Lighting System: Specifications Saturn Sky I

Exterior Lights 20 illustrations ~137 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Back Up Lamp Screws2 N.m18 lb in
DRL Lamp Assembly Screws2 N.m18 lb in
Fog Lamp Screws2 N.m18 lb in
Headlamp Bolts9 N.m80 lb in
License Lamp Screws2 N.m18 lb in
Tail Lamp Screws2.5 N.m22 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics
Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics

Scheme 2

Scheme 2: Fog Lights Schematics
Scheme 2: Fog Lights Schematics

Scheme 3

Scheme 3: Exterior Lights Schematics
Scheme 3: Exterior Lights Schematics

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6: Interior Lights Schematics
Scheme 6: Interior Lights Schematics

Scheme 7

Scheme 7: Interior Lights Dimming Schematics
Scheme 7: Interior Lights Dimming Schematics

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9: Lighting Systems Component Views
Scheme 9: Lighting Systems Component Views
CalloutComponent Name
1Fog Lamp - RF
2Park/Turn Signal Lamp - RF
3Marker Lamp - RF
4Park Lamp - RF
5Headlamp - Low Beam - Right
6Headlamp - High Beam - Right
7Headlamp - High Beam - Left
8Headlamp - Low Beam - Left
9Park Lamp - LF
10Marker Lamp - LF
11Park/Turn Signal Lamp - LF
12Fog Lamp - LF

Scheme 10

Scheme 10
Scheme 10
CalloutComponent Name
1Inflatable Restraint Steering Wheel Module
2Turn Signal/Multifunction Switch C2
3Turn Signal/Multifunction Switch C1
4Inflatable Restraint Steering Wheel Module Coil C3
5Inflatable Restraint Steering Wheel Module Coil C2
6Ignition Switch
7Windshield Wiper/Washer Switch Connector
8Windshield Wiper/Washer Switch

Scheme 11

Scheme 11
Scheme 11
CalloutComponent Name
1Hazard Switch
2Ambient Light Sensor
3Inflatable Restraint Passenger Airbag On/Off Indicator
4Fog Lamp Switch (T96)
5I/P Dimmer Switch
6Traction Control Switch (if equipped)
7HVAC Control Module
8Inflatable Restraint I/P Module
9Rear Compartment Lid Release Switch
10Radio/Navigation Unit (UE1/U2K)
11Park Brake Lever
12Auxiliary Power Outlet
13Steering Wheel - Controls - Right
14Steering Wheel - Controls - Left
15Inflatable Restraint Steering Wheel Module
16Instrument Panel Cluster (IPC)

Scheme 12

Scheme 12
Scheme 12
CalloutComponent Name
1Cellular Microphone (UE1)
2Inside Rearview Mirror
3OnStar Button Assembly (UE1)
4Inside Rearview Mirror Lamps
5Antenna
6Cellular and Navigational Antenna (U2K/UE1)
7Remote Control Door Lock Receiver (RCDLR)
8Vehicle Communication Interface Module (VCIM)

Scheme 13

Scheme 13
Scheme 13
CalloutComponent Name
1Digital Radio Receiver (U2K)
2Rear Compartment Lamp
3Rear Compartment Lid

Scheme 14

Scheme 14
Scheme 14
CalloutComponent Name
1Marker Lamp - LR
2Tail/Stop and Turn Signal Lamp - Left Outer
3Tail/Stop and Turn Signal Lamp - Left Inner
4License Lamp
5Center High Mounted Stop Lamp (CHMSL)
6Tail/Stop and Turn Signal Lamp - Right Inner
7Tail/Stop and Turn Signal Lamp - Right Outer
8Marker Lamp - RR
9Backup Lamp

Scheme 15

Scheme 15: Ambient Light Sensor
Scheme 15: Ambient Light Sensor
Connector Part Information OEM: 12047662 Service: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Pins: Terminal: TBD Core/Insulation Crimp: TBD Release Tool/Test Probe: TBD

Ambient Light Sensor Connector Part Information

PinWire ColorCircuit No.Function
AL-GN/BK1137DRL Ambient Light Sensor Signal
BYE/BK1138DRL Ambient Light Sensor Low Reference

Ambient Light Sensor Connector Terminal Identification

Scheme 16

Scheme 16: Backup Lamp
Scheme 16: Backup Lamp
Connector Part Information OEM: 15435155 Service: No Service Number Found Description: 3-Way F Socket Wedge (NA)
Terminal Part Information Pins: Terminal: TBD Core/Insulation Crimp: TBD Release Tool/Test Probe: TBD

Backup Lamp Connector Part Information

PinWire ColorCircuit No.Function
AL-GN24Backup Lamp Supply Voltage
BNot Used
GBK750Ground

Backup Lamp Connector Terminal Identification

Scheme 17

Scheme 17: Backup Lamp Switch (MA5)
Scheme 17: Backup Lamp Switch (MA5)
Connector Part Information OEM: 12103584 Service: 12085485 Description: 2-Way M Weather Pack (BK)
Terminal Part Information Pins: Terminal: TBD Core/Insulation Crimp: TBD Release Tool/Test Probe: TBD

Backup Lamp Switch (MA5) Connector Part Information

PinWire ColorCircuit No.Function
APK539Ignition 1 Voltage (MA5)
BL-GN24Backup Lamp Supply Voltage (MA5)

Backup Lamp Switch (MA5) Connector Terminal Identification

Scheme 18

Scheme 18: Brake Pedal Position Sensor
Scheme 18: Brake Pedal Position Sensor
Connector Part Information OEM: 15332132 Service: 88953364 Description: 3-Way F GT 150 Series (BK)
Terminal Part Information Pins: Terminal: TBD Core/Insulation Crimp: TBD Release Tool/Test Probe: TBD

Brake Pedal Position Sensor Connector Part Information

PinWire ColorCircuit No.Function
AWH53595-Volt Reference
BYE5361Brake Pedal Position Sensor Signal
CBN5360Low Reference

Brake Pedal Position Sensor Connector Terminal Identification

Scheme 19

Scheme 19: Center High Mounted Stop Lamp (CHMSL)
Scheme 19: Center High Mounted Stop Lamp (CHMSL)
Connector Part Information OEM: 15449029 Service: 88987993 Description: 2-Way F GT 150 Series, Sealed (GY)
Terminal Part Information Pins: Terminal: TBD Core/Insulation Crimp: TBD Release Tool/Test Probe: TBD

Center High Mounted Stop Lamp (CHMSL) Connector Part Information

PinWire ColorCircuit No.Function
AL-BU20Stop Lamp Supply Voltage
BBK750Ground

Center High Mounted Stop Lamp (CHMSL) Connector Terminal Identification

Scheme 20

Scheme 20: Fog Lamp - LF
Scheme 20: Fog Lamp - LF
Connector Part Information OEM: 12124819 Service: 12101877 Description: 2-Way F Metri-Pack 280 Series, Sealed (BK)
Terminal Part Information Pins: Terminal: TBD Core/Insulation Crimp: TBD Release Tool/Test Probe: TBD

Fog Lamp - LF Connector Part Information

PinWire ColorCircuit No.Function
APU2234Front Fog Lamp Supply Voltage (T96)
BBK250Ground (T96)

Fog Lamp - LF Connector Terminal Identification
