Engine Cooling System: Specifications — Saturn VUE II (2007-2009)

Engine Cooling System: Specifications Saturn VUE II

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Coolant Heater Bolt (LAT/L61)	10 N.m	89 lb in
Coolant Heater Bolt (L66)	60 N.m	44 lb ft
Condenser Radiator Fan Module (CRFM) Bracket Bolt	8 N.m	71 lb in
Crossover Pipe Bolts (L66)	22 N.m	16 lb ft
Engine Coolant Temperature (ECT) Sensor (LAT/L61)	20 N.m	15 lb ft
Engine Coolant Temperature (ECT) Sensor (L66)	18 N.m	13 lb ft
Exhaust Heat Shield Bolts (LAT/L61)	22 N.m	16 lb ft
Fan Assembly to Radiator Bolt	8 N.m	71 lb in
Fan Assembly Screw	8 N.m	71 lb in
Negative Battery Terminal Bolt	17 N.m	13 lb ft
Surge Tank Bolt	8 N.m	71 lb in
Thermostat Housing Bolt (L66)	12 N.m	106 lb in
Thermostat Housing Cover Bolt (LAT/L61)	10 N.m	89 lb in
Thermostat Housing Bolt (LAT/L61)	10 N.m	89 lb in
Thermostat Pipe Bracket-to-Cylinder Head Bolt (L61)	8 N.m	71 lb in
Transaxle Oil Cooler Line Fitting	16 N.m	12 lb ft
Water Pump Access Cover Bolt (LAT/L61)	10 N.m	89 lb in
Water Pump Bolt (LAT/L61)	10 N.m	89 lb in
Water Pump Bolt (L66)	12 N.m	106 lb in
Water Pump Sprocket Bolt (LAT/L61)	10 N.m	89 lb in
Wheel Nut	125 N.m	92 lb ft
Wiring Harness Ground Terminal Nut (L66)	12 N.m	106 lb in
