Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Accelerator Pedal Bracket Nuts | 10 N.m | 89 lb in |
| Accelerator Pedal Nuts | 10 N.m | 89 lb in |
| Adjustable Brake Pedal Motor Mounting Screws | 3 N.m | 27 lb in |
| Brake and Accelerator Pedal Adjustment Position Sensor Bolt | 2 N.m | 18 lb in |
| Brake Pedal Assembly to Cowl Mounting Nuts | 15 N.m | 11 lb ft |
| Brake Pedal Bracket Bolts | 25 N.m | 18 lb ft |
Scheme 1
Scheme 1: Adjustable Pedal Schematics
Scheme 2
Scheme 2: Brake and Accelerator Pedal Adjuster Switch Replacement
| Callout | Component Name |
|---|
| 1 | Knee Bolster Assembly Refer to Knee Bolster Replacement . |
| 2 | Knee Bolster Bracket Screw (Qty: 2) NOTE: Refer to Fastener Notice. Tighten: 2 N.m (18 lb in) |
| 3 | Knee Bolster Bracket |
| 4 | Electronic Brake Control Brake Pedal Switch Assembly Tip: Disconnect electrical connector. |
| NOTE |
|---|
| Refer to Fastener Notice. |
