Wiring diagram: Computer data lines — Computer data lines circuit Saturn Astra I

Components on these wiring diagrams

Click a component to highlight it on every diagram it appears on.

• A/T
• Data Link Connector
• Dlc — Class 2 Serial Data
• Driver Information Center
• Electronic Brake Control Module
• Engine — Control Module
• Hi Spd
• Hi Spd Hi Spd Low Low Hi Spd Gmlan Spd Spd Gmlan Gmlan Serial
• High Speed Gmlan Serial Data
• High Speed Gmlan Serial Data Bus +
• Inflatable Restraint Sensing, Diagnostic Module
• Left Vehicle Communication Interface Module
• Lo Spd
• Low — Speed Gmlan Serial Data
• M/T
• Mid — Speed Gmlan Serial Data
• Power Steering Control Module
• Rear Fuse Lo Spd Gmlan Gmlan Block Serial Serial Data Data
• Right Vehicle Communication Interface Module
• Steering Column Control Module
• Tire Pressure Module
• Transmission Control Module
• Yaw, Lateral Accelerometer Sensor
