Scheme 1
BRAKE FLUID WARNING LIGHT
Light indicates low brake fluid level in the master cylinder reservoir. Stop vehicle and check brake fluid reservoir if light comes on while driving. Have the system checked and serviced immediately. Vehicle should not be driven until cause has been located and corrected.
ANTI-LOCK BRAKE WARNING LIGHT (IF EQUIPPED)
If light comes on while driving, it indicates a possible defect in the anti-lock braking system. Have the system checked and serviced promptly. The regular braking system will still operate normally, but without anti-lock function.
| CAUTION | DO NOT continue to operate vehicle if both BRAKE FLUID and ANTI-LOCK warning lights are illuminated at the same time. |
OIL PRESSURE WARNING LIGHT
Light indicates low oil pressure, but does not indicate amount of oil in the engine. Stop vehicle, turn off engine and check oil level if light comes on while driving. DO NOT continue to drive vehicle if light comes on again after restarting engine, even if oil level is correct, as severe engine damage may result.
CHARGE WARNING LIGHT
Light indicates possible fault in the charging system. Check alternator belt. If belt is okay, but light remains illuminated, have the system checked and serviced promptly. DO NOT drive vehicle if alternator belt is loose or broken.
PARK BRAKE WARNING LIGHT
Light comes on with the parking brake fully or partially engaged. If light does not come on as designed or comes on at any other time, it indicates possible fault in the electrical system or the parking brake switch may be damaged. Have the system checked and serviced as necessary to correct problem.
TRIP COMPUTER DISPLAY (IF EQUIPPED)
System monitors a variety of functions including some check/warning indications in vehicle. Whenever the INFO button is pressed, a monitored function will be displayed on the left side of the screen. The check/warning indications are automatically shown on the right side of the screen and cannot be selected by pressing the button. Should a fault occur in one of the trip computer sensor, an ERR message will appear briefly on the left side of the screen when the ignition switch is turned on and will go out when the car is driven off. The ERR code will be reappeared on the trip computer display screen if the function with the faulty sensor is selected.
CHECK ENGINE WARNING LIGHT
The CHECK message will light up on the right side of the trip computer display screen if there is an electrical malfunction in the fuel injection system. A back-up system in the control unit will take over to allow continued operation of vehicle after light has illuminated. On non-turbo models, light may also indicate a fault in the ignition system. Have the system checked and serviced as soon as possible if light comes on.
SHIFT UP INDICATOR LIGHT (MANUAL TRANSMISSION VEHICLES)
Light serves as a gearshift guide for conserving fuel by illuminating when it is time to shift into a higher gear.
CRUISE INDICATOR LIGHT (IF EQUIPPED)
Light comes on to indicate that the cruise control switch is currently in the ON position.
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG WARNING LIGHT (IF
EQUIPPED)
Light is designed to come on briefly with the ignition switch in the ON position and should go out shortly after. If light blinks or glows steadily while driving, it indicates possible fault in the Supplemental Restraint System (SRS) and should be checked and serviced as soon as possible.
AUTOMATIC RESET (1994 MODELS)
- If 365 days have elapsed since last service or vehicle is within 600 miles of next required service, TIME FOR SERVICE will be displayed on service reminder in instrument cluster.
- Press CLEAR button once to erase display. Service message will be displayed for the next 20 key on cycles. On 21st key on cycle, service indicator will automatically reset.
MANUAL RESET (1994 MODELS)
- Press and hold CLEAR button for at least 8 seconds. CLEAR will be displayed and after 4 second delay, audible signal sound. DO NOT release button at this time.
- SERVICE will be displayed after another 4 second delay. Audible signal will again sound. Release button. Service message is now reset and will not reappear until required service time or mileage is accomplished.
