Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Engine Mount to Frame Nut | 75 N.m | 55 lb ft |
| Frame Brace Bolt | 60 N.m | 44 lb ft |
| Front Crossmember Brace Bolt | 50 N.m | 37 lb ft |
| Front Frame to Body Bolt | 110 N.m | 81 lb ft |
| + 90 degrees |
| Front Wheelhouse Liner Screw | 2.5 N.m | 22 lb in |
| Radiator Support Bolt | 50 N.m | 37 lb ft |
| Rear Brake Caliper Bracket Bolt | 50 N.m | 37 lb ft |
| Rear Frame Reinforcement Bolt | 60 N.m | 44 lb ft |
| Rear Frame Reinforcement Stud | 60 N.m | 44 lb ft |
| Rear Shock Absorber Bolt | 50 N.m | 37 lb ft |
| Rear Suspension Crossmember to Body Bolt | 110 N.m | 81 lb ft |
| + 90 degrees |
| Rear Wheelhouse Liner Screw | 2.5 N.m | 22 lb in |
| Right Park Brake Cable Retaining Bolt | 10 N.m | 89 lb in |
| Trailer Hitch Bolt | 100 N.m | 74 lb ft |
| Transmission Mount to Frame Nut | 75 N.m | 55 lb ft |
| Underbody Side Rail Bolt | 47 N.m | 35 lb ft |
| Underbody Side Rail Nut | 11 N.m | 97 lb in |
| Upper Bumper Support to Radiator Support Bolt | 9 N.m | 80 lb in |
| Wheel Drive Shaft Nut | 260 N.m | 192 lb ft |
Scheme 1
Scheme 1: Underbody Rear Side Rail Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure: Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle. |
| 1 | Underbody Rear Side Rail Bolt (Qty: 6) NOTE: Refer to Fastener Notice. Tighten: 47 N.m (35 lb ft) |
| 2 | Underbody Rear Side Rail Nut Tighten: 11 N.m (97 lb in) |
| 3 | Underbody Rear Side Rail |
| NOTE |
|---|
| Refer to Fastener Notice. |
