Lighting Systems: Specifications Saturn ION I

Exterior Lights 30 illustrations ~1452 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Fog Lamp Nuts2.5 N.m22 lb in
HVAC Control Screws2.5 N.m22 lb in
License Plate Lamp Screws2 N.m18 lb in
Side Marker Lamp Screws2.5 N.m22 lb in
Tail Lamp Screws2 N.m18 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics
Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4: Fog Lights Schematics
Scheme 4: Fog Lights Schematics

Scheme 5

Scheme 5: Exterior Lights Schematics
Scheme 5: Exterior Lights Schematics

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9: Interior Lights Schematics
Scheme 9: Interior Lights Schematics

Scheme 10

Scheme 10: Interior Lights Dimming Schematics
Scheme 10: Interior Lights Dimming Schematics

Scheme 11

Scheme 11: Lighting Systems Component Views
Scheme 11: Lighting Systems Component Views
CalloutComponent Name
1Ambient Light Sensor (T82)

Scheme 12

Scheme 12
Scheme 12
CalloutComponent Name
1A/T Shift Lock Control Solenoid
2Ignition Lock Cylinder Control Switch
3A/T Shift Indicator Lamp
4C351

Scheme 13

Scheme 13
Scheme 13
CalloutComponent Name
1Driver Outside Rearview Mirror
2LF Door Tweeter Speaker (UZ6)
3Driver Door Jamb Switch
4Instrument Panel (I/P) Dimmer Switch
5Fog Lamp Switch (T37)
6Rear Compartment Lid Release Switch
7LF Door Speaker
8Outside Rearview Mirror Switch (DG7)
9Window Switch - Driver (A31)
10Door Lock Switch - Driver (AU3)

Scheme 14

Scheme 14
Scheme 14
CalloutComponent Name
1Radio
2Passenger Door Jamb Switch
3RF Door Tweeter Speaker (UZ6)
4Radio Antenna
5Passenger Outside Rearview Mirror
6Front Passenger Door Lock Switch (AU3)
7Front Passenger Window Switch (A31)
8RF Door Speaker

Scheme 15

Scheme 15
Scheme 15
CalloutComponent Name
1LR Speaker
2Audio Amplifier (UZ6)
3Rear Compartment Courtesy Lamp
4RR Speaker

Scheme 16

Scheme 16
Scheme 16
CalloutComponent Name
1Courtesy/Reading Lamp (C74)
2Sunroof Switch (CF5)
3Sunroof Module (CF5)
4Dome Lamp

Scheme 17

Scheme 17
Scheme 17
CalloutComponent Name
1Dome Lamp
2Center High Mounted Stop Lamp (CHMSL)
3Rear Window Defogger Grid

Scheme 18

Scheme 18
Scheme 18
CalloutComponent Name
1Tail/Turn Signal Lamp - Left
2Tail/Stop Lamp - Left
3Backup Lamp - Left

Scheme 19

Scheme 19
Scheme 19
CalloutComponent Name
1Tail/Turn Signal Lamp - Right
2Tail/Stop Lamp - Right
3Backup Lamp - Right

Scheme 20

Scheme 20
Scheme 20
CalloutComponent Name
1Door Jamb Switch - RR, LR Similar

Scheme 21

Scheme 21
Scheme 21
CalloutComponent Name
1Windshield Washer Fluid Pump
2Horn
3Fog Lamp - LF

Scheme 22

Scheme 22
Scheme 22
CalloutComponent Name
1C110
2Fog Lamp RF

Scheme 23

Scheme 23
Scheme 23
CalloutComponent Name
1Turn Signal/Multifunction Switch
2Windshield Wiper/Washer Switch
3Hazard Switch
4Instrument Panel Cluster (IPC)
5Traction Control Switch (NW7)
6Radio
7A/T Shifter (MN5)
8HVAC Control Assembly
9Steering Wheel Controls - Right (K34)
10Steering Wheel Controls - Left (K34)
11Rear Compartment Lid Release Switch

Scheme 24

Scheme 24
Scheme 24
CalloutComponent Name
1C111 (Sedan), C110 Similar on Right
2Park/Turn Signal Lamp - LF (Sedan), RF Similar
3Headlamp - Left (Sedan), Right Similar
4Headlamp - Left (Coupe), Right Similar
5Park/Turn Signal Lamp - LF (Coupe), RF Similar

Scheme 25

Scheme 25
Scheme 25
CalloutComponent Name
1I/P Tie Bar
2Data Link Connector (DLC)
3Headlamp Relay

Scheme 26

Scheme 26
Scheme 26
CalloutComponent Name
1Rear Component Lid Latch
2License Lamp
3C401

Scheme 27

Scheme 27
Scheme 27
CalloutComponent Name
1Marker Lamp - LF, RF Similar

Scheme 28

Scheme 28
Scheme 28
CalloutComponent Name
1Stop Lamp Switch - Upper
2Stop Lamp Switch - Lower

Scheme 29

Scheme 29
Scheme 29
CalloutComponent Name
1Backup Lamp Switch (M86)
2Engine Coolant Temperature Sensor (ECT)
3Heated Oxygen Sensor (HO2S)1
4Heated Oxygen Sensor (HO2S)2 Connector

Scheme 30

Scheme 30
Scheme 30
CalloutComponent Name
1Backup Lamp Switch

Ambient Light Sensor (T82) Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A L-GN/BK 1137 DRL Ambient Light Sensor Signal B YE/BK 1138 DRL Ambient Light Sensor Low Reference

Backup Lamp - Left Connector Part Information 16530675 2-Way (GY) Pin Wire Color Circuit No. Function A L-GN 24 Backup Lamp Supply Voltage B BK 750 Ground BK 750 Ground

Backup Lamp - Right Connector Part Information 16530675 2-Way (GY) Pin Wire Color Circuit No. Function A L-GN 24 Backup Lamp Supply Voltage B BK 750 Ground BK 750 Ground

Backup Lamp Switch (M86/MU3) Connector Part Information 12052641 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A PK 539 Ignition 1 Voltage B L-GN 24 Backup Lamp Supply Voltage

Center High Mounted Stop Lamp (CHMSL) Connector Part Information 12092158 2-Way F (GY) Pin Wire Color Circuit No. Function A L-BU 20 Stop Lamp Supply Voltage B BK 750 Ground

Courtesy/Reading Lamp (C74) Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A WH 156 Courtesy Lamp Low Control B BK 750 Ground C OG 1732 Courtesy Lamps Supply Voltage

Dome Lamp Connector Part Information 12045813 4-Way F Metri-Pack 150 Series (TN) Pin Wire Color Circuit No. Function A WH 156 Courtesy Lamp Low Control B - - Not Used C BK 750 Ground D OG 1732 Courtesy Lamps Supply Voltage

Door Jamb Switch - Driver Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A L-GN/BK 394 Driver Door Jamb Switch Signal B BK/WH 151 Ground C - - Not Used

Door Jamb Switch - Front Passenger Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A L-BU 395 Passenger Door Jamb Switch Signal B BK/WH 151 Ground C - - Not Used

Door Jamb Switch - LR (Sedan) Connector Part Information 15304635 2-Way F Metri-Pack 150 Series (GY) Pin Wire Color Circuit No. Function A L-BU 395 Passenger Door Jamb Switch Signal B BK/WH 151 Ground

Door Jamb Switch - RR (Sedan) Connector Part Information 15304635 2-Way F Metri-Pack 150 Series (GY) Pin Wire Color Circuit No. Function A L-BU 395 Passenger Door Jamb Switch Signal B BK/WH 151 Ground

Fog Lamp - LF (T37/T96) Connector Part Information 12124819 2-Way F (BK) Pin Wire Color Circuit No. Function A PU 34 Fog Lamps Supply Voltage B BK 150 Ground

Fog Lamp - RF (T37/T96) Connector Part Information 12124819 2-Way F (BK) Pin Wire Color Circuit No. Function A PU 34 Fog Lamps Supply Voltage B BK 150 Ground

Fog Lamp Switch (T37/T96) Connector Part Information 12089248 4-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BK/WH 151 Ground B GY 8 Instrument Panel Lamp Supply Voltage C YE 317 Fog Lamp Relay Coil Supply Voltage D OG 192 Front Fog Lamp Switch Signal/Fog Lamps Enable

Hazard Switch Connector Part Information 12047785 4-Way F Metri-Pack 150 Series (WH) Pin Wire Color Circuit No. Function A BK/WH 151 Ground B GY 8 Instrument Panel Lamp Supply Voltage C - - Not Used D L-BU 1508 Turn/Hazard Module Supply Voltage

Headlamp - Left Connector Part Information 12048369 3-Way F Metri-Pack 280 Series Sealed (BU) Pin Wire Color Circuit No. Function A D-BU 1201 Headlamp Low Beam Signal B OG 740 Battery Positive Voltage C PK 1200 Headlamp High Beam Signal

Headlamp - Right Connector Part Information 12048369 3-Way F Metri-Pack 280 Series Sealed (BU) Pin Wire Color Circuit No. Function A D-BU 1201 Headlamp Low Beam Signal B OG 640 Battery Positive Voltage C PK 1200 Headlamp High Beam Signal

Headlamp Relay (T82) Connector Part Information 12110541 6-Way F Metri-Pack 280 Series Flexlock (BK) Pin Wire Color Circuit No. Function A1 BK 550 Ground A2 BK 550 Ground BK 550 Ground B1-B2 - - Not Used C1 YE 10 Headlamp Switch Signal C2 PK/WH 1970 Headlamp Low Beam Relay Control

I/P Dimmer Switch Connector Part Information 12020299 5-Way F P/C Edgeboard - Standard (WH) Pin Wire Color Circuit No. Function A - - Not Used B BN/WH 230 Instrument Panel Lamps Dimming Control C PU 719 Low Reference D-E - - Not Used

License Lamp Connector Part Information 15324946 2-Way F Lamp Socket Wedge Base W2 Pin Wire Color Circuit No. Function A BN 9 Park Lamp Supply Voltage B BK 850 Ground

Marker Lamp - LF (Coupe) Connector Part Information 15324946 2-Way F Lamp Socket Wedge Base W2 (D-GY) Pin Wire Color Circuit No. Function A BN 9 Park Lamp Supply Voltage B BK 150 Ground

Marker Lamp - RF (Coupe) Connector Part Information 15324946 2-Way F Lamp Socket Wedge Base W2 (D-GY) Pin Wire Color Circuit No. Function A BN 9 Park Lamp Supply Voltage B BK 150 Ground

Park/Turn Signal Lamp - LF (Coupe) Connector Part Information 7900-1493-000 3-Way F (BK) Pin Wire Color Circuit No. Function 1 D-BU 15 Right Turn Signal Lamps Supply Voltage 2 BN 9 Park Lamp Supply Voltage 3 BK 150 Ground

Park/Turn Signal Lamp - RF (Coupe) Connector Part Information 7900-1493-000 3-Way F (BK) Pin Wire Color Circuit No. Function 1 D-BU 15 Right Turn Signal Lamps Supply Voltage 2 BN 9 Park Lamp Supply Voltage 3 BK 150 Ground

Park/Turn Signal Lamp - LF (Sedan) Connector Part Information 16530670 3-Way F (BK) Pin Wire Color Circuit No. Function A L-BU 14 Left Turn Signal Lamps Supply Voltage B BN 9 Park Lamp Supply Voltage G BK 150 Ground

Park/Turn Signal Lamp - RF (Sedan) Connector Part Information 16530670 3-Way F (BK) Pin Wire Color Circuit No. Function A D-BU 15 Right Turn Signal Lamps Supply Voltage B BN 9 Park Lamp Supply Voltage G BK 150 Ground

Rear Compartment Courtesy Lamp Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A OG/BK 737 Rear Compartment Lamp Control B OG 1732 Courtesy Lamps Supply Voltage

Stop Lamp Switch - Lower Connector Part Information 12041433 2-Way F Metri-Pack 280 Series (BK) Pin Wire Color Circuit No. Function A PK 339 Ignition 1 Voltage B PU 420 Stop Lamp Switch Signal

Stop Lamp Switch - Upper Connector Part Information 12033701 2-Way F Metri-Pack 480 Series (GY) Pin Wire Color Circuit No. Function A OG 140 Battery Positive Voltage B L-BU 20 Stop Lamp Switch Signal

Tail/Stop Lamp - Left Connector Part Information 16530671 3-Way F (GY) Pin Wire Color Circuit No. Function A L-BU 20 Stop Lamp Supply Voltage B BN 9 Park Lamp Supply Voltage BN 9 Park Lamp Supply Voltage G BK 750 Ground BK 750 Ground

Tail/Turn Signal Lamp - Left Connector Part Information 16530671 3-Way F (GY) Pin Wire Color Circuit No. Function A YE 18 Left Rear Stop/Turn Lamp Supply Voltage B BN 9 Park Lamp Supply Voltage G BK 750 Ground

Tail/Stop Lamp - Right Connector Part Information 16530671 3-Way F (GY) Pin Wire Color Circuit No. Function A L-BU 20 Stop Lamp Supply Voltage B BN 9 Park Lamp Supply Voltage BN 9 Park Lamp Supply Voltage G BK 850 Ground BK 850 Ground

Tail/Turn Signal Lamp - Right Connector Part Information 16530671 3-Way F (GY) Pin Wire Color Circuit No. Function A YE 19 Right Rear Stop/Turn Lamp Supply Voltage B BN 9 Park Lamp Supply Voltage G BK 750 Ground

Turn Signal/Multi-Function Switch Connector Part Information 12047976 8-Way F Metri-Pack 280 Series (BU) Pin Wire Color Circuit No. Function A BK 550 Ground B L-BU 1508 Turn/Hazard Module Supply Voltage C PK 1200 Headlamp High Beam Signal D D-BU 1201 Headlamp Low Beam Signal E YE 10 Headlamp Lamp High/Low Beam Ground (T82) F BN 9 Park Lamp Supply Voltage G OG 240 Battery Positive Voltage H PU/WH 549 Headlamp Switch Headlamps Off Signal (T82)

Begin the system diagnosis with the Diagnostic System Check - Vehicle in Vehicle DTC Information. The Diagnostic System Check will provide the following information

  1. The identification of the control modules which command the system
  2. The ability of the control modules to communicate through the serial data circuit
  3. The identification of any stored diagnostic trouble codes (DTCs) and their status

The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.

More articles — Lighting Systems
