Lighting System: Specifications Saturn VUE II

Exterior Lights 20 illustrations ~135 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
CHMSL to Lift Gate Screws1 N.m9 lb in
Fog Lamp to Fascia Screws4 N.m35 lb in
Headlamp Bracket Bolts10 N.m89 lb in
License Plate Bezel to Lift Gate Nuts4 N.m35 lb in
License Plate Bulb Assembly Screws4 N.m35 lb in
Tail Lamp Screws2.5 N.m22 lb in

Fastener Tightening Specifications

Lighting Systems Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR DISABLING AND ENABLING. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs

Scheme 1

Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics

Scheme 2

Scheme 2

Scheme 3

Scheme 3: Fog Lights Schematics

Scheme 4

Scheme 4: Exterior Lights Schematics

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9: Interior Lights Schematics

Scheme 10

Scheme 10

Scheme 11

Scheme 11: Interior Lights Dimming Schematics

Scheme 12

Scheme 12: Lighting Systems Component Views
CalloutComponent Name
1Fog Lamp-Right (T96)
2Park/Turn Signal Lamp-RF
3Headlamp-Right-High Beam
4Headlamp-Right-Low Beam
5Headlamp-Left-Low Beam
6Headlamp-Left-High Beam
7Park/Turn Signal Lamp-RF
8Fog Lamp-Left (T96)

Scheme 13

Scheme 13
CalloutComponent Name
1Ambient Air Temperature Sensor (DH3)
2Cooling Fan
3Daytime Running Lamps (DRL) Resistor
4G101
5SP101

Scheme 14

Scheme 14
CalloutComponent Name
1Vehicle Speed Sensor (VSS) (3 BK)
2Engine Wiring Harness
3Backup Switch (2 BK)

Scheme 15

Scheme 15
CalloutComponent Name
1Instrument Panel Cluster (IPC)
2Windshield Wiper/Washer Switch
3I/P Dimmer Control
4Hazard Switch
5Inflatable Restraint Front Passenger Presence System (PPS) Indicator
6Fog Lamp (T96) or Traction Control Switch (NW9)
7Ambient Light Sensor
8Inflatable Restraint I/P Module
9HVAC Control Module
10Cigar Lighter (DT4)
11Window Switch - Passenger
12Heated Seat Switches
13Window Switch - Driver
14Outside Rearview Mirror Switch (D22/DG7)
15Radio
16Steering Wheel Control Switch - Right (Radio)
17Inflatable Restraint Steering Wheel Module
18Steering Wheel Control Switch - Left (Cruise Control)
19Turn Signal/Multifunction Switch

Scheme 16

Scheme 16
CalloutComponent Name
1Cruise Release Switch
2Stop Lamp Switch
3Accelerator Pedal Position (APP) Sensor
4Clutch Start Switch (M/T)

Scheme 17

Scheme 17
CalloutComponent Name
1Turn Signal/Multifunction Switch
2Instrument Panel Cluster (IPC)
3Dimmer Switch
4Sunshade
5Dome Lamps, Front and Rear
6Liftgate Lamps, Left and Right
7PRNDL Lamp
8Cigar Lighter
9Radio

Scheme 18

Scheme 18
CalloutComponent Name
1Center High Mounted Stop Lamp (CHMSL)
2Park/Stop Lamp-RR
3Park/Turn Signal Lamp-RR
4Backup Lamp-Right
5License Lamps
6Backup Lamp-Left
7Park/Turn Signal Lamp-LR
8Park/Stop Lamp-LR

Scheme 19

Scheme 19: Ambient Light Sensor
Connector Part Information OEM: 12047662 Service: See Catalog Description: 2-Way F Metri-Pack 150 Series (BK)

Ambient Light Sensor Connector Parts Information

PinWire ColorCircuit No.Function
AL-GN/BK1137DRL/Ambient Light Sensor Signal
BYE/BK1138Low Reference

Ambient Light Sensor Connector Terminal Identification

Scheme 20

Scheme 20: Backup Lamp - Left
Connector Part Information OEM: 021940259 Service: See Catalog Description: 3-Way F Bulb 3057 Socket (GY)

Backup Lamp - Left Connector Parts Information

PinWire ColorCircuit No.Function
MAJL-GN24Backup Lamp Supply Voltage
MINNot Used
GNDBK750Ground

Backup Lamp - Left Connector Terminal Identification
