Power Mirror Control (Inspection): Overview Scion FR-S I

Scheme 13

Scheme 14

Scheme 15

OPERATION CHECK [07/2013 - ]

1. CHECK OUTER MIRROR SWITCH OPERATION Turn the ignition switch to ACC. With the mirror master switch set to L, check that the mirror surface moves up, down, left and right normally. With the mirror master switch set to R, check that the mirror surface moves up, down, left and right normally.
2. CHECK MIRROR HEATER Turn the ignition switch to ON. Check that pressing the mirror heater switch illuminates the indicator and warms the mirror surface. Check that after approximately 15 minutes, the indicator light turns off and the mirror heater deactivates.

See also:
• INSPECTION [07/2013 - ]
