Interior Equipment: Component Locations Saab 9-5 II

Exterior/interior Trim 26 illustrations ~164 words

Special Tools

Illustration Tool Number/Description BO-347 KM-347 Installer BO-569-A KM-569-A Plug Lifter DT-6459-B Torque Wrench GE-604-D MKM-604-D TORX Bit and Socket Set EL 47955 J 2534 Multi Diagnostic Interface MDI

Scheme 42

Scheme 42: Special Tools
Scheme 42: Special Tools

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Illustration Tool Number/Description BO-347 KM-347 Installer BO-569-A KM-569-A Plug Lifter DT-6459-B Torque Wrench GE-604-D MKM-604-D TORX Bit and Socket Set EL 47955 J 2534 Multi Diagnostic Interface MDI

Scheme 45

Scheme 45: Special Tools
Scheme 45: Special Tools

Scheme 46

Scheme 46
Scheme 46

Illustration Tool Number/Description BO-347 KM-347 Installer BO-569-A KM-569-A Plug Lifter DT-6459-B Torque Wrench GE-604-D MKM-604-D TORX Bit and Socket Set

Scheme 47

Scheme 47: Special Tools
Scheme 47: Special Tools

Scheme 48

Scheme 48
Scheme 48

Location (pos)

  1. 01 - Front
  2. 02 - Rear
  3. 03 - Left
  4. 04 - Right
  5. 05 - All
  6. 06 - Upper
  7. 07 - Centre
  8. 08 - Lower
  9. 09 - Service Information

Scheme 49

Scheme 49: Front Floor Panel Carpet Replacement
Scheme 49: Front Floor Panel Carpet Replacement
CalloutComponent Name
Preliminary Procedure Remove the driver or passenger seat. Refer to DRIVER OR PASSENGER SEAT REPLACEMENT (8-WAY-POWER) or DRIVER OR PASSENGER SEAT REPLACEMENT (2/4/6-WAY HYBRID, 6-WAY HYBRID SPORT) . Remove the front floor console. Refer to FRONT FLOOR CONSOLE REPLACEMENT . Remove the front and rear side door sill trim plate. Refer to FRONT AND REAR SIDE DOOR SILL TRIM PLATE REPLACEMENT .
1Front Floor Panel Carpet

Scheme 50

Scheme 50: Rear Floor Panel Carpet Replacement
Scheme 50: Rear Floor Panel Carpet Replacement
CalloutComponent Name
Preliminary Procedure Remove the driver or passenger seat. Refer to DRIVER OR PASSENGER SEAT REPLACEMENT (8-WAY-POWER) or DRIVER OR PASSENGER SEAT REPLACEMENT (2/4/6-WAY HYBRID, 6-WAY HYBRID SPORT) . Remove the rear seat. Refer to REAR SEAT REPLACEMENT (BACK 40 PERCENT) or REAR SEAT REPLACEMENT (BACK 60 PERCENT) Remove the front floor console. Refer to FRONT FLOOR CONSOLE REPLACEMENT . Remove the front and rear side door sill trim plate. Refer to FRONT AND REAR SIDE DOOR SILL TRIM PLATE REPLACEMENT .
1Rear Floor Panel Carpet

Scheme 51

Scheme 51: Rear Compartment Floor Panel Carpet Replacement
Scheme 51: Rear Compartment Floor Panel Carpet Replacement
CalloutComponent Name
1Rear Compartment Floor Panel Carpet

Scheme 52

Scheme 52: Headlining trim panel, replace (without sunroof) 4D
Scheme 52: Headlining trim panel, replace (without sunroof) 4D
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. WARNING: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. WARNING: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. Preliminary Procedure Disable the SIR system. Refer to SIR DISABLING AND ENABLING . Remove the sunshade. Refer to SUNSHADE REPLACEMENT . Remove the sunshade supports. Refer to SUNSHADE SUPPORT REPLACEMENT . Remove the roof rail front assist handles. Refer to ROOF RAIL FRONT ASSIST HANDLE REPLACEMENT . Remove the windshield side garnish moldings. Refer to WINDSHIELD SIDE GARNISH MOLDING REPLACEMENT . Remove the center pillar upper garnish moldings. Refer to CENTER PILLAR UPPER GARNISH MOLDING REPLACEMENT . Remove the body lock pillar upper trim panel. Refer to C-pillar upper trim panel, replace 4D Remove the reading lamp assembly. Refer to READING LAMP REPLACEMENT . Remove the front side door, passenger side. Refer to FRONT SIDE DOOR REPLACEMENT . Remove the front passenger seat. Refer to DRIVER OR PASSENGER SEAT REPLACEMENT (8-WAY-POWER) or DRIVER OR PASSENGER SEAT REPLACEMENT (2/4/6-WAY HYBRID, 6-WAY HYBRID SPORT) .
1Headlining Trim Panel Procedure Disconnect the electrical connectors. NOTE: Carefully observe the placements of the retainers and remove from there. See graphic. Use melting glue if the fabric unintentionally is removed from the panel.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
WARNING
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.
WARNING
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
NOTE
Carefully observe the placements of the retainers and remove from there. See graphic. Use melting glue if the fabric unintentionally is removed from the panel.

Scheme 53

Scheme 53: Headlining trim panel, replace (with sunroof) 4D
Scheme 53: Headlining trim panel, replace (with sunroof) 4D
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. WARNING: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. WARNING: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. Preliminary Procedure Disable the SIR system. Refer to SIR DISABLING AND ENABLING . Remove the sunshade. Refer to SUNSHADE REPLACEMENT . Remove the sunshade supports. Refer to SUNSHADE SUPPORT REPLACEMENT . Remove the roof rail front assist handles. Refer to ROOF RAIL FRONT ASSIST HANDLE REPLACEMENT . Remove the windshield side garnish moldings. Refer to WINDSHIELD SIDE GARNISH MOLDING REPLACEMENT . Remove the center pillar upper garnish moldings. Refer to CENTER PILLAR UPPER GARNISH MOLDING REPLACEMENT . Remove the body lock pillar upper trim panel. Refer to C-pillar upper trim panel, replace 4D . Remove the reading lamp assembly. Refer to READING LAMP REPLACEMENT . Remove the front side door, passenger side. Refer to FRONT SIDE DOOR REPLACEMENT . Remove the front passenger seat. Refer to DRIVER OR PASSENGER SEAT REPLACEMENT (8-WAY-POWER) or DRIVER OR PASSENGER SEAT REPLACEMENT (2/4/6-WAY HYBRID, 6-WAY HYBRID SPORT) .
1Headlining Trim Panel Procedure Disconnect the electrical connectors.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
WARNING
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.
WARNING
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.

Scheme 54

Scheme 54: Instrument Panel Lower Trim Panel Insulator Replacement - Driver Side
Scheme 54: Instrument Panel Lower Trim Panel Insulator Replacement - Driver Side
CalloutComponent Name
1Instrument Panel Lower Trim Panel Insulator Retainer (Qty: 2) Procedure Use BO-569-A lifter to release the retainer clips securing the insulator to the instrument panel. Remove the electrical connections. Special Tools BO-569-A Plug Lifter For equivalent regional tools, refer to SPECIAL TOOLS .
2Instrument Panel Lower Trim Panel Insulator

Scheme 55

Scheme 55: Instrument Panel Outer Compartment Replacement
Scheme 55: Instrument Panel Outer Compartment Replacement
CalloutComponent Name
1Instrument Panel Outer Compartment Retainer (Qty: 2)
2Instrument Panel Outer Compartment

Scheme 56

Scheme 56: Instrument Panel Upper Trim Panel Replacement
Scheme 56: Instrument Panel Upper Trim Panel Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel lower center trim panel. Refer to INSTRUMENT PANEL LOWER CENTER TRIM PANEL REPLACEMENT . Remove the headlamp switch molding. Refer to HEADLAMP SWITCH MOLDING REPLACEMENT . Remove the turn signal multifunction switch. Refer to TURN SIGNAL MULTIFUNCTION SWITCH REPLACEMENT . Remove the windshield wiper and washer switch. Refer to WINDSHIELD WIPER AND WASHER SWITCH REPLACEMENT . Remove the hazard warning switch. Refer to HAZARD WARNING SWITCH REPLACEMENT .
1Instrument Panel Upper Trim Panel Fastener (Qty: 4) Refer to FASTENER CAUTION
2Instrument Panel Upper Trim Panel Retainer (Qty: 10) Procedure Use a flat-bladed plastic trim tool in order to release the retaining clips securing the upper trim panel to the instrument panel. NOTE: Apply protection tape on the instrument panel to prevent scratches and pressmarks on instrument panel surface. The flat-bladed plastic trim tool and retainers may cause damage.
3Instrument Panel Upper Trim Panel
NOTE
Apply protection tape on the instrument panel to prevent scratches and pressmarks on instrument panel surface. The flat-bladed plastic trim tool and retainers may cause damage.

Scheme 57

Scheme 57: Instrument Cluster Head-Up Display Bezel Replacement
Scheme 57: Instrument Cluster Head-Up Display Bezel Replacement
1Instrument Cluster Head Up Display Bezel Procedure Remove the head up display assembly bezel clips (Qty: 6).

Scheme 58

Scheme 58: Instrument Panel Outer Trim Cover Replacement - Right Side
Scheme 58: Instrument Panel Outer Trim Cover Replacement - Right Side
CalloutComponent Name
1Instrument Panel Outer Trim Cover Procedure Remove the cover carefully with a suitable tool. Disconnect the electrical connector. Transfer any parts as needed.

Scheme 59

Scheme 59: Instrument Panel Outer Trim Cover Replacement - Left Side
Scheme 59: Instrument Panel Outer Trim Cover Replacement - Left Side
CalloutComponent Name
1Instrument Panel Outer Trim Cover Procedure Remove the cover carefully with a suitable tool.

Scheme 60

Scheme 60: Instrument Panel Lower Center Trim Panel Replacement
Scheme 60: Instrument Panel Lower Center Trim Panel Replacement
CalloutComponent Name
Preliminary Procedure Remove the front floor console cover. Refer to FRONT FLOOR CONSOLE COVER REPLACEMENT .
1Instrument Panel Lower Center Trim Panel Fastener Refer to FASTENER CAUTION .
2Instrument Panel Lower Center Trim Panel Procedure Use a flat-bladed plastic trim tool in order to release the retaining clips securing the upper center trim panel to the instrument panel. Disconnect the electrical connectors. If replacing the lower center trim panel, transfer parts as necessary. NOTE: Apply protecting tape on the upper right corner between the Lower Center Trim Panel and Instrument Panel Upper Trim Panel to prevent paint peel of.
NOTE
Apply protecting tape on the upper right corner between the Lower Center Trim Panel and Instrument Panel Upper Trim Panel to prevent paint peel of.

Scheme 61

Scheme 61: Glove compartment, Replacement
Scheme 61: Glove compartment, Replacement
CalloutComponent Name
Preliminary Procedure Remove the right outer trim cover. Refer to INSTRUMENT PANEL OUTER TRIM COVER REPLACEMENT - RIGHT SIDE .
1Instrument Panel Compartment Assembly Fastener (Qty: 4) Refer to FASTENER CAUTION . Procedure Disconnect the electrical connectors.
2Instrument Panel Compartment Assembly

Scheme 62

Scheme 62: Instrument Panel Compartment Door Assembly Replacement (Left Hand Drive)
Scheme 62: Instrument Panel Compartment Door Assembly Replacement (Left Hand Drive)
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment. Refer to Glove compartment, Replacement .
1Instrument Panel Compartment Door Dampener Connector
2Instrument Panel Compartment Door Hinge Pin (Qty: 2) Procedure Release and pull off the door hinge pin.
3Instrument Panel Compartment Door Assembly

Scheme 63

Scheme 63: Headlamp Switch Molding Replacement
Scheme 63: Headlamp Switch Molding Replacement
CalloutComponent Name
1Headlamp Switch Molding Procedure Disconnect the electrical connectors. If replacing the headlamp switch molding, transfer any parts as needed. NOTE: Use a flat-bladed plastic trim tool to release the headlamp switch molding from the instrument panel.
NOTE
Use a flat-bladed plastic trim tool to release the headlamp switch molding from the instrument panel.

Scheme 64

Scheme 64: Instrument Panel Molding Replacement - Passenger Side
Scheme 64: Instrument Panel Molding Replacement - Passenger Side
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment. Refer to Glove compartment, Replacement .
1Instrument Panel Molding Procedure Release the retainers by pressing them out from the backside.

Scheme 65

Scheme 65: Dash Panel Brace Replacement
Scheme 65: Dash Panel Brace Replacement
CalloutComponent Name
Preliminary Procedure Remove the plenum water deflector. Refer to PLENUM WATER DEFLECTOR REPLACEMENT .
1Dash Panel Brace Fastener (Qty: 4) Refer to FASTENER CAUTION . Tighten 22 Nm (16 lb ft)
2Dash Panel Brace

Scheme 66

Scheme 66: Instrument Panel Assembly Replacement
Scheme 66: Instrument Panel Assembly Replacement
CalloutComponent Name
Preliminary Procedure Refer to SIR WARNING . Disable the SIR system. Remove the radio assembly. Refer to RADIO REPLACEMENT . Remove the HVAC remote control assembly. Refer to HEATER AND AIR CONDITIONING REMOTE CONTROL REPLACEMENT . Remove the radio front speaker. Refer to RADIO FRONT SPEAKER REPLACEMENT . Remove the front floor console. Refer to FRONT FLOOR CONSOLE REPLACEMENT . Remove the steering column trim covers. Refer to STEERING COLUMN TRIM COVER REPLACEMENT . Remove the instrument cluster. Refer to INSTRUMENT CLUSTER REPLACEMENT . Remove both windshield side garnish moldings. Refer to WINDSHIELD SIDE GARNISH MOLDING REPLACEMENT .
1Instrument Panel Assembly Fastener (Qty: 7) Refer to FASTENER CAUTION . Tighten 9 Nm (80 lb in)
2Instrument Panel Assembly Procedure Disconnect the wiring harness from the I/P assembly. With the aid of an assistant, remove the I/P assembly from the vehicle. If replacing the I/P assembly, transfer all necessary components.

Scheme 67

Scheme 67: Instrument Panel Tie Bar Replacement
Scheme 67: Instrument Panel Tie Bar Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel (I/P) assembly. Refer to INSTRUMENT PANEL ASSEMBLY REPLACEMENT . Remove both front and rear side door still trim plates. Refer to FRONT AND REAR SIDE DOOR SILL TRIM PLATE REPLACEMENT . Remove the steering column. Refer to STEERING COLUMN REPLACEMENT . Remove the body control module bracket. Refer to BODY CONTROL MODULE REPLACEMENT (RIGHT HAND DRIVE) or BODY CONTROL MODULE REPLACEMENT (LEFT HAND DRIVE) .
1Instrument Panel Tie Bar Assembly Fastener (Qty: 10) Refer to FASTENER CAUTION . Tighten 22 Nm (16 lb ft)
2Heater and Air Conditioning Evaporator and Blower Module Fastener (Qty: 3) Procedure Release the heater and air conditioning evaporator and blower module from the I/P tie bar and secure the module at the body. Tighten 5 Nm (44 lb in)
3Instrument Panel Tie Bar Assembly Procedure Remove the hood release handle. Note location and routing of the I/P wiring harness prior to removal of the I/P tie bar assembly to ensure proper reinstallation. Disconnect the wiring harness from the I/P tie bar assembly. With the aid of an assistant, remove the I/P tie bar assembly from the vehicle. If replacing the I/P tie bar assembly, transfer all necessary components.
