Supplemental Inflatable Restraint System: Specifications Saturn Aura I

Airbag 4 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Curtain Inflator Retaining Bolt (10 mm Hex Head)10 N.m89 lb in
Curtain Inflator Retaining Nut (10 mm Hex Head)10 N.m89 lb in
Curtain Inflator Retaining Screw (7 mm Hex Head)2.5 N.m22 lb in
Front Seat Anchoring Bolts20 N.m15 lb ft
Front Seat Inflatable Restraint Side Impact Module Nuts10 N.m89 lb in
Height Adjuster Fasteners35 N.m26 lb ft
Inflator Fasteners5 N.m18 lb in
Latch Bracket Attaching Bolts25 N.m18 lb ft
Passenger Inflator Module Bolts10 N.m89 lb in
Retractor Fastener35 N.m26 lb ft
SDM Nuts10 N.m89 lb in
SIS Fasteners10 N.m89 lb in
Seat Belt Buckle-to-Seat Frame Fasteners35 N.m26 lb ft
Shoulder Belt-to-Height Adjuster Bolt29 N.m21 lb ft
Shoulder Belt-to-Seat Track Fastener20 N.m15 lb ft
Steering Column Cover Fasteners4 N.m35 lb in
Steering Wheel Nut40 N.m30 lb ft

Scheme 1

Scheme 1: SIR Schematics
Scheme 1: SIR Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4
