Navigation — Navigation circuit Scion iA I

Components on these wiring diagrams 36

Click a component to highlight it on every diagram it appears on.

• * If Equipped
• Antenna
• Audio 2 Fuse
• Clearance Warning ECU Assembly
• Combination Meter Assembly
• Disc Player
• GPS Antenna
• Hung-Up
• Information
• Interior Fuse
• Left Front Speaker Assembly 1
• Left Front Speaker Assembly 2
• Left Rear Speaker Assembly
• Main Body ECU 2
• Meter 1 Fuse
• Microcomputer
• Mirror Fuse
• Multi-Display
• Navigation Antenna Assembly
• Navigation Receiver
• Pick-Up
• Rear Television Camera Assembly
• Relay & Fuse Block3
• Remote Operation Controller Assembly
• Right End Of Dash2
• Right Front Speaker Assembly 1
• Right Front Speaker Assembly 2
• Right Rear Speaker Assembly
• Shield2
• Spiral Cable Sub-Assembly
• Steering Pad Switch Assembly
• Stereo Component Amplifier Assembly
• Stereo Jack Adapter Assembly 1
• Telephone Microphone Assembly
• Volume
• Warning/ Indicator Lights
