Power Outlets: Overview Saturn VUE II

Body Electrical 3 illustrations

Scheme 65

Scheme 65: Cigar Lighter/Power Outlet Schematics
Scheme 65: Cigar Lighter/Power Outlet Schematics

Scheme 66

Scheme 66: Power Outlet Component Views
Scheme 66: Power Outlet Component Views
CalloutComponent Name
1Cigar Lighter
2Auxiliary Power Outlet 1
3Auxiliary Power Outlet 2

Scheme 67

Scheme 67: Auxiliary Power Outlet 1
Scheme 67: Auxiliary Power Outlet 1
Connector Part Information OEM: 12176836 Service: See Catalog Description: 3-Way F Metri-Pack 280 Series (GY)

Auxiliary Power Outlet 1 Connector Parts Information

PinWire ColorCircuit NumberFunction
AOG340Battery Positive Voltage
BNot Used
CBK550Ground

Auxiliary Power Outlet 1 Connector Terminal Identification
