Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Bezel Screw	8 N.m	70 lb in
Coat Hook Bolt	9 N.m	80 lb in
D-Ring Bolt	35 N.m	25 lb ft
Inside Handle Screw	2 N.m	18 lb in
Sunshade Anchor Screws	3 N.m	25 lb in
Sunshade Screws	3 N.m	25 lb in
Trim Panel Screw	8 N.m	70 lb in

Scheme 43

Scheme 43: Front Door Switch Bezel Replacement (Passenger Side)

Callout	Component Name
1	Front Side Door Pull Handle Finish Plug
2	Front Side Door Window Bezel Screw (Qty: 2) NOTE: Refer to Fastener Notice. Tighten: 8 N.m (70 lb in)
3	Front Side Door Window Bezel Assembly Tip: Disconnect electrical connector.

NOTE
Refer to Fastener Notice.

Scheme 44

Scheme 44: Front Door Switch Bezel Replacement (Driver Side)

Callout	Component Name
1	Front Side Door Pull Handle Finish Plug
2	Front Side Door Window Bezel Screw (Qty: 2) NOTE: Refer to Fastener Notice. Tighten: 8 N.m (70 lb in)
3	Front Side Door Window Bezel Assembly Tip: Disconnect electrical connector.

NOTE
Refer to Fastener Notice.

Scheme 45

Scheme 45: Rear Door Switch Bezel Replacement

Callout	Component Name
1	Rear Side Door Pull Handle Finish Plug
2	Rear Side Door Window Bezel Screw (Qty: 2) NOTE: Refer to Fastener Notice. Tighten: 8 N.m (70 lb in)
3	Rear Side Door Window Bezel Assembly

NOTE
Refer to Fastener Notice.

Scheme 46

Scheme 46: Front Side Door Trim Panel Replacement

Callout	Component Name
Preliminary Procedure: Remove front door switch bezel. Refer to Front Door Switch Bezel Replacement (Passenger Side) or Front Door Switch Bezel Replacement (Driver Side).
1	Front Side Door Trim Push-in Retainer (Qty: 2)
2	Front Side Door Inside Handle Bolt Cap
3	Front Side Door Inside Handle Screw NOTE: Refer to Fastener Notice. Tighten: 2 N.m (18 lb in)
4	Front Side Door Trim Panel Screw (Qty: 2) Tighten: 8 N.m (70 lb in)
5	Front Side Door Locking Rod Knob Tab
6	Front Side Door Locking Rod Knob Assembly
7	Front Side Door Trim Panel Assembly Procedure Use a J 38778 to aid in the removal of the door trim panel Pull upwards on door lock retainer cable to disengage. Disconnect electrical connectors. Special Tools: J 38778 Door Trim Clip Remover
8	Front Side Door Trim Panel Retainer (Qty: 7)

NOTE
Refer to Fastener Notice.

Scheme 47

Scheme 47: Rear Side Door Trim Panel Replacement

Callout	Component Name
Preliminary Procedure: Remove rear door switch bezel. Refer to Rear Door Switch Bezel Replacement.
1	Rear Side Door Trim Push-in Retainer (Qty: 2)
2	Rear Side Door Locking Rod Knob Tab
3	Rear Side Door Locking Rod Knob Assembly
4	Rear Side Door Inside Handle Bolt Cap
5	Rear Side Door Inside Handle Screw NOTE: Refer to Fastener Notice. Tighten: 2 N.m (18 lb in)
6	Rear Side Door Trim Panel Screw (Qty: 2) Tighten: 2 N.m (18 lb in)
7	Rear Side Door Trim Panel Assembly Procedure Use a J 38778 to aid in the removal of the door trim panel Pull upwards on the door lock retainer cable to disengage. Disconnect the electrical connectors. Special Tools: J 38778 Door Trim Clip Remover
8	Rear Side Door Trim Panel Retainer (Qty: 7)

NOTE
Refer to Fastener Notice.

Scheme 48

Scheme 48: Front Side Door Water Deflector Replacement

Callout	Component Name
Preliminary Procedure: Remove the interior trim panel. Refer to Front Side Door Trim Panel Replacement.
1	Water Deflector Tip: Pull the water deflector from the door. Guide electrical connectors through the water deflector while removing it from the door.

Scheme 49

Scheme 49: Rear Side Door Water Deflector Replacement

Callout	Component Name
Preliminary Procedure: Remove the rear door trim panel. Refer to Rear Side Door Trim Panel Replacement.
1	Rear Door Water Deflector Tip: Guide electrical connectors through the water deflector while removing it from the door.

Scheme 50

Scheme 50: Rear Compartment Trim Panel Replacement

Callout	Component Name
Preliminary Procedure: Remove the rear compartment sill plate. Refer to Rear Compartment Sill Trim Plate Replacement.
1	Rear Compartment Side Trim Panel Retainer (Qty: 4)
2	Rear Compartment Side Trim Panel Assembly

Scheme 51

Scheme 51: Coat Hook Replacement

Callout	Component Name
1	Coat Hook Bolt (Qty: 1) NOTE: Refer to Fastener Notice. Tighten: 9 N.m (80 lb in)
2	Coat Hook Assembly Tip: Pull cover downward to access fastener.

NOTE
Refer to Fastener Notice.

Scheme 52

Scheme 52: Sunshade Replacement

Callout	Component Name
1	Sunshade Screw (Qty: 3) NOTE: Refer to Fastener Notice. Tighten: 3 N.m (25 lb in)
2	Sunshade Assembly Procedure Squeeze the tabs at the base of the sunshade assembly to remove from the headliner. Disconnect electrical connector.

NOTE
Refer to Fastener Notice.

Scheme 53

Scheme 53: Sunshade Anchor Replacement

Callout	Component Name
Preliminary Procedures: Remove sunshade assembly. Refer to Sunshade Replacement.
1	Sunshade Anchor Screw NOTE: Refer to Fastener Notice. Tighten: 3 N.m (25 lb in)
2	Sunshade Anchor Assembly Tip: Pull cover downward to access fastener.

NOTE
Refer to Fastener Notice.

Scheme 54

Scheme 54: Windshield Pillar Garnish Molding Replacement

Callout	Component Name
Preliminary Procedure: Disable the SIR system. Refer to SIR Disabling and Enabling.
1	Windshield Side Upper Garnish Molding Retainer
2	Windshield Side Upper Garnish Molding Clip
3	Windshield Side Upper Garnish Molding Tether Clip
4	Windshield Side Upper Garnish Molding Assembly Procedure Tabs must be installed prior to retainers. Tabs to be fully seated in I/P trim panel retainer and valance panel. Disconnect electrical connectors. Ensure the tether is reattached when installed.

Scheme 55

Scheme 55: Center Pillar Upper Garnish Molding Replacement

Callout	Component Name
Preliminary Procedure: Disable SIR system. Refer to SIR Disabling and Enabling.
1	Seat Belt D-Ring Adjuster Bolt NOTE: Refer to Fastener Notice. Tighten: 35 N.m (25 lb ft)
2	Rear Quarter Upper Trim Panel Screw Tip: Open the access door to remove screw. Tighten: 3 N.m (27 lb in)
3	Center Pillar Upper Garnish Molding

NOTE
Refer to Fastener Notice.

Scheme 56

Scheme 56: Center Pillar Lower Garnish Molding Replacement

Callout	Component Name
Preliminary Procedures Remove front carpet retainer. Refer to Front Carpet Retainer Replacement. Remove rear carpet retainer. Refer to Rear Carpet Retainer Replacement. Remove the center pillar upper garnish molding. Refer to Center Pillar Upper Garnish Molding Replacement.
1	Body Lock Pillar Lower Garnish Molding Assembly
2	Body Lock Pillar Lower Garnish Molding Clip (Qty: 2)
3	Body Lock Pillar Lower Garnish Molding Retainer (Qty: 2)

Scheme 57

Scheme 57: Body Rear Corner Upper Garnish Molding Replacement

Callout	Component Name
Preliminary Procedure: Disable SIR system. Refer to SIR Disabling and Enabling.
1	Rear Corner Upper Garnish Molding Assembly Procedure Pull outward from the top front to release the upper portion of the molding, then move upward to release the tabs. Release the tether to remove. Securely attach the tether when reinstalling the molding.
2	Rear Corner Upper Garnish Molding Retainer
3	Rear Corner Upper Garnish Molding Clip

Scheme 58

Scheme 58: Body Lock Pillar Lower Trim Panel Replacement

Callout	Component Name
Preliminary Procedures Remove rear carpet retainer. Refer to Rear Carpet Retainer Replacement. Remove rear seat back assembly. Refer to Rear Split Folding Seat Back Bolster Replacement. Remove rear corner upper garnish molding. Refer to Body Rear Corner Upper Garnish Molding Replacement. Remove the rear seat cushion. Refer to Rear Seat Cushion Replacement (Sedan).
1	Body Side Rear Trim Panel Push-in Retainer (Qty: 2)
2	Body Side Rear Trim Panel Assembly Tip: Ensure seat belt assembly is routed over and through opening in panel assembly.
3	Body Side Rear Trim Panel Retainer

Scheme 59

Scheme 59: Rear Window Shelf Trim Panel Replacement

Callout	Component Name
Preliminary Procedures Disable SIR system. Refer to SIR Disabling and Enabling. Remove rear corner upper molding. Refer to Body Rear Corner Upper Garnish Molding Replacement. Remove the rear seat back cushion frame. Refer to Rear Seat Back Cushion Frame Replacement.
1	Rear Window Shelf Trim Panel Retainer (Qty: 2)
2	Rear Window Shelf Trim Panel Assembly Tip: Disconnect electrical connector.
