Emission Control: Removal & Installation Scion tC I

REPLACEMENT

Note. When disconnecting the battery terminal, initialize the following system after the terminal is reconnected.

SYSTEM REFERENCE

Scheme 35

Scheme 36

Scheme 37

1. DISCONNECT BATTERY NEGATIVE TERMINAL
2. REMOVE VACUUM SWITCHING VALVE ASSY NO.1 Disconnect the vacuum switching valve connector. Remove the wire harness clamp. Disconnect the fuel vapor feed hose No. 1 from the vacuum switching valve. Disconnect the fuel vapor feed hose No. 2 from the vacuum switching valve. Remove the vacuum switching valve from the air cleaner hose.
3. INSTALL VACUUM SWITCHING VALVE ASSY NO.1 Install the vacuum switching valve onto the air cleaner hose. Connect the fuel vapor feed hose No. 2 to the vacuum switching valve. NOTE: Make sure that the hose clip and mark are at the correct angle when installing. Connect the fuel vapor feed hose No. 1 to the vacuum switching valve. NOTE: Make sure that the hose clip and mark are at the correct angle when installing. Install the wire harness clamp. Connect the vacuum switching valve connector.
4. CONNECT BATTERY NEGATIVE TERMINAL Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf)

Note. When disconnecting the battery terminal, initialize the following system after the terminal is reconnected.

SYSTEM REFERENCE

Scheme 38

Scheme 39

1. DISCONNECT BATTERY NEGATIVE TERMINAL
2. REMOVE AIR FUEL RATIO SENSOR Disconnect the connector and clamp. Using SST, remove the air fuel ratio sensor. SST 09224-00010
3. INSTALL AIR FUEL RATIO SENSOR Using SST, install the air fuel ratio sensor. SST 09224-00010 Torque: 44 N.m (449 kgf.cm, 32 ft.lbf) Connect the connector and clamp.
4. CONNECT BATTERY NEGATIVE TERMINAL Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf)
5. CHECK FOR EXHAUST GAS LEAKAGE

Note. When disconnecting the battery terminal, initialize the following system after the terminal is reconnected.

SYSTEM REFERENCE

Scheme 40

Scheme 41

1. DISCONNECT BATTERY NEGATIVE TERMINAL
2. REMOVE HEATED OXYGEN SENSOR Disconnect the heated oxygen sensor connector. Using SST, remove the heated oxygen sensor. SST 09224-00010
3. INSTALL HEATED OXYGEN SENSOR Using SST, install the heated oxygen sensor. SST 09224-00010 Torque: 44 N.m (449 kgf.cm, 32 ft.lbf) Connect the heated oxygen sensor connector.
4. CONNECT BATTERY NEGATIVE TERMINAL Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf)
5. CHECK FOR EXHAUST GAS LEAKAGE

Note. When disconnecting the battery terminal, initialize the following system after the terminal is reconnected.

SYSTEM REFERENCE

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

1. DISCONNECT BATTERY NEGATIVE TERMINAL
2. REMOVE FLOOR PANEL BRACE FRONT (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224769-S00988693982006031100000) )
3. REMOVE EXHAUST PIPE ASSY CENTER (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224766-S14470383222006031100000) )
4. REMOVE FUEL TANK PROTECTOR NO.1 (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224766-S14470383222006031100000) )
5. REMOVE REAR SUSPENSION BRACE LOWER RH (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224766-S14470383222006031100000) )
6. REMOVE CHARCOAL CANISTER ASSY Disconnect the leak detection pump connector. Disconnect the fuel emission hose and clamp. Disconnect the fuel tank vent hose. Pinch the retainer and pull out the fuel tank vent connector with the fuel tank vent connector pushed to the pipe side to disconnect the fuel tank vent hose from the charcoal canister. NOTE: Remove dirt or foreign objects on the fuel tank vent connector before this work. Do not allow any scratches or foreign objects on the parts when disconnecting as the fuel tank vent connector has the O-ring that seals the pipe. Perform this work by hand. Do not use any tools. Do not forcibly bend, twist or turn the nylon tube. Protect the connected part by covering it with a vinyl bag after disconnecting the fuel tank vent hose. If the fuel tank vent connector and pipe are stuck, push and pull them to release. Disconnect the fuel tank vent hose. Pinch the tab of the retainer of the fuel tube connector to remove the lock claws and slide it as shown in the illustration. Pull the fuel tank vent hose out of the charcoal canister. NOTE: Remove any dirt or foreign objects on the fuel tube connector before performing this work. Do not allow ant scratches or foreign objects on the parts when disconnecting as the fuel tube connector has the O-ring that seals the pipe. Perform this work by hand. Do not use any tools. Do not forcibly bend, twist or turn the nylon tube. Protect the disconnected part by covering it with a vinyl bag after disconnecting the fuel tank vent hose. If the fuel tube connector and pipe are stuck, push and pull to release them. Using a clip remove, remove the clip. HINT: The clip is for placing the part temporarily when working at a workshop. There is no need of installing the clip when reassembling. Remove the 2 bolts and charcoal canister.
7. INSTALL CHARCOAL CANISTER ASSY Temporarily hook the claw of the charcoal canister bracket around the fuel tank hoses, and install the charcoal canister with the 2 bolts. Torque: 19 N.m (194 kgf.cm, 14 ft.lbf) Install the fuel vent hose. Align the fuel tube connector with the pipe, then push in the fuel tube connector until the contacts the seat to contact the fuel tank vent hose to the pipe, then push up the retainer to the claws lock. NOTE: Check that there are no scratches or foreign objects around the connected part of the fuel tube connector and pipe before performing this work. After connecting the fuel tank vent hose, check that the fuel tank vent hose is securely connected by pulling the fuel tube connector and pipe. Connect the fuel tank vent hose. Align the fuel tank vent connector with the pipe, then push in the fuel tank vent connector until the retainer makes a "click" sound to connect the fuel tank vent hose to the charcoal canister. NOTE: Check that there are no scratches or foreign objects around the connected part of the fuel tank vent connector and pipe before this work. After connecting the fuel tank vent hose, check that the fuel tank vent hose is securely connected by pulling the quick connector. Install the fuel emission hose and clamp. Install the leak detection pump connector.
8. INSTALL REAR SUSPENSION BRACE LOWER RH (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224766-S14470383222006031100000) )
9. INSTALL FUEL TANK PROTECTOR NO.1 (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224766-S14470383222006031100000) )
10. INSTALL EXHAUST PIPE ASSY CENTER (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224766-S14470383222006031100000) )
11. INSTALL FLOOR PANEL BRACE FRONT (See «REMOVAL & INSTALLATION AND DISASSEMBLY & REASSEMBLY»(ref-224769-S00988693982006031100000) )
12. CONNECT BATTERY NEGATIVE TERMINAL Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf)
13. CHECK FOR EXHAUST GAS LEAKAGE
