Charging System (Diagnostic Codes): Overview Scion FR-S I

Charging System 4 illustrations ~723 words

Scheme 8

Scheme 8: ON-VEHICLE INSPECTION [07/2013 - ]

Scheme 9

Scheme 9
  1. CHECK BATTERY CONDITION NOTE: If the battery is weak or if the engine is difficult to start, perform the following procedures. Check the battery for damage and deformation. If severe damage, deformation or leakage is found, replace the battery. Check the volume of electrolyte quantity in each cell. If the electrolyte volume is below the lower line, add distilled water to each cell. Then, recharge the battery and check the electrolyte specific gravity. Standard specific gravity 1.25 to 1.29 at 20°C (68°F) If the electrolyte volume is above the lower line, check the battery voltage when cranking the engine. If the battery voltage is less than 9.6 V, recharge or replace the battery. HINT: Before checking the battery voltage, turn off all the electrical systems (headlights, blower motor, rear defogger, etc.).
  2. INSPECT BATTERY TERMINAL AND FUSE Check that the battery terminals are not loose or corroded. If the terminal is corroded, clean the terminal. Battery positive (+) terminal Torque: 6 N*m (61 kgf*cm, 53 in.*lbf) Battery negative (-) terminal Torque: 6 N*m (61 kgf*cm, 53 in.*lbf) Measure the resistance of the H-fuses and fuses. Standard resistance Below 1 ohms If the result is not as specified, replace the fuse.
  3. INSPECT FAN AND GENERATOR V BELT . Refer to «ON-VEHICLE INSPECTION [07/2013 - ] - Step 1»(/scion/fr-s/i-2012-2016/remont/mechanical/#engine-mechanical-service-information)
  4. INSPECT GENERATOR WIRING Visually check the generator wiring. Check that the wiring is in good condition.
  5. CHECK FOR ABNORMAL NOISES Listen for abnormal noises from the generator. Check that no abnormal noises are heard from the generator while the engine is running.
  6. INSPECT CHARGE WARNING LIGHT CIRCUIT Turn the ignition switch to ON. Check that the charge warning light comes on. Start the engine and check that the light goes off. If the light does not operate as specified, troubleshoot the charge warning light circuit.
  7. INSPECT CHARGING CIRCUIT WITHOUT LOAD Connect a voltmeter and ammeter to the charging circuit as follows. Disconnect the wire from terminal B of the generator, and then connect it to the negative (-) lead of an ammeter. TEXT IN ILLUSTRATION *1 Battery *2 Terminal B *3 Generator Assembly Connect the positive (+) lead of the ammeter to terminal B of the generator. Connect the positive (+) lead of a voltmeter to terminal B of the generator. Ground the negative (-) lead of the voltmeter. Check the charging circuit. Maintain the engine speed at 2000 rpm and check the reading on the ammeter and voltmeter. Standard current 20 A or less Standard voltage 11.3 to 15.6 V If the result is not as specified, replace the generator assembly. HINT: If the battery is not fully charged, the ammeter reading will sometimes be higher than the standard current.
  8. INSPECT CHARGING CIRCUIT WITH LOAD With the engine running at 2000 rpm, turn the high beam headlights on and turn the heater blower switch to the HI position. Check the reading on the ammeter. Standard current 30 A or higher If the ammeter reading is below the standard current, repair the generator. HINT: If the battery is fully charged, the indication will sometimes be below the standard current. If this is the case, add more electrical load (operate the wipers, rear window defogger, etc.) and check the reading on the ammeter again.

Scheme 10

Scheme 10: DESCRIPTION

The battery temperature sensor installed on the battery current sensor assembly detects the battery temperature.

A thermistor is integrated into the battery temperature sensor, and the resistance in the battery temperature sensor changes according to the battery temperature.

The resistance of the thermistor in the battery temperature sensor decreases as the battery temperature increases. The resistance increases as the temperature decreases.

The battery temperature sensor is connected to the ECM. The ECM supplies 5 V from the THB terminal to the battery temperature sensor through resistor R.

The battery temperature sensor and resistor R are connected in series. This results in fluctuations in the voltage supplied from the THB terminal when the resistance changes according to the battery temperature.

The ECM determines the battery temperature according to fluctuations in voltage. When the battery temperature is high, the ECM determines to reduce the amount of current supplied from the generator in order to protect the battery.

DTC No.DTC Detection ConditionTrouble Area
P0516Engine speed is 500 r/min or more, battery voltage is 10.9 V or more, and 1 second or more have elapsed after starting. Battery temperature sensor output is less than 0.104 V, and duration of the malfunction is 0.5 seconds or more (1-trip detection logic).Battery current sensor assembly (battery temperature sensor) Short to GND in battery temperature sensor circuit ECM
P0517Engine speed is 500 r/min or more, battery voltage is 10.9 V or more, and 1 second or more have elapsed after starting. Battery temperature sensor output is more than 4.867 V, and duration of the malfunction is 0.5 seconds or more (1-trip detection logic).Battery current sensor assembly (battery temperature sensor) Open in battery temperature sensor circuit ECM

Scheme 11

Scheme 11: WIRING DIAGRAM
