Camber & Caster adjustments. Scheme 1
Scheme 1: Camber & Caster adjustments.
ALIGNMENT SPECIFICATIONS
| Application | Specification |
|---|
| 900 900S |
| Front (Scheme 1) |
| Camber in Degrees |
| Fraction | 1/2 +/- 1/2 |
| Decimal | .5 +/- .5 |
| Caster in Degrees |
| Fraction | 2 +/- 1/2 |
| Decimal | 2.0 +/- .5 |
| Toe-In in Inches |
| Fraction | 3/32 +/- 3/64 |
| Decimal | .09 +/- .05 |
| Toe-In in Degrees |
| Fraction | 3/16 +/- 3/32 |
| Decimal | .19 +/- .09 |
| Toe-Out in Turns |
| Inner | (1) |
| Outer | (1) |
| Steering Axis Inclination (SAI) | (1) |
| 900 Turbo |
| Rear |
| Camber in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Caster in Degrees |
| Fraction | N/A |
| Decimal | N/A |
| Toe-In in Inches |
| Fraction | 5/32 +/- 3/64 |
| Decimal | .16 +/- .05 |
| Toe-In in Degrees |
| Fraction | 5/16 +/- 3.32 |
| Decimal | .31 +/- .09 |
| Toe-Out in Turns |
| Inner | N/A |
| Outer | N/A |
| Steering Axis Inclination (SAI) | N/A |
| 9000 Turbo |
| Front (Scheme 1) |
| Camber in Degrees |
| Fraction | 5/8 +/- 1/2 |
| Decimal | .62 +/- .5 |
| Caster in Degrees |
| Fraction | 1 5/8 +/- 1/2 |
| Decimal | 1.62 +/- .5 |
| Toe-In in Inches |
| Fraction | 3/32 +/- 3/64 |
| Decimal | .09 +/- .05 |
| Toe-In in Degrees |
| Fraction | 3/16 +/- 3/32 |
| Decimal | .19 +/- .09 |
| Toe-Out in Turns |
| Inner | (1) |
| Outer | (1) |
| Steering Axis Inclination (SAI) | (1) |
| (1) Information not available. |
| (1) | Information not available. |
