Engine Cooling System: Specifications Saturn Astra I

Cooling System (Mechanical) 2 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Battery Bracket Bolt5 N.m44 lb in
Battery Holder Bolt15 N.m11 lb ft
Battery Negative Connection Nut5 N.m44 lb in
Condenser to Radiator Bolts5 N.m44 lb in
Coolant Pump Manifold Bolts8 N.m71 lb in
Exhaust Camshaft Adjuster65 N.m48 lb ft
Plus 120 Degrees Plus 15 Degrees
Exhaust Camshaft Adjuster Closure Bolt30 N.m22 lb ft
Fan Housing to Radiator Bolts5 N.m44 lb in
Fan Motor to Fan Housing Bolts3 N.m26 lb in
Front Fascia Bolts - Bottom2.5 N.m22 lb in
Front Fascia Bolts - Top2.5 N.m22 lb in
Ground Connection to Ground Terminal Nut5 N.m44 lb in
Heat Exchanger to Oil Filter Adapter Bolts2.5 N.m22 lb in
Intake Camshaft Adjuster65 N.m48 lb ft
Plus 120 Degrees Plus 15 Degrees
Intake Camshaft Adjuster Closure Bolt30 N.m22 lb ft
Negative Connection to Ground Terminal Nut5 N.m44 lb in
Oil Cooling Line Bolt - Lower25 N.m18 lb ft
Oil Cooling Line Bolt - Upper25 N.m18 lb ft
Oil Filter Adaptor Bolts8 N.m71 lb in
Positive Cable to Positive Terminal Bolt5 N.m44 lb in
Positive Connection to Positive Terminal Nut5 N.m44 lb in
Radiator Bracket Bolts - Bottom of Radiator5 N.m44 lb in
Radiator Bracket Bolts - Lower15 N.m11 lb ft
Rear Toothed Belt Cover Bolts6 N.m53 lb in
Thermostat Housing Bolts8 N.m71 lb in
Thermostat Housing Coolant Pipe to Oil Filter Adapter Bolts8 N.m71 lb in
Water Pump Belt Pulley Bolts20 N.m15 lb ft
Water Pump Bolts8 N.m71 lb in
Wiring Harness Bracket Nut2.5 N.m22 lb in
Wiring Harness Bracket to Thermostat Housing Nut5 N.m44 lb in

Scheme 1

Scheme 1: Engine Cooling Schematics
Scheme 1: Engine Cooling Schematics

Scheme 2
