Scheme 1
Scheme 1: Cigar Lighter/Power Outlet Schematics
Scheme 2
Scheme 2: Power Outlet Component Views
| Callout | Component Name |
|---|
| 1 | Turn Signal/Multifunction Lever |
| 2 | Cruise Control Switches |
| 3 | Instrument Panel Cluster (IPC) |
| 4 | Audio Steering Wheel Controls |
| 5 | Ambient Air Temperature Sensor |
| 6 | Hazard Switch |
| 7 | Inflatable Restraint I/P Module |
| 8 | I/P Compartment |
| 9 | Rear Compartment Lid Release Switch |
| 10 | Cigar Lighter |
| 11 | Traction Control Switch |
| 12 | Radio/Navigation Unit |
| 13 | Park Brake Lever |
| 14 | Shifter Knob |
| 15 | Inflatable Restraint Passenger Airbag On/Off Indicator |
| 16 | HVAC Controls |
| 17 | Windshield Wiper/Washer Controls |
| 18 | Inflatable Restraint Steering Wheel Module |
| 19 | Driver Information Center (DIC) Controls |
| 20 | Dimmer Switch |
| 21 | Fog Lamp Switch |
Scheme 3
Scheme 3: Auxiliary Power Outlet
| Connector Part Information OEM: 12176836 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (GY) |
|---|
| Terminal Part Information Pins: Terminal: TBD Core/Insulation Crimp: TBD Release Tool/Test Probe: TBD |
Connector Part Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | RD/WH | 240 | Battery Positive Voltage |
| B | | | Not Used |
| C | BK | 550 | Ground |
Connector Terminal Identification
