Lighting Systems: Specifications Saturn VUE I

Exterior Lights 11 illustrations ~1418 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
CHMSL to Lift Gate Screws1 N.m9 lb in
Fog Lamp to Fascia Screws4 N.m35 lb in
Headlamp Bracket Bolts10 N.m89 lb in
License Plate Bezel to Lift Gate Nuts4 N.m35 lb in
License Plate Bulb Assembly Screws4 N.m35 lb in
Tail Lamp Screws2.5 N.m22 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics (w/T82)
Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics (w/T82)

Scheme 2

Scheme 2: Headlights/Daytime Running Lights (DRL) Schematics (w/o T82)
Scheme 2: Headlights/Daytime Running Lights (DRL) Schematics (w/o T82)

Scheme 3

Scheme 3: Fog Lights Schematics
Scheme 3: Fog Lights Schematics

Scheme 4

Scheme 4: Exterior Lights Schematics
Scheme 4: Exterior Lights Schematics

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9: Interior Lights Schematics
Scheme 9: Interior Lights Schematics

Scheme 10

Scheme 10: Interior Lights Dimming Schematics
Scheme 10: Interior Lights Dimming Schematics

Scheme 11

Scheme 11: Lighting Systems Component Views
Scheme 11: Lighting Systems Component Views
CalloutComponent Name
1Headlamp Switch
2Instrument Panel Cluster (IPC)
3Dimmer Switch
4Sunshade Lamps (Not Used)
5Dome Lamps, Front and Rear
6Liftgate Lamps, Left and Right
7PRNDL Lamp
8Cigar Lighter
9Radio

Backup Lamp - Left Lighting Systems Connector End Connector Part Information 021940259 3-Way F Bulb 3057 Socket (BK) Pin Wire Color Circuit No. Function MAJ L-GN 24 Backup Lamp Supply Voltage MIN - - Not Used GND BK 750 Ground

Backup Lamp - Right Lighting Systems Connector End Connector Part Information 021940259 3-Way F Bulb 3057 Socket (BK) Pin Wire Color Circuit No. Function MAJ L-GN 24 Backup Lamp Supply Voltage MIN - - Not Used GND BK 850 Ground

Backup Switch (L61 w/M/T) Connector End Connector Part Information 12052641 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A PK 239 Ignition 1 Voltage B L-GN 24 Backup Lamp Supply Voltage

Center High Mount Stop Lamp (CHMSL) Connector End Connector Part Information 7283-5530-40 2-Way F (L-GY) Pin Wire Color Circuit No. Function 1 L-BU 20 Stop Lamp Switch Signal 2 BK 650 Ground

Courtesy/Map Lamp Connector End Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A OG 1732 Courtesy Lamps Supply Voltage B BK 750 Ground

Cruise/Brake Switch Connector End Connector Part Information 12041433 2-Way F Metri-Pack 280 Series (BK) Pin Wire Color Circuit No. Function A PK 1339 Ignition 1 Voltage B PU 420 Cruise Control Release Signal

Daytime Running Lamps (DRL) Resistor Connector End Connector Part Information 15300027 2-Way F Metri-Pack 280 Sealed (BK) Pin Wire Color Circuit No. Function A GY 589 DRL Relay B BK 150 Ground

Dimmer Switch (Dash Illumination) Connector End Connector Part Information 12020299 5-Way F P/C Edgeboard - Standard (NA) Pin Wire Color Circuit No. Function A - - Not Used B BN/WH 230 I/P Lamps Dimmer Control C TN 470 Low Reference D-E - - Not Used

Dome Lamp - Front Connector End Connector Part Information 12045813 4-Way F Metri-Pack 150 Series (NA) Pin Wire Color Circuit No. Function A WH 156 Courtesy Lamps Switch Signal B GY 157 Courtesy Lamp Control C BK 750 Ground D OG 1732 Courtesy Lamps Supply Voltage

Dome Lamp - Rear Connector End Connector Part Information 12045813 4-Way F Metri-Pack 150 Series (NA) Pin Wire Color Circuit No. Function A - - Not Used B GY 157 Courtesy Lamp Control C - - Not Used D OG 1732 Courtesy Lamps Supply Voltage

Fog Lamps Connector End Connector Part Information 12020599 2-Way F Metri-Pack 280 Series (BK) Pin Wire Color Circuit No. Function A PU 34 Fog Lamp Relay B BK 150 Ground

Fog Lamp Switch Connector End Connector Part Information 12065872 7-Way F Micro-Pack 100 Series (GY) Pin Wire Color Circuit No. Function 1 YE 317 Fog Lamp Relay Coil Supply Voltage 2 OG 192 Front Fog Lamp Switch Signal 3 PK 139 Ignition 1 Voltage 4 - - Not Used 5 BK 550 Ground 6 GY 8 Instrument Panel Lamp Supply Voltage 7 - - Not Used

Hazard Switch Connector End Connector Part Information 12064769 10-Way Metri-Pack 150 Series (NA) Pin Wire Color Circuit No. Function A BK/WH 151 Ground B OG 1040 Battery Positive Voltage C YE 243 Accessory Voltage D - - Not Used E GY 8 Instrument Panel Lamp Supply Voltage F L-BU 14 Left Turn Signal Lamps Supply Voltage G D-BU 15 Right Turn Signal Lamps Supply Voltage H PU 16 Turn Signal Flasher Signal J-K - - Not Used

Headlamp - Left - High Beam Connector End Connector Part Information 12059183 2-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A OG 740 Battery Positive Voltage B PK 1200 Headlamp High Beam Signal

Headlamp - Left - Low Beam Connector End Connector Part Information 12059181 2-Way F Metri-Pack 280 Series Sealed (M-GY) Pin Wire Color Circuit No. Function A OG 740 Battery Positive Voltage B D-BU 1201 Headlamp Low Beam Signal

Headlamp - Right - High Beam Connector End Connector Part Information 12059183 2-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A OG 640 Battery Positive Voltage B PK 1200 Headlamp High Beam Signal

Headlamp - Right - Low Beam Connector End Connector Part Information 12059181 2-Way F Metri-Pack 280 Series Sealed (M-GY) Pin Wire Color Circuit No. Function A OG 640 Battery Positive Voltage B D-BU 1201 Headlamp Low Beam Signal

Headlamp Switch Connector End Connector Part Information 12047976/929504-3 8-Way F Metri-Pack 280 Series (BK) Pin Wire Color Circuit No. Function 1 BK 550 Ground 2 L-BU 14 Left Turn Signal Lamps Supply Voltage 3 OG 240 Battery Positive Voltage 4 PU 16 Turn Signal Flasher Signal 5 D BU 1201 Headlamp Low Beam Signal 6 D-BU 15 Right Turn Signal Lamps Supply Voltage 7 PK 1200 Headlamp High Beam Signal 8 BN 9 Park Lamp Supply Voltage

License Lamp - Left Connector End Connector Part Information 12020599 2-Way F 280 Series (BK) Pin Wire Color Circuit No. Function A BK 650 Ground BK 650 Ground B WH 9 Park Lamp Supply Voltage WH 9 Park Lamp Supply Voltage

License Lamp - Right Connector End Connector Part Information 12020599 2-Way F 280 Series (BK) Pin Wire Color Circuit No. Function A BK 650 Ground B WH 9 Park Lamp Supply Voltage

Liftgate Lamp - Left Connector End Connector Part Information 12186713 2-Way F (BK) Indexing may vary Pin Wire Color Circuit No. Function 1 OG 1732 Courtesy Lamps Supply Voltage 2 GY 157 Courtesy Lamp Control

Liftgate Lamp - Right Connector End Connector Part Information 12186713 2-Way F (BK) Indexing may vary Pin Wire Color Circuit No. Function 1 OG 1732 Courtesy Lamps Supply Voltage 2 GY 157 Courtesy Lamp Control

Marker Lamp - LF Connector End Connector Part Information 12110053 2-Way F Lamp Socket Wedge Base W2 (L-GY) Pin Wire Color Circuit No. Function A BN 9 Park Lamp Supply Voltage B BK 150 Ground

Marker Lamp - RF Connector End Connector Part Information 12110053 2-Way F Lamp Socket Wedge Base W2 (L-GY) Pin Wire Color Circuit No. Function A BN 9 Park Lamp Supply Voltage B BK 150 Ground

Park/Stop Lamp - LR Connector End Connector Part Information 021940459 3-Way F Bulb 3057 Socket (BK) Pin Wire Color Circuit No. Function MAJ L-BU 20 Stop Lamp Switch Signal MIN BN 9 Park Lamp Supply Voltage GND BK 750 Ground

Park/Stop Lamp - RR Connector End Connector Part Information 021940459 3-Way F Bulb 3057 Socket (BK) Pin Wire Color Circuit No. Function MAJ L-BU 20 Stop Lamp Switch Signal MIN BN 9 Park Lamp Supply Voltage GND BK 850 Ground

Park/Turn Signal Lamp - LF Connector End Connector Part Information ZF1-00561-UA 3-Way F (BK) Pin Wire Color Circuit No. Function 1 BK 150 Ground 2 BN 9 Park Lamp Supply Voltage 3 L-BU 14 Left Turn Signal Lamps Supply Voltage

Park/Turn Signal Lamp - LR Connector End Connector Part Information 021780959 3-Way F Bulb 3057 Socket (BK) Pin Wire Color Circuit No. Function MAJ D-BU 18 Left Rear Turn Lamp Supply Voltage MIN BN 9 Park Lamp Supply Voltage GND BK 750 Ground

Park/Turn Signal Lamp - RF Connector End Connector Part Information ZF1-00561-UA 3-Way F (BK) Pin Wire Color Circuit No. Function 1 BK 150 Ground 2 BN 9 Park Lamp Supply Voltage 3 D-BU 15 Right Turn Signal Lamps Supply Voltage

Park/Turn Signal Lamp - RR Connector End Connector Part Information 021780959 3-Way F Bulb 3057 Socket (BK) Pin Wire Color Circuit No. Function MAJ D-BU 19 Right Rear Turn Lamp Supply Voltage MIN BN 9 Park Lamp Supply Voltage GND BK 850 Ground

PRNDL Lamp Connector End Connector Part Information 12033701 Lamp Socket Bulb Base Type W-2 Axial (BK) Pin Wire Color Circuit No. Function A GY 8 I/P Dimmer Lamps Switch Signal B BK 550 Ground

Stop Lamp Switch Connector End Connector Part Information 12033701 2-Way F Metri-Pack 480 Series (GY) Pin Wire Color Circuit No. Function A OG 540 Battery Positive Voltage B L-BU 20 Stop Lamp Switch Signal

Begin the system diagnosis with the Diagnostic System Check - Lighting Systems . The Diagnostic System Check will provide the following information

  1. The identification of the control module(s) which command the system
  2. The ability of the control module(s) to communicate through the serial data circuit
  3. The identification of any stored diagnostic trouble codes (DTCs) and their status

The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.
