Audio & Visual System: Removal & Installation Scion tC I

Entertainment Systems 18 illustrations ~1331 words

REPLACEMENT

HINT

  1. See «COMPONENTS»(ref-224790-S42714249212006031100000) .
  2. Use the same procedures for the RH side and LH side.
  3. The procedures listed below are for the LH side.
  4. Installation is in the reverse order of removal.

Scheme 1

Scheme 1
Scheme 1

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (SEE «OVERHAUL»(ref-224796-S32602758482006031100000) )
  2. REMOVE ASSIST GRIP COVER LH (SEE «OVERHAUL»(ref-224796-S32602758482006031100000) )
  3. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (SEE «OVERHAUL»(ref-224796-S32602758482006031100000) )
  4. REMOVE FRONT NO. 1 SPEAKER ASSY Disconnect the connector. Drill out the 3 rivet heads using a drill with a bit diameter of less than 4 mm (0.16 in.), and remove the front No.1 speaker assy from the front door panel. Operate the drill along the rivet head circumference and cut out the flange. CAUTION: Be careful. The cut rivet is very hot. NOTE: Prying the rivet using a drill may scratch the rivet hole or break the drill bit. After drilling out the flange, continue drilling to push out the shreds on the drill. Using a vacuum cleaner, remove the holed rivet and foreign matter from the front door panel.
  5. INSTALL FRONT NO. 1 SPEAKER ASSY Using an air riveter or hand riveter, install 3 new strike rivets on the front No.1 speaker assy on the front door panel. HINT: Install the new strike rivets in order (Scheme 2) NOTE: Do not tilt the rivet head. Doing so may scratch the riveter or bend the loosened rivet on the mandrel. Do not tilt the riveter or remove the rivet from the material. Material that is not securely tightened may deviate. The rivet should be installed only when there is no clearance between materials to ensure secure installation. Connect the connector.

HINT

  1. See «COMPONENTS»(ref-224790-S42714249212006031100000) .
  2. Use the same procedures for the RH side and LH side.
  3. The procedures listed below are for the LH side.
  4. Installation is in the reverse order of removal.

Scheme 6

Scheme 6
Scheme 6
  1. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (SEE «OVERHAUL»(ref-224796-S32602758482006031100000) )
  2. REMOVE ASSIST GRIP COVER LH (SEE «OVERHAUL»(ref-224796-S32602758482006031100000) )
  3. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (SEE «OVERHAUL»(ref-224796-S32602758482006031100000) )
  4. REMOVE FRONT NO.2 SPEAKER ASSY Disconnect the connector. Remove the screw and the front No.2 speaker assy.

HINT

  1. See «COMPONENTS»(ref-224790-S42714249212006031100000) .
  2. Use the same procedures for the RH side and LH side.
  3. The procedures listed below are for the LH side.
  4. Installation is in the reverse order of removal.

Scheme 7

Scheme 7
Scheme 7
  1. REMOVE TONNEAU COVER ASSY
  2. REMOVE DECK BOARD SUB-ASSY
  3. REMOVE BACK DOOR SCUFF PLATE (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  4. REMOVE DECK FLOOR BOX LH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  5. REMOVE DECK FLOOR BOX RH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  6. REMOVE ROPE HOOK ASSY (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  7. REMOVE REAR FLOOR BOARD NO. 1 (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  8. REMOVE REAR SEAT CUSHION ASSY (SEE «OVERHAUL»(ref-224793-S13116922602006031100000) )
  9. REMOVE REAR SEATBACK ASSY LH (SEE «OVERHAUL»(ref-224793-S13116922602006031100000) )
  10. REMOVE FRONT DOOR SCUFF PLATE LH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  11. REMOVE LUGGAGE COMPARTMENT TRIM HOOK NO. 1 (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  12. REMOVE SIDE NO. 1 TRIM ASSY LH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  13. REMOVE REAR SPEAKER ASSY Disconnect the connector. Remove the 3 screws and the rear speaker assy.
  14. INSTALL REAR SEATBACK ASSY LH (SEE «OVERHAUL»(ref-224793-S13116922602006031100000) )

HINT

  1. See «COMPONENTS»(ref-224790-S42714249212006031100000) .
  2. Installation is in the reverse order of removal.

Scheme 8

Scheme 8
Scheme 8
  1. REMOVE TONNEAU COVER ASSY
  2. REMOVE DECK BOARD SUB-ASSY
  3. REMOVE BACK DOOR SCUFF PLATE (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  4. REMOVE DECK FLOOR BOX LH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  5. REMOVE DECK FLOOR BOX RH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  6. REMOVE ROPE HOOK ASSY (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  7. REMOVE REAR FLOOR BOARD NO. 1
  8. REMOVE FRONT SEAT TRACK COVER RH REAR OUTER (SEE «OVERHAUL»(ref-224793-S36693401512006031100000) )
  9. REMOVE SEAT TRACK BRACKET COVER INNER RH (SEE «OVERHAUL»(ref-224793-S36693401512006031100000) )
  10. REMOVE FRONT SEAT ASSY RH (SEE «OVERHAUL»(ref-224793-S36693401512006031100000) )
  11. REMOVE REAR SEAT CUSHION ASSY (SEE «OVERHAUL»(ref-224793-S13116922602006031100000) )
  12. REMOVE REAR SEATBACK ASSY RH (SEE «OVERHAUL»(ref-224793-S13116922602006031100000) )
  13. REMOVE LAP BELT OUTER ANCHOR COVER (SEE «REPLACEMENT»(ref-224793-S34686199812006031100000) )
  14. DISCONNECT FRONT SEAT OUTER BELT ASSY RH (SEE «REPLACEMENT»(ref-224793-S34686199812006031100000) )
  15. REMOVE FRONT DOOR SCUFF PLATE RH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  16. REMOVE LUGGAGE COMPARTMENT TRIM HOOK NO. 1 (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  17. REMOVE SIDE NO. 1 TRIM ASSY RH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  18. REMOVE LUGGAGE COMPARTMENT TRIM HOOK NO.2 (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  19. REMOVE DECK TRIM SIDE PANEL ASSY RH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  20. REMOVE SHIFT LEVER KNOB SUB-ASSY (MANUAL TRANSAXLE) (SEE «INSTRUMENT PANEL SUB-ASSY UPPER»(ref-224792-S41617267082006031100000) )
  21. REMOVE CONSOLE PANEL SUB-ASSY UPR FR (SEE «INSTRUMENT PANEL SUB-ASSY UPPER»(ref-224792-S41617267082006031100000) )
  22. REMOVE CONSOLE UPPER REAR PANEL SUB-ASSY (SEE «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  23. REMOVE CONSOLE BOX ASSY RR (SEE «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  24. REMOVE HEATER CONTROL & ACCESSORY ASSY (SEE «OVERHAUL»(ref-224785-S11378606302006031100000) )
  25. REMOVE ANTENNA CORD SUB-ASSY Remove the bolt. Remove the all clamps and the antenna cord sub-assy.
  26. INSTALL FRONT SEAT OUTER BELT ASSY RH (SEE «REPLACEMENT»(ref-224793-S34686199812006031100000) )
  27. INSTALL REAR SEATBACK ASSY RH (SEE «OVERHAUL»(ref-224793-S13116922602006031100000) )
  28. INSTALL FRONT SEAT ASSY RH (SEE «OVERHAUL»(ref-224793-S36693401512006031100000) )

HINT

  1. See «COMPONENTS»(ref-224790-S42714249212006031100000) .
  2. Installation is in the reverse order of removal.

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. REMOVE TONNEAU COVER ASSY
  2. REMOVE DECK BOARD SUB-ASSY
  3. REMOVE BACK DOOR SCUFF PLATE (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  4. REMOVE DECK FLOOR BOX LH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  5. REMOVE DECK FLOOR BOX RH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  6. REMOVE ROPE HOOK ASSY (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  7. REMOVE REAR FLOOR BOARD NO. 1 (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  8. REMOVE REAR SEAT CUSHION ASSY (SEE «OVERHAUL»(ref-224793-S13116922602006031100000) )
  9. REMOVE REAR SEATBACK ASSY RH (SEE «OVERHAUL»(ref-224793-S13116922602006031100000) )
  10. REMOVE FRONT DOOR SCUFF PLATE RH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  11. REMOVE LUGGAGE COMPARTMENT TRIM HOOK NO. 1 (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  12. REMOVE SIDE NO. 1 TRIM ASSY RH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  13. REMOVE LUGGAGE COMPARTMENT TRIM HOOK NO.2 (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  14. REMOVE DECK TRIM SIDE PANEL ASSY RH (SEE «REPLACEMENT»(ref-224797-S17527791092006031100000) )
  15. REMOVE ROOF ANTENNA POLE SUB-ASSY (SEE «ROOF ANTENNA POLE SUB-ASSY»(ref-224790-S01643489962006031100000) )
  16. REMOVE ANTENNA NUT Using a snap ring pliers, remove the antenna nut (Scheme 9) Tool Part Number: Snap Ring Pliers: 09905-00013 Claw: 09904-00060 HINT: Wrap the tip of the snap ring pliers with protective tape to prevent damage to the parts.
  17. REMOVE ANTENNA ORNAMENT Remove the antenna ornament.
  18. REMOVE AMPLIFIER ANTENNA ASSY Disconnect the connector. Remove the nut. Remove the amplifier antenna assy in the direction shown by the arrow in (Scheme 12).
  19. INSTALL REAR SEATBACK ASSY RH (SEE «OVERHAUL»(ref-224793-S13116922602006031100000) )

HINT

  1. See «COMPONENTS»(ref-224790-S42714249212006031100000)
  2. Installation is in the reverse order of removal.

Scheme 13

Scheme 13
Scheme 13
  1. REMOVE ROOF ANTENNA POLE SUB-ASSY Remove the antenna pole sub-assy by turning it counterclockwise.

HINT

  1. See «COMPONENTS»(ref-224790-S42714249212006031100000) .
  2. Installation is in the reverse order of removal.

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. REMOVE SHIFT LEVER KNOB SUB-ASSY (MANUAL TRANSAXLE) (SEE «INSTRUMENT PANEL SUB-ASSY UPPER»(ref-224792-S41617267082006031100000) )
  2. REMOVE CONSOLE PANEL SUB-ASSY UPR FR (SEE «INSTRUMENT PANEL SUB-ASSY UPPER»(ref-224792-S41617267082006031100000) )
  3. REMOVE CIGARETTE LIGHTER COVER Disengage the 2 claws and remove the cigarette lighter cover.
  4. REMOVE CIGARETTE LIGHTER ASSY Remove the cigarette lighter knob and element assy. Turn the socket in the direction (Scheme 15), disengage the claw between the socket and the cigarette lighter bezel stay, and pull out the socket. Align the socket with the notch on the cigarette lighter bezel stay, and remove the cigarette lighter assy.
  5. INSTALL CIGARETTE LIGHTER ASSY Align the socket with the notch on the cigarette lighter bezel stay and push the cigarette lighter assy in as hard as possible. Install the cigarette lighter knob and element assy.

HINT

  1. See «COMPONENTS»(ref-224790-S42714249212006031100000) .
  2. Installation is in the reverse order of removal.

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. REMOVE SHIFT LEVER KNOB SUB-ASSY (MANUAL TRANSAXLE) (SEE «INSTRUMENT PANEL SUB-ASSY UPPER»(ref-224792-S41617267082006031100000) )
  2. REMOVE CONSOLE PANEL SUB-ASSY UPR FR (SEE «INSTRUMENT PANEL SUB-ASSY UPPER»(ref-224792-S41617267082006031100000) )
  3. REMOVE CONSOLE UPPER REAR PANEL SUB-ASSY (SEE «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  4. REMOVE CONSOLE BOX ASSY RR (SEE «INSTRUMENT PANEL SUB-ASSY LOWER»(ref-224792-S32836266652006031100000) )
  5. REMOVE POWER POINT SOCKET ASSY Turn the socket in the direction (Scheme 17), disengage the claw between the socket and the power point socket cover, and pull out the socket. Align the socket with the notch on the power point socket cover, and remove the power point socket assy.
  6. INSTALL POWER POINT SOCKET ASSY Align the socket with the notch on the power point socket cover and push the power point socket assy in as hard as possible.
