Wiring diagram: Air conditioning — Compressor circuit, with auto a/c Saturn Aura I

Components on these wiring diagrams 14

Click a component to highlight it on every diagram it appears on.

• 1 9 Serial Data Serial Data
• 3.6L, 2.4L 3.5L 2.4L
• A/C Clu Fuse 1
• A/C Clutch Relay 34
• A/C Compressor Clutch
• A/C Refrigerant Pressure Sensor
• Body Control Module
• High Speed Gmlan Serial Data
• Hvac Control Module
• Low — Speed Gmlan Serial Data
• Mode Switch
• Switch Temperature Upper Air
• Temperature Switch
• Underhood Fuse Block
