) )
  20. INSTALL PARKING BRAKE SHOE ASSY LH NO.2 (See «OVERHAUL»(ref-224778-S10290197352006031100000) ) SST 09718-00010
  21. INSTALL PARKING BRAKE SHOE ASSY LH NO.1 (See «OVERHAUL»(ref-224778-S10290197352006031100000) ) SST 09718-00010
  22. INSTALL PARKING BRAKE SHOE ADJUSTING SCREW SET (See «OVERHAUL»(ref-224778-S10290197352006031100000) )
  23. INSTALL PARKING BRAKE SHOE STRUT LH (See «OVERHAUL»(ref-224778-S10290197352006031100000) )
  24. INSTALL REAR DISC (See «OVERHAUL»(ref-224778-S24188500742006031100000) )
  25. CONNECT REAR DISC BRAKE CALIPER ASSY LH (See «OVERHAUL»(ref-224778-S24188500742006031100000) )
  26. ADJUST PARKING BRAKE SHOE CLEARANCE (See «OVERHAUL»(ref-224778-S10290197352006031100000) )
  27. REAR WHEEL Torque: 103 N.m (1,050 kgf.cm, 76 ft.lbf)
  28. SETTLING PARKING BRAKE SHOES AND DISC (See «OVERHAUL»(ref-224778-S10290197352006031100000) )
  29. INSPECT PARKING BRAKE LEVER TRAVEL (See «ADJUSTMENT»(ref-224778-S12577752942006031100000) )
  30. ADJUST PARKING BRAKE LEVER TRAVEL (See «ADJUSTMENT»(ref-224778-S12577752942006031100000) )
  31. CHECK FOR EXHAUST GAS LEAKS (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224769-S00988693982006031100000) )

Scheme 33

Scheme 33: COMPONENTS
Scheme 33: COMPONENTS
