Seat System: Specifications Saturn VUE I

Seats 5 illustrations ~571 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Front Bucket Seat Adjuster Bolt50 N.m37 lb ft
Front Bucket Seat Armrest Screw30 N.m22 lb ft
Front Bucket Seat Back Frame Bolts - Fold Flat70 N.m52 lb ft
Front Bucket Seat Back Frame Nut - Non Fold Flat17 N.m13 lb ft
Front Bucket Seat Back Panel Screws - Fold Flat2 N.m18 lb in
Front Bucket Seat Cushion Frame Bolt12 N.m9 lb ft
Front Bucket Seat Inboard Recliner Trim Panel Screw2.5 N.m22 lb in
Front Bucket Seat Lumbar Actuator Screw2 N.m18 lb in
Front Bucket Seat Outboard Recliner Trim Panel Screw2.5 N.m22 lb in
Front Bucket Seat Recliner Handle Bolt - Non Fold Flat10 N.m89 lb in
Front Bucket Seat Teardrop Washer Bolt - Non Fold Flat35 N.m26 lb ft
Front Seat Back Recliner Trim Panel Screw2.5 N.m22 lb in
Front Seat Belt Buckle Bolt45 N.m33 lb ft
Front Seat Belt Quick Disconnect Bolt45 N.m33 lb ft
Front Seat Cushion Inner Trim Panel Screw2.5 N.m22 lb in
Front Seat Cushion Outer Trim Panel Screw2.5 N.m22 lb in
Front Seat Recliner Bolt - Fold Flat45 N.m33 lb ft
Seat Back Panel - Front2 N.m18 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Driver Seat Schematics
Scheme 1: Driver Seat Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: Passenger Seat Schematics
Scheme 3: Passenger Seat Schematics

Scheme 4

Scheme 4: Power Seat Systems Component Views
Scheme 4: Power Seat Systems Component Views
CalloutComponent Name
1Not Used - Early Production
2Seat - Driver
3C305 - To the Driver Power/Heated Seat (w/ AG1,KA1)
4Seat - Front Passenger
5C306 - To the Front Passenger Heated Seat (w/ KA1)
6Driver Heated Seat Switch (w/ KA1) (Mounted Near the Shifter Assembly)
7Front Passenger Heated Seat Switch (w/ KA1) (Mounted Near the Shifter Assembly)

Heated Seat Switch - Driver Connector End (w/KA1) Connector Part Information 12177194 6-Way F Metri-Pack 150 Series (NA) Pin Wire Color Circuit Number Function A PK 1501 Driver Heated Seat High/Low Signal B GY 8 Instrument Panel Lamps Dimmer Switch Signal C - - Not Used D BN 141 Ignition 1 Voltage E BK 650 Ground F L-BU 1462 Driver Heated Seat Switch Signal

Heated Seat Switch - Front Passenger Connector End (w/KA1) Connector Part Information 12177195 6-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit Number Function A PK/BK 1503 Front Passenger Heated Seat High/Low Signal B GY 8 Instrument Panel Lamps Dimmer Switch Signal C - - Not Used D BN 141 Ignition 1 Voltage E BK 650 Ground F L-BU/BK 1505 Front Passenger Heated Seat Switch Signal

Heated Seat Module - Driver C1 Connector End (w/KA1) Connector Part Information 7283-5629-40 4-Way F (GY) Pin Wire Color Circuit Number Function 1 BK 650 Ground 2 PK 1501 Driver Heated Seat High/Low Signal 3 L-BU 1462 Driver Heated Seat Switch Signal 4 OG 1540 Battery Positive Voltage

Scheme 5

Scheme 5: Power Seat Systems Connector End Views
Scheme 5: Power Seat Systems Connector End Views

Heated Seat Module - Driver C2 (Heated Seat Cushion Pigtail) Connector End (w/KA1) Connector Part Information 7283-5630-60 4-Way F (GN) Pin Wire Color Circuit Number Function 1 RD - H1 Signal 2 GY - Low Reference 3 GY - Temperature Sensor Signal 4 BK - H2 Signal

Heated Seat Module - Driver C3 (Heated Seat Back Pigtail) Connector End (w/KA1) Connector Part Information 7283-5579-40 2-Way F (GY) Pin Wire Color Circuit Number Function 1 BK - H2 Control 2 BK - H2 Signal

Heated Seat Module - Front Passenger C1 Connector End (w/KA1) Connector Part Information 7283-5629-40 4-Way F (GY) Pin Wire Color Circuit Number Function 1 BK 650 Ground 2 PK/BK 1503 Front Passenger Heated Seat High/Low Signal 3 L-BU/BK 1505 Front Passenger Heated Seat Switch Signal 4 OG 1540 Battery Positive Voltage

Heated Seat Module - Front Passenger C2 (Heated Seat Cushion Pigtail) Connector End (w/KA1) Connector Part Information 7283-5630-60 4-Way F (GN) Pin Wire Color Circuit Number Function 1 RD - H1 Signal 2 GY - Low Reference 3 GY - Temperature Sensor Signal 4 BK - H2 Signal

Heated Seat Module - Front Passenger C3 (Heated Seat Back Pigtail) Connector End (w/KA1) Connector Part Information 7283-5579-40 2-Way F (GY) Pin Wire Color Circuit Number Function 1 BK - H2 Control 2 BK - H2 Signal

Seat Adjuster Switch - Driver Connector End (w/AG1) Connector Part Information 15326924 8-Way F GT 280 Series (BK) Pin Wire Color Circuit Number Function A D-GN 286 Seat Front Vertical Down Control B BK 650 Ground C RD 285 Seat Horizontal Forward Control D OG 1240 Battery Positive Voltage E YE 282 Seat Rear Vertical Up Control F BK 284 Seat Horizontal Rearward Control G L-BU 283 Seat Rear Vertical Down Control H D-BU 287 Seat Front Vertical Down Control

Seat Recline Motor - Driver Connector End (w/AG1) Connector Part Information 811860 2-Way F (BK) Pin Wire Color Circuit Number Function 1 L-BU 283 Seat Rear Vertical Down Control 2 YE 282 Seat Rear Vertical Up Control

Seat Vertical Motor - Driver Connector End (w/AG1) Connector Part Information 811860 2-Way F (BK) Pin Wire Color Circuit Number Function 1 D-BU 287 Seat Front Vertical Down Control 2 D-GN 286 Seat Front Vertical Down Control
