Wiring Systems (General Information): Overview Saturn VUE I

Body Electrical 24 illustrations ~113 words

Power and Grounding Schematic Icons

Power and Grounding Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Disabling and Enabling Zones. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs

Scheme 1

Scheme 1: Power Distribution Schematics

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12: Ground Distribution Schematics

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20: Harness Routing Views
CalloutComponent Name
1Marker Lamp - RF (2 GY)
2Park/Turn Signal Lamp - RF (3 GY)
3Headlamp - Right Low Beam (2 BK)
4Headlamp - Right High Beam (2 BK)
5Headlamp - Left High Beam (2 BK)
6Headlamp - Left Low Beam (2 BK)
7Fuse Block - Underhood C1
8C106
9S111
10Park/Turn Signal Lamp - LF (3 GY)
11Marker Lamp - LF (2 GY)
12Windshield Washer Fluid Pump (2 BK)
13Horn (2 GY)
14Cooling Fan Resistor (2 GY)
15Splice Pack SP301, G101
16Daytime Running Lamp (DRL) Resistor (2 BK)
17Fog Lamp - Left (2 BK) (w/T96)
18Cooling Fan (3 TN)
19Ambient Air Temperature Sensor (2 L-GN) (w/HAA)
20Fog Lamp - Right (2 BK) (w/T96)

Scheme 21

Scheme 21
CalloutComponent Name
1Headlamp - Left Low Beam (2 BK)
2Park/Turn Signal Lamp - LF (3 GY)
3Fuse Block - Underhood C1
4C106
5Marker Lamp - LF (2 GY)
6Horn (2 GY)
7Splice Pack SP301, G101
8Daytime Running Lamp (DRL) Resistor (2 BK)
9Fog Lamp - Left (2 BK)
10Cooling Fan Relay 3 (5 BK)
11Cooling Fan - Left (3 TN)
12Headlamp - Left High Beam (2 BK)
13Ambient Air Temperature Sensor (2 L-GN)
14Cooling Fan - Right (3 TN)
15Fog Lamp - Right (2 BK)
16Headlamp - Right High Beam (2 BK)
17Headlamp - Right Low Beam (2 BK)
18Marker Lamp - RF (2 GY)
19Park/Turn Signal Lamp - RF (3 GY)

Scheme 22

Scheme 22
CalloutComponent Name
1Inflatable Restraint Steering Wheel Module Coil C3
2Instrument Panel Cluster (IPC)
3I/P Fuse Block C2,C3
4G203
5C202 - HVAC Harness to the I/P Harness Connector
6S201
7C203 - I/P Harness to the Inflatable Restraint I/P Module Jumper Harness Connector
8S205
9Splice Pack SP201, G201
10C311 - Body Harness to the I/P Harness Connector
11C308 - SDM Harness to the SIS Harness Connector
12C307 - Roof Rail Module Harness to the SDM Harness Connector
13C303 - Headliner Harness to the I/P Harness Connector
14C201 - Auxiliary Outlet Harness to the I/P Harness Connector
15C204 - I/P Harness to the Digital Radio Harness Connector
16S203
17C200 - I/P Harness to the Body Harness Connector
18Data Link Connector (DLC)
19Splice Pack SP203
20Inflatable Restraint Steering Wheel Module Coil C5

Scheme 23

Scheme 23
CalloutComponent Name
1Inside Rearview Mirror (ISRM)
2Courtesy/Map Lamps
3Sunroof Switch
4Cellular Telephone Microphone
5Dome Lamp - Front
6Dome Lamp - Rear
7S302
8S303
9C302 - Sunroof Harness to Headliner Harness Connector
10S301
11C300 - Body Harness to Headliner Harness Connector
12C303 - Headliner Harness to I/P Harness Connector

Scheme 24

Scheme 24
CalloutComponent Name
1Body Harness to the Liftgate Harness Connector C403
2Body Harness to the Liftgate Harness Connector C402
3S402
4S400
5S407
6Liftgate Lamp - Left
7License Lamp Harness to the Liftgate Harness Connector C405
8Liftgate Lock Actuator/Ajar Switch
9Wiper Motor - Rear
10Liftgate Lamp - Right
