PRECAUTION
Note. When disconnecting the negative (-) battery terminal, initialize the following systems after the terminal is reconnected.
| System Name | Refer To |
|---|---|
| Power window control system | INITIALIZATION |
| Sliding roof system | INITIALIZATION |
POWER WINDOW CONTROL AND SLIDING ROOF SYSTEMS REFERENCE
Note. Perform the RESET MEMORY (AT initialization) when replacing the automatic transaxle assy, engine assy or ECM (SEE INITIALIZATION ).
HINT
RESET MEMORY can not be completed by only disconnecting the battery terminal.
DEFINITION OF TERMS
| Term | Definition |
|---|---|
| Monitor description | Description of what the ECM monitors and how it detects malfunctions (monitoring purpose and its details). |
| Related DTCs | Diagnostic code |
| Typical enabling condition | Preconditions that allow the ECM to detect malfunctions. With all preconditions satisfied, the ECM sets the DTC when the monitored value(s) exceeds the malfunction threshold(s). |
| Sequence of operation | The priority order that is applied to monitoring, if multiple sensors and components are used to detect the malfunction. While a sensor is being monitored, another sensor or component will not be monitored until the previous monitoring has concluded. |
| Required sensor/components | The sensors and components that are used by the ECM to detect malfunctions. |
| Frequency of operation | The number of times that the ECM checks for malfunctions per driving cycle. "Once per driving cycle" means that the ECM detects a malfunction only one time during a single driving cycle. "Continuous" means that the ECM detects a malfunction every time when the enabling condition is met. |
| Duration | The minimum time that the ECM must sense a continuous deviation in the monitored value(s) before setting a DTC. This timing begins after the "typical enabling conditions" are met. |
| Malfunction thresholds | Beyond this value, the ECM will conclude that there is a malfunction and set a DTC. |
| MIL operation | MIL illumination timing after a defect is detected. "Immediately" means that the ECM illuminates the MIL the instant the ECM determines that there is a malfunction. "2 driving cycle" means that the ECM illuminates the MIL if the same malfunction is detected again in the 2nd driving cycle. |
| Component operating range | Normal operation range of sensors and solenoids under normal driving conditions. Use these ranges as a reference. They cannot be used to judge if a sensor or solenoid is defective or not. |
TERMS DEFINITIONS
PART AND SYSTEM NAME LIST
This reference list indicates the part names used in this information along with their definitions.
| Part and system name | Definition |
|---|---|
| Toyota HCAC system, Hydrocarbon adsorptive Catalyst (HCAC) system, HC adsorptive three-way catalyst | HC adsorptive three-way catalytic converter |
| Variable valve timing sensor, VVT sensor | Camshaft position sensor |
| Variable valve timing system, VVT system | Camshaft timing control system |
| Camshaft timing oil control valve, Oil control valve OCV, VVT, VSV | Camshaft timing oil control valve |
| Variable timing and lift, VVTL | Camshaft timing and lift control |
| Crankshaft position sensor "A" | Crankshaft position sensor |
| Engine speed sensor | Crankshaft position sensor |
| THA | Intake air temperature |
| Knock control module | Engine knock control module |
| Knock sensor | Engine knock sensor |
| Mass or volume air flow circuit | Mass air flow sensor circuit |
| Vacuum sensor | Manifold air pressure sensor |
| Internal control module, Control module, Engine control ECU, PCM | Power train control module |
| FC idle | Deceleration fuel cut |
| Idle air control valve | Idle speed control |
| VSV for CCV, Canister close valve VSV for canister control | Evaporative emissions canister vent valve |
| VSV for EVAP, Vacuum switching valve assembly No.1, EVAP VAV, Purge VSV | Evaporative emissions canister purge valve |
| VSV for pressure switching valve, Bypass | VSV Evaporative emission pressure switching valve |
| Vapor pressure sensor, EVAP pressure sensor, Evaporative emission control system pressure sensor | Fuel tank pressure sensor |
| Charcoal canister | Evaporative emissions canister |
| ORVR system | On-board refueling vapor recovery system |
| Intake manifold runner control | Intake manifold tuning system |
| Intake manifold runner valve, IMRV, IACV (runner valve) | Intake manifold tuning valve |
| Intake control VSV | Intake manifold tuning solenoid valve |
| AFS | Air fuel ratio sensor |
| O2 sensor | Heater oxygen sensor |
| Oxygen sensor pumping current circuit | Oxygen sensor output signal |
| Oxygen sensor reference ground circuit | Oxygen sensor signal ground |
| Accel position sensor | Accelerator pedal position sensor |
| Throttle actuator control motor, Actuator control motor, Electronic throttle motor, Throttle control motor | Electronic throttle actuator |
| Electronic throttle control system, Throttle actuator control system | Electronic throttle control system |
| Throttle/pedal position sensor, Throttle/pedal position switch, Throttle position sensor/switch | Throttle position sensor |
| Turbo press sensor | Turbocharger pressure sensor |
| Turbo VSV | Turbocharger pressure control solenoid valve |
| P/S pressure switch | Power-steering pressure switch |
| VSV for ACM | Active control engine mount |
| Speed sensor, Vehicle speed sensor "A", Speed sensor for skid control ECU | Vehicle speed sensor |
| ATF temperature sensor, Trans. fluid temp. sensor, ATF temperature sensor "A" | Transmission fluid temperature sensor |
| Electronic controlled automatic transmission, ECT | Electronically controlled automatic |
| Intermediate shaft speed sensor "A" | Counter gear speed sensor |
PART AND SYSTEM NAME LIST (1 OF 2)
| Part and system name | Definition |
|---|---|
| Output speed sensor | Output shaft speed sensor |
| Input speed sensor, Input turbine speed sensor "A", Speed sensor (NT), Turbine speed sensor | Input turbine speed sensor |
| PNP switch, NSW | Park/neutral position switch |
| Pressure control solenoid | Transmission pressure control solenoid |
| Shift solenoid | Transmission shift solenoid valve |
| Transmission control switch, Shift lock control unit | Shift lock control module |
| Engine immobilizer system, Immobilizer system | Vehicle anti-theft system |
PART AND SYSTEM NAME LIST (2 OF 2)
Scheme 152
SYSTEM DIAGRAM
The configuration of the electronic control system in the U241E automatic transaxles is (Scheme 153)
Scheme 153
LIST OF DISABLE A MONITOR
HINT
This table indicates ECM monitoring status for the items in the upper columns if the DTCs in each line on the left are being set.
As for the "X" mark, when the DTC on the left is stored, detection of the DTC in the upper column is not performed.
Scheme 154
Scheme 155
Scheme 156
Scheme 157
Scheme 158
Scheme 159
MONITOR DRIVE PATTERN
- MONITOR DRIVE PATTERN FOR ECT TEST Perform this drive pattern as one method to simulate the detection conditions of the ECT malfunctions. (The DTCs may not be detected due to the actual driving conditions. And some codes may not be detected through this drive pattern). HINT: Preparation for driving Warm up the engine sufficiently. (Engine coolant temperature is 60°C (140°F) or higher.) Drive the vehicle when the atmospheric temperature is -10°C (14°F) or higher. (Malfunction is not detected when the atmospheric temperature is -10°C (14°F) or less.) Driving note Drive the vehicle through all gears. Stop -> 1st -> 2nd -> 3rd -> O/D -> O/D (lock-up ON). Repeat the above driving pattern three times or more. NOTE: The monitor status can be checked using the OBD II scan tool. When using the hand-held tester, monitor status can be found in the "ENHANCED OBD II/DATA LIST" or under "CARB OBD II". In the event that the drive pattern must be interrupted (possibly due to traffic conditions or other factors), the drive pattern can be resumed and, in most cases, the monitor can be completed. CAUTION: Perform this drive pattern on a level road as much as possible and strictly observe the posted speed limits and traffic laws while driving.
Scheme 160
MONITOR STRATEGY
| Related DTCs | P0705: Park/neutral position switch/Verify switch input |
|---|---|
| Required sensors/Components | Park/neutral position switch |
| Frequency of operation | Continuous |
| Duration | 2 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
TYPICAL ENABLING CONDITIONS
CONDITION (A) AND (B)
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Ignition switch | ON |
| Battery voltage | 10.5 V or more |
TYPICAL ENABLING CONDITIONS (A) AND (B)
TYPICAL MALFUNCTION THRESHOLDS
Either of the following conditions is met: TYPICAL MALFUNCTION THRESHOLDS CONDITION (A) and TYPICAL MALFUNCTION THRESHOLDS CONDITION (B) (1 OF 2) or TYPICAL MALFUNCTION THRESHOLDS CONDITION (B) (2 OF 2)
CONDITION (A)
| Number of the following signal input at the same time | 2 or more |
|---|---|
| NSW switch | ON |
| R switch | ON |
| D switch | ON |
| 2 switch | ON |
TYPICAL MALFUNCTION THRESHOLDS CONDITION (A)
Condition (B)
Both (i) and (ii) are met
(i) Either of the followings is met
| NSW switch | ON |
|---|---|
| R switch | ON |
TYPICAL MALFUNCTION THRESHOLDS CONDITION (B) (1 OF 2)
(ii) Either of the followings is met
| 3 switch | ON |
|---|---|
| L switch | ON |
TYPICAL MALFUNCTION THRESHOLDS CONDITION (B) (2 OF 2)
COMPONENT OPERATING RANGE
| Park/neutral position switch | The park/neutral position switch sends only one signal to the ECM. |
COMPONENT OPERATING RANGE
Scheme 161
| Related DTCs | P0710: ATF temperature sensor/Range check (Chattering) |
|---|---|
| P0712: ATF temperature sensor/Range check (Low resistance) | |
| P0713: ATF temperature sensor/Range check (High resistance) | |
| Required sensors/Components | ATF temperature sensor (TFT sensor) |
| Frequency of operation | Continuous |
| Duration | 0.5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
P0710: Range check (Chattering)
P0712: RANGE CHECK (LOW RESISTANCE)
| The monitor will run whenever these DTCs are not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| The typical enabling condition is not available. |
TYPICAL ENABLING CONDITIONS P0712 RANGE CHECK (LOW RESISTANCE)
P0713: RANGE CHECK (HIGH RESISTANCE)
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Time after engine start | 15 min. or more |
TYPICAL ENABLING CONDITIONS P0713 RANGE CHECK (HIGH RESISTANCE)
P0710: RANGE CHECK (CHATTERING)
| TFT (transmission fluid temperature) sensor resistance | Less than 79 ohm |
|---|---|
| Or | |
| More than 156 kohm |
TYPICAL MALFUNCTION THRESHOLDS P0710 RANGE CHECK (CHATTERING)
P0712: RANGE CHECK (LOW RESISTANCE)
| TFT sensor resistance | Less than 79 ohm |
TYPICAL MALFUNCTION THRESHOLDS P0712 RANGE CHECK (LOW RESISTANCE)
P0713: RANGE CHECK (HIGH RESISTANCE)
| TFT sensor resistance | More than 156 kohm |
TYPICAL MALFUNCTION THRESHOLDS P0713 RANGE CHECK (HIGH RESISTANCE)
| TFT sensor | Atmospheric temperature - approx. 130°C (266°F) |
COMPONENT OPERATING RANGE
Scheme 162
| Related DTCs | P0711: ATF temperature sensor/Rationality check |
|---|---|
| Required sensors/Components | ATF temperature sensor (TFT sensor) |
| Frequency of operation | Continuous |
| Duration | 3 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Time after engine start | 16 min. and 40 sec. or more |
| ECT (Engine coolant temperature) | 15 °C (5°F) or more |
| TFT (transmission fluid temperature) sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| IAT (Intake air temperature) sensor circuit | Not circuit malfunction |
| Driving distance after engine start | 9 km/h (5.6 mph) |
| IAT (12 sec. after engine start) | 10 °C (14°F) or more |
| ECT (12 sec. after engine start) | 10 °C (14°F) or more |
TYPICAL ENABLING CONDITIONS
| TFT (transmission fluid temperature) | Less than 10°C (50°F) |
TYPICAL MALFUNCTION THRESHOLDS
| TFT (transmission fluid temperature) | Atmospheric temperature - approx. 130°C (266°F) |
COMPONENT OPERATING RANGE
Scheme 163
| Related DTCs | P0717: Speed sensor (NT)/Verify pulse input |
|---|---|
| Required sensors/Components | Speed sensor (NT), Speed sensor (NC) |
| Frequency of operation | Continuous |
| Duration | 5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Shift change | Shift change is completed and before starting next shift change operation |
| ECM selected gear | 2nd, 3rd or 4th |
| Output shaft rpm | 1,000 rpm or more |
| NSW switch | OFF |
| R switch | OFF |
| L switch | OFF |
| Engine | Running |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS
| Sensor signal rpm | Less than 300 rpm |
TYPICAL MALFUNCTION THRESHOLDS
| Speed sensor (NT) | Turbine speed is equal to engine speed with lock-up ON |
COMPONENT OPERATING RANGE
Scheme 164
Scheme 165
Scheme 166
Scheme 167
- INSPECT SPEED SENSOR INSTALLATION Check the speed sensor installation. OK: The (Scheme 165) bolt is tightened properly and there is no clearance between the sensor and transaxle case. NG: REPLACE SPEED SENSOR (NT) OK: Go to next step.
- INSPECT SPEED SENSOR (NT) Disconnect the speed sensor connector from the transaxle. Measure the resistance according to the value(s) in the table shown in «SPEED SENSOR (NT) SPECIFIED CONDITIONS»(ref-224756-S28606841322006031100000). STANDARD: SPEED SENSOR (NT) SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) 1 - 2 560 to 680 ohm NG: REPLACE SPEED SENSOR (NT) OK: Go to next step.
- CHECK HARNESS AND CONNECTOR (SPEED SENSOR - ECM) Connect the speed sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table shown in «SPEED SENSOR - ECM SPECIFIED CONDITIONS»(ref-224756-S05642987822006031100000). STANDARD: SPEED SENSOR - ECM SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) E7 - 27 (NT+) - E7 - 35 (NT-) 560 to 680 ohm Measure the resistance according to the value(s) in the table shown in «SPEED SENSOR - ECM SPECIFIED CONDITIONS (CHECK FOR SHORT)»(ref-224756-S11080522172006031100000). STANDARD (CHECK FOR SHORT): SPEED SENSOR - ECM SPECIFIED CONDITIONS (CHECK FOR SHORT): Tester Connection Specified Condition E7 - 27 (NT+) - Body ground 10 kohm or higher E7 - 35 (NT-) - Body ground NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-224750-S28128780772006031100000) ) OK: REPLACE ECM (SEE «REPLACEMENT»(ref-224765-S19142744612006031100000) )
| Related DTCs | P0724: Stop light switch/Range check/Rationality |
|---|---|
| Required sensors/Components | Stop light switch, Vehicle speed sensor |
| Frequency of operation | Continuous |
| Duration | GO and STOP 5 times |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 8 V or more |
| Starter | OFF |
| Ignition switch | ON |
| GO (vehicle speed is 30 km/h (18.63 mph) or more) | Once |
| STOP (vehicle speed is less than 3 km/h (1.86 mph)) | Once |
TYPICAL ENABLING CONDITIONS
| Brake switch | Remain ON during GO and STOP 5 times |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 168
| Related DTCs | P0741 |
|---|---|
| Shift solenoid valve DSL/OFF malfunction | |
| Shift solenoid valve DSL/ON malfunction | |
| Required sensors/Components | Shift solenoid valve DSL, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE), Throttle position sensor (VPA1), Mass air flow sensor (MAF), Transmission temperature sensor (THO1), Engine coolant temperature sensor (ECT) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction |
| 3.5 sec. | |
| ON malfunction | |
| 1.8 sec. | |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
ALL
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 60°C (140°F) or higher |
| TFT (transmission fluid temperature) | 20 °C (-4°F) or higher |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Shift solenoid valve DSL circuit | Not circuit malfunction |
| Electronic throttle system | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS (ALL)
OFF malfunction
| ECM lock-up command | ON |
|---|---|
| ECM selected gear | 3rd or 4th |
| Vehicle speed | 25 km/h (15.5 mph) or more |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION)
ON malfunction
| ECM lock-up command | OFF |
|---|---|
| ECM selected gear | 3rd or 4th |
| Vehicle speed | 25 to 60 km/h (15.5 to 37.2 mph) |
| Throttle valve opening angle | 8% or more |
TYPICAL ENABLING CONDITIONS (ON MALFUNCTION)
Either of the following conditions is met: OFF malfunction or ON malfunction
OFF MALFUNCTION
| Engine speed - Input (turbine) speed | 100 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS (OFF MALFUNCTION)
ON malfunction
2 detections are necessary per driving cycle
1st detection; temporary flag ON
2nd detection; pending fault code ON
Vehicle speed must be under 10 km/h (6.2 mph) once before 2nd detection
| Difference between engine speed and input (turbine) speed | Less than 35 rpm |
TYPICAL MALFUNCTION THRESHOLDS (ON MALFUNCTION)
| Related DTCs | P0746 |
|---|---|
| Shift solenoid valve SL1/OFF malfunction | |
| Shift solenoid valve SL1/ON malfunction | |
| Required sensors/Components | Shift solenoid valve SL1, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | OFF malfunction, ON malfunction (A) |
| 0.8 sec. | |
| ON malfunction (B) | |
| 1 sec. | |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
ALL
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 60°C (140°F) or higher |
| TFT (transmission fluid temperature) | 20 °C (-4°F) or higher |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Electronic throttle system | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS (ALL)
OFF MALFUNCTION
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | 10 to 40 km/h (6.2 to 24.9 mph) |
| Throttle valve opening angle | 3.5% or more (varies with engine speed) |
TYPICAL ENABLING CONDITIONS (OFF MALFUNCTION)
ON MALFUNCTION (A)
| ECM selected gear | 2nd |
|---|---|
| Vehicle speed | 10 km/h (6.2 mph) or more |
| Throttle valve opening angle | 3.5% or more (varies with engine speed) |
TYPICAL ENABLING CONDITIONS ON MALFUNCTION (A)
ON MALFUNCTION (B)
| ECM lock-up command | OFF |
|---|---|
| ECM selected gear | 3rd or 4th |
TYPICAL ENABLING CONDITIONS ON MALFUNCTION (B)
Either of the following conditions is met: OFF malfunction, or ON malfunction (A) and (B)
2 detections are necessary per driving cycle
1st detection; temporary flag ON
2nd detection; pending fault code ON
OFF MALFUNCTION
| Input (turbine) speed/Intermediate shaft speed | 1.49 to 1.63 |
TYPICAL MALFUNCTION THRESHOLDS OFF MALFUNCTION
ON MALFUNCTION (A)
| Input (turbine) speed/Intermediate shaft speed | 2.72 to 2.86 |
TYPICAL MALFUNCTION THRESHOLDS ON MALFUNCTION (A)
ON MALFUNCTION (B)
| Engine speed - Input (turbine) speed | 250 rpm or more |
TYPICAL MALFUNCTION THRESHOLDS ON MALFUNCTION (B)
| Related DTCs | P0748: Shift solenoid valve SL1/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SL1 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 10 V or more |
| Starter | OFF |
| Ignition switch | ON |
TYPICAL ENABLING CONDITIONS
| Output signal duty | 100% |
TYPICAL MALFUNCTION THRESHOLDS
| Output signal duty | Less than 100% |
COMPONENT OPERATING RANGE
Scheme 169
Scheme 170
Scheme 171
Scheme 172
- INSPECT TRANSMISSION WIRE (SL1) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table shown in «TRANSMISSION WIRE (SL1) SPECIFIED CONDITIONS»(ref-224756-S08601301922006031100000) . STANDARD: TRANSMISSION WIRE (SL1) SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) 5 (SL1+) - 10 (SL1-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in the table shown in «TRANSMISSION WIRE (SL1) STANDARD (CHECK FOR SHORT)»(ref-224756-S15968217662006031100000) . STANDARD (CHECK FOR SHORT): TRANSMISSION WIRE (SL1) STANDARD (CHECK FOR SHORT): Tester Connection Specified Condition SL1+ - Body ground 10 kohm or higher SL1- - Body ground NG: Go to step 3 OK: Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table shown in «TRANSMISSION WIRE - ECM SPECIFIED CONDITIONS»(ref-224756-S32380059262006031100000) . STANDARD: TRANSMISSION WIRE - ECM SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) E7 - 19 (SL1+) - E7 - 18 (SL1-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in the table shown in «TRANSMISSION WIRE - ECM SPECIFIED CONDITIONS (CHECK FOR SHORT)»(ref-224756-S14313629642006031100000) . STANDARD (CHECK FOR SHORT): TRANSMISSION WIRE - ECM SPECIFIED CONDITIONS (CHECK FOR SHORT): Tester Connection Specified Condition E7 - 19 (SL1+) - Body ground 10 kohm or higher E7 - 18 (SL1-) - Body ground NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-224750-S28128780772006031100000) ) OK: REPLACE ECM (SEE «REPLACEMENT»(ref-224765-S19142744612006031100000) )
- INSPECT SHIFT SOLENOID VALVE (SL1) Remove the shift solenoid valve SL1. Measure the resistance according to the value(s) in the table shown in «SHIFT SOLENOID VALVE (SL1) SPECIFIED CONDITIONS»(ref-224756-S15421070692006031100000) . STANDARD: SHIFT SOLENOID VALVE (SL1) SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohm Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK: The solenoid makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE (SL1) OK: REPAIR OR REPLACE TRANSMISSION WIRE (SEE «TRANSMISSION WIRE (ATM)»(ref-224780-S14904518342006031100000) )
| Related DTCs | P0766 |
|---|---|
| Shift solenoid valve S4/ON malfunction | |
| Shift solenoid valve S4/OFF malfunction | |
| Required sensors/Components | Shift solenoid valve S4, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
ALL
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 60°C (140°F) or higher |
| TFT (transmission fluid temperature) | 20°C (-4°F) or higher |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Electronic throttle system | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS (ALL)
OFF MALFUNCTION
| ECM selected gear | 4th |
|---|---|
| Vehicle speed | 10 km/h (6.2 mph) or more |
| Throttle valve opening angle | 5% or more |
TYPICAL ENABLING CONDITIONS OFF MALFUNCTION
ON MALFUNCTION
| ECM selected gear | 3rd |
|---|---|
| Vehicle speed | 10 km/h (6.2 mph) or more |
| Throttle valve opening angle | 5% or more |
TYPICAL ENABLING CONDITIONS ON MALFUNCTION
Either of the following conditions is met: OFF malfunction or ON malfunction
2 detections are necessary per driving cycle
1st detection; temporary flag ON
2nd detection; pending fault code ON
OFF MALFUNCTION
| Intermediate shaft speed/Output speed | 1.34 to 1.48 |
TYPICAL MALFUNCTION THRESHOLDS OFF MALFUNCTION
ON MALFUNCTION
| Intermediate shaft speed/Output speed | 0.95 to 1.09 |
TYPICAL MALFUNCTION THRESHOLDS ON MALFUNCTION
| Related DTCs | P0776 |
|---|---|
| Shift solenoid valve SL2/OFF malfunction | |
| Shift solenoid valve SL2/ON malfunction | |
| Required sensors/Components | Shift solenoid valve SL2, Speed sensor (NT), Speed sensor (NC), Crankshaft position sensor (NE) |
| Frequency of operation | Continuous |
| Duration | 0.8 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
ALL
| Transmission range | "D" |
|---|---|
| ECT (Engine coolant temperature) | 60°C (140°F) or higher |
| TFT (transmission fluid temperature) | 20 °C (-4°F) or higher |
| TFT sensor circuit | Not circuit malfunction |
| ECT sensor circuit | Not circuit malfunction |
| Turbine speed sensor circuit | Not circuit malfunction |
| Intermediate shaft speed sensor circuit | Not circuit malfunction |
| Output speed sensor circuit | Not circuit malfunction |
| Shift solenoid valve SL1 circuit | Not circuit malfunction |
| Shift solenoid valve SL2 circuit | Not circuit malfunction |
| Shift solenoid valve S4 circuit | Not circuit malfunction |
| Electronic throttle system | Not circuit malfunction |
TYPICAL ENABLING CONDITIONS ALL
OFF MALFUNCTION
| ECM selected gear | 1st |
|---|---|
| Vehicle speed | 10 to 40 km/h (6.2 to 24.9 mph) |
| Throttle valve opening angle | 3.5% or more (varies with engine speed) |
TYPICAL ENABLING CONDITIONS OFF MALFUNCTION
ON MALFUNCTION
| ECM selected gear | 3rd or 4th |
|---|---|
| Vehicle speed | 10 km/h (6.2 mph) or more |
| Throttle valve opening angle | 3.5% or more (varies with engine speed) |
TYPICAL ENABLING CONDITIONS ON MALFUNCTION
Either of the following conditions is met: OFF malfunction or ON malfunction
2 detections are necessary per driving cycle
1st detection; temporary flag ON
2nd detection; pending fault code ON
OFF MALFUNCTION
| Input (turbine) speed/Intermediate shaft speed | 0.93 to 1.07 |
TYPICAL MALFUNCTION THRESHOLDS OFF MALFUNCTION
ON MALFUNCTION
| Input (turbine) speed/Intermediate shaft speed | 1.49 to 1.63 |
TYPICAL MALFUNCTION THRESHOLDS ON MALFUNCTION
| Related DTCs | P0778: Shift solenoid valve SL2/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SL2 |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 10 V or more |
| Starter | OFF |
| Ignition switch | ON |
TYPICAL ENABLING CONDITIONS
| Output signal duty | 100% |
TYPICAL MALFUNCTION THRESHOLDS
| Output signal duty | Less than 100% |
COMPONENT OPERATING RANGE
Scheme 173
Scheme 174
Scheme 175
Scheme 176
Scheme 177
Scheme 178
- INSPECT TRANSMISSION WIRE (SL2) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table shown in «TRANSMISSION WIRE (SL2) SPECIFIED CONDITIONS»(ref-224756-S31457332832006031100000). STANDARD: TRANSMISSION WIRE (SL2) SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) 4 (SL2+) - 9 (SL2-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in the table (Scheme 174) Standard (Check for short): NG: Go to step 3 OK: Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table shown in «TRANSMISSION WIRE - ECM SPECIFIED CONDITIONS»(ref-224756-S03594174302006031100000). STANDARD: TRANSMISSION WIRE - ECM SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) E7 - 15 (SL2+) - E7 - 14 (SL2-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in the table (Scheme 176) Standard (Check for short): NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-224750-S28128780772006031100000) ) OK: REPLACE ECM (SEE «REPLACEMENT»(ref-224765-S19142744612006031100000) )
- INSPECT SHIFT SOLENOID VALVE (SL2) Remove the shift solenoid valve SL2. Measure the resistance according to the value(s) in the table shown in «SHIFT SOLENOID VALVE SL2 SPECIFIED CONDITIONS»(ref-224756-S10257637182006031100000). STANDARD: SHIFT SOLENOID VALVE SL2 SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohm Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK: The solenoid makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE (SL2) OK: REPAIR OR REPLACE TRANSMISSION WIRE (SEE «TRANSMISSION WIRE (ATM)»(ref-224780-S14904518342006031100000) )
| Related DTCs | P0793: Speed sensor (NC)/Verify pulse input |
|---|---|
| Required sensors/Components | Speed sensor (NC), Speed sensor (NT), NSW switch |
| Frequency of operation | Continuous |
| Duration | 5 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Engine | Running |
| NSW switch | OFF |
| Output shaft rpm | 1,000 rpm or more |
TYPICAL ENABLING CONDITIONS
| Sensor signal rpm | Less than 300 rpm |
TYPICAL MALFUNCTION THRESHOLDS
| Counter gear speed sensor (NC) | [HINT] 4th (O/D) when shift lever position is D position (After warming up the engine); Intermediate shaft speed (NC) becomes close to the engine speed. |
COMPONENT OPERATING RANGE
Scheme 179
| Related DTCs | P0982: Shift solenoid valve S4/Range check (Low resistance) P0983: Shift solenoid valve S4/Range check (High resistance) |
|---|---|
| Required sensors/Components | Shift solenoid valve S4 |
| Frequency of operation | Continuous |
| Duration | 0.064 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
P0982: RANGE CHECK (LOW RESISTANCE)
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve S4 | ON |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS P0982 RANGE CHECK (LOW RESISTANCE)
P0983: RANGE CHECK (HIGH RESISTANCE)
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve S4 | OFF |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS P0983 RANGE CHECK (HIGH RESISTANCE)
P0982: RANGE CHECK (LOW RESISTANCE)
| Shift solenoid valve S4 resistance | 8 ohm or less |
TYPICAL MALFUNCTION THRESHOLDS P0982 RANGE CHECK (LOW RESISTANCE)
P0983: RANGE CHECK (HIGH RESISTANCE)
| Shift solenoid valve S4 resistance | 100 kohm or more |
TYPICAL MALFUNCTION THRESHOLDS P0983 RANGE CHECK (HIGH RESISTANCE)
| Shift solenoid valve S4 | Resistance: 11 to 15 ohm at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 180
Scheme 181
Scheme 182
Scheme 183
- INSPECT TRANSMISSION WIRE (S4) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table shown in «TRANSMISSION WIRE (S4) SPECIFIED CONDITIONS»(ref-224756-S10682568022006031100000) . STANDARD: TRANSMISSION WIRE (S4) SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) 8 - Body ground 11 to 15 ohm NG: Go to step 3 OK: Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transaxle. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table shown in «TRANSMISSION WIRE - ECM SPECIFIED CONDITIONS»(ref-224756-S35364704232006031100000) . STANDARD: TRANSMISSION WIRE - ECM SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) E7 - 11 (S4) - Body ground 11 to 15 ohm NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-224750-S28128780772006031100000) ) OK: REPLACE ECM (SEE «REPLACEMENT»(ref-224765-S19142744612006031100000) )
- INSPECT SHIFT SOLENOID VALVE (S4) Remove the shift solenoid valve S4. Measure the resistance according to the value(s) in the table shown in «SHIFT SOLENOID VALVE S4 SPECIFIED CONDITIONS»(ref-224756-S25181303732006031100000) . STANDARD: SHIFT SOLENOID VALVE S4 SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S4) - Solenoid Body (S4) 11 to 15 ohm Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK: The solenoid makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE (S4) OK: REPAIR OR REPLACE TRANSMISSION WIRE (SEE «TRANSMISSION WIRE (ATM)»(ref-224780-S14904518342006031100000) )
| Related DTCs | P2716: Shift solenoid valve SLT/Range check |
|---|---|
| Required sensors/Components | Shift solenoid valve SLT |
| Frequency of operation | Continuous |
| Duration | 1 sec. |
| MIL operation | Immediate |
| Sequence of operation | None |
MONITOR STRATEGY
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Battery voltage | 11 V or more |
| Solenoid current cut status | Not cut |
| CPU commanded duty ratio to SLT | 19% or more |
| Starter | OFF |
| Ignition switch | ON |
TYPICAL ENABLING CONDITIONS
| Solenoid status from IC | Fail (Open or short) |
TYPICAL MALFUNCTION THRESHOLDS
| Shift solenoid valve SLT | Resistance: 5.0 to 5.6 ohm at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 184
Scheme 185
Scheme 186
Scheme 187
Scheme 188
Scheme 189
- INSPECT TRANSMISSION WIRE (SLT) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table shown in «TRANSMISSION WIRE (SLT) SPECIFIED CONDITIONS»(ref-224756-S30628198692006031100000). STANDARD: TRANSMISSION WIRE (SLT) SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) 2 (SLT+) - 7 (SLT-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in the table (Scheme 185) Standard (Check for short): NG: Go to step 3 OK: Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transaxle. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table shown in «TRANSMISSION WIRE - ECM SPECIFIED CONDITIONS»(ref-224756-S21506494692006031100000). STANDARD: TRANSMISSION WIRE - ECM SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) E7 - 13 (SLT+) - E7 - 12 (SLT-) 5.0 to 5.6 ohm Measure the resistance according to the value(s) in the table (Scheme 187) Standard (Check for short): NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-224750-S28128780772006031100000) ) OK: REPLACE ECM (SEE «REPLACEMENT»(ref-224765-S19142744612006031100000) )
- INSPECT SHIFT SOLENOID VALVE (SLT) Remove the shift solenoid valve (SLT). Measure the resistance according to the value(s) in the table shown in «SHIFT SOLENOID VALVE (SLT) SPECIFIED CONDITIONS»(ref-224756-S36231740232006031100000). STANDARD: SHIFT SOLENOID VALVE (SLT) SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohm Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK: The solenoid makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE (SLT) OK: REPAIR OR REPLACE TRANSMISSION WIRE (SEE «TRANSMISSION WIRE (ATM)»(ref-224780-S14904518342006031100000) )
| Related DTCs | P2769: Shift solenoid valve DSL/Range check (Low resistance) P2770: Shift solenoid valve DSL/Range check (High resistance) |
|---|---|
| Required sensors/Components | Shift solenoid valve DSL |
| Frequency of operation | Continuous |
| Duration | 0.064 sec. |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
P2769: RANGE CHECK (LOW RESISTANCE)
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve DSL | ON |
| Solenoid current cut status | Not cut |
| Battery voltage | 8 V or more |
| Starter | OFF |
| Ignition switch | ON |
TYPICAL ENABLING CONDITIONS P2769: RANGE CHECK (LOW RESISTANCE)
P2770: RANGE CHECK (HIGH RESISTANCE)
| The monitor will run whenever this DTC is not present. | SEE LIST OF DISABLE A MONITOR |
|---|---|
| Shift solenoid valve DSL | ON |
| Battery voltage | 8 V or more |
| Starter | OFF |
| Ignition switch | ON |
TYPICAL ENABLING CONDITIONS P2770: RANGE CHECK (HIGH RESISTANCE)
P2769: RANGE CHECK (LOW RESISTANCE)
| Shift solenoid valve DSL resistance | 8 ohm or less |
TYPICAL MALFUNCTION THRESHOLDS P2769 RANGE CHECK (LOW RESISTANCE)
P2770: RANGE CHECK (HIGH RESISTANCE)
| Shift solenoid valve DSL resistance | 100 kohm or more |
TYPICAL MALFUNCTION THRESHOLDS P2770 RANGE CHECK (HIGH RESISTANCE)
| Shift solenoid valve DSL | Resistance: 11 to 13 ohm at 20°C (68°F) |
COMPONENT OPERATING RANGE
Scheme 190
Scheme 191
Scheme 192
Scheme 193
- INSPECT TRANSMISSION WIRE (DSL) Disconnect the transmission wire connector from the transaxle. Measure the resistance according to the value(s) in the table shown in «TRANSMISSION WIRE (DSL) SPECIFIED CONDITIONS»(ref-224756-S30417915722006031100000) . STANDARD: TRANSMISSION WIRE (DSL) SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) 3 - Body ground 11 to 13 ohm NG: Go to step 3 OK: Go to next step.
- CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table shown in «TRANSMISSION WIRE - ECM SPECIFIED CONDITIONS»(ref-224756-S42796150252006031100000) . STANDARD: TRANSMISSION WIRE - ECM SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) E7 - 9 (DSL) - Body ground 11 to 13 ohm NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (SEE «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-224750-S28128780772006031100000) ) OK: REPLACE ECM (SEE «REPLACEMENT»(ref-224765-S19142744612006031100000) )
- INSPECT SHIFT SOLENOID VALVE (DSL) Remove the shift solenoid valve DSL. Measure the resistance according to the value(s) in «SHIFT SOLENOID VALVE (DSL) SPECIFIED CONDITIONS»(ref-224756-S29626460422006031100000) . STANDARD: SHIFT SOLENOID VALVE (DSL) SPECIFIED CONDITIONS Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (DSL) - Solenoid Body (DSL) 11 to 13 ohm Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK: The solenoid valve makes an operating noise. NG: REPLACE SHIFT SOLENOID VALVE (DSL) OK: REPAIR OR REPLACE TRANSMISSION WIRE (SEE «TRANSMISSION WIRE (ATM)»(ref-224780-S14904518342006031100000) )
