Points to remember

  1. Observe the test conditions. Use common sense in assessing the readings.
  2. The test readings presented are taken with the ignition switched ON unless otherwise stated.
  3. Start by checking that the control module is receiving power and is grounded.
  4. Check all sensor inputs and signals from other systems.
  5. Finally, check the control module outputs. Remember that the readings do not provide an indication that the actuator is operating.
  6. If any reading is not OK, consult the wiring diagram to trace the leads, connectors or components that need further checking.
  7. The specified readings are valid for a correctly calibrated Fluke 88/97.
  8. The readings %(+) and ms(+) indicate the pulse ratio and pulse length. A test instrument capable of measuring both pulse ratio and pulse length must be used. The "+" sign denotes a positive trigger pulse (TRIG+).

Scheme 306

Scheme 306: Control module connections
Scheme 306: Control module connections
IMPORTANTBOB cable assemblies have not been produced for ABS 5.3, ABS 5.4 or TC/ABS 5.3. Unless otherwise stated, the test readings are those that should be obtained on the control module connector (unplugged). For TC/ABS 5.3, certain readings can be taken with the BOB cable assembly connected to the Trionic T7 control module, see the notes under TEST READING .

= greater than; < = less than; ~ = alternating current (LP: LOGIC PROBE P = select pulse; p = visible pulse)

PinCable colourComponent/functionIn/OutTest conditionsTest acrossTest readingSee
1WHWheel sensor, RR: Reference groundInRotate the wheel one turn per second1--2100 mV ACREAR-WHEEL SENSORS
2VTWheel sensor, RR: Signal inputInRotate the wheel one turn per second2-1100 mV ACREAR-WHEEL SENSORS
3GNWheel sensor, FR: Reference groundInRotate the wheel one turn per second3--5100 mV ACFRONT-WHEEL SENSORS
4Spare
5GYWheel sensor, FR: Signal inputInRotate the wheel one turn per second5-3100 mV ACFRONT-WHEEL SENSORS
6BUWheel sensor, FL: Reference groundInRotate the wheel one turn per second6--7100 mV ACFRONT-WHEEL SENSORS
7VTWheel sensor, FL: Signal inputInRotate the wheel one turn per second7-6100 mV ACFRONT-WHEEL SENSORS
8BKWheel sensor, RL: Reference groundInRotate the wheel one turn per second8--9100 mV ACREAR-WHEEL SENSORS
9YEWheel sensor, RL: Signal inputInRotate the wheel one turn per second9-8100 mV ACREAR-WHEEL SENSORS
10Spare
11GNData linkIn/OutTech 2 not connected11-B0 V
Tech 2 connected and TC/ABS selected for communication11-BAbout 10 V
12Spare
13Spare
14GN/GYBrake light switchInBrake pedal depressed14-BB+BRAKE-LIGHTS SWITCH
Brake pedal released14-B0 V
15RD/BUCurrent (+15 circuit)In15-BB+POWER SUPPLY
16BKPump motor groundInB+-16B+RETURN PUMP, ABS FUNCTION
17RDCurrent (+30 circuit)In17-BB+POWER SUPPLY
18RDCurrent (+30 circuit)In18-BB+POWER SUPPLY
19BKGroundInB+-19B+CONTROL MODULE GROUND
20Spare
21Spare
22Spare
23GNSignal from wheel sensor, rear left Used by special equipmentOutRotate the wheel one turn per second100 mV AC
24Signal from wheel sensor, rear right Used by special equipmentOutRotate the wheel one turn per second100 mV AC
25Spare
26Spare
27Spare
28Spare
29WHCAN-LBus informationCannot be measured
30GNCAN-HBus informationCannot be measured
31PKSwitch, TCS ON/OFFInSwitch not depressedB+-310 VSWITCH, TCS ON/OFF
Switch depressedB+-31B+

CONTROL MODULE CONNECTIONS REFERENCE

Scheme 307

Scheme 307: System Overview
Scheme 307: System Overview
  1. «REAR-WHEEL SENSORS»(ref-212253-S08248000662005122300000) (298R).
  2. «FRONT-WHEEL SENSORS»(ref-212253-S35939552152005122300000) (298F).
  3. «HYDRAULIC UNIT»(ref-212253-S02322159682005122300000) including «CONTROL MODULE»(ref-212253-S25364812622005122300000) valve housing and return pump (382).
  4. Engine control module
  5. Switch, TCS (449)
  6. Main instrument unit, MIU (540)
  7. «DIAGNOSTICS COMMUNICATION»(ref-212253-S35630459882005122300000) (445).

Scheme 308

Scheme 308: Main Components
Scheme 308: Main Components
  1. Hydraulic unit with control module, valve housing and return pump (382)
  2. Hydraulic unit (540)
  3. Speed sensor, front right
  4. Speed sensor, front left
  5. Speed sensor, rear right
  6. Speed sensor, rear left
  7. Switch, TCS
