ECM (TRIONIC T7)

Checking For Leaks (9-3)

1. Inspect the pressurizing equipment to make sure there are no leaks and that it is fault-free.
2. Make sure that the filler cap is screwed on tightly.
3. Install a service port if the car is not already equipped with one. (Scheme 333)
4. Connect the Pressurizing Equipment (J41413) to the service port at the EVAP canister purge valve.
5. Activate the EVAP shut-off valve with the diagnostics tool. Select the "ACTIVATE" menu. Select "ACTIVATE SHUT-OFF VALVE".
6. Pressurize the system and perform a leakage test as described in the Kent-Moore instruction manual.

Scheme 333

Checking For Leaks (9-5)

1. Inspect the pressurizing equipment to make sure it is not leaking or defective.
2. Make sure the filler cap is securely screwed on.
3. Connect the Pressurizing Equipment (J41413) to the service port at the EVAP canister purge valve in the engine bay. (Scheme 334)
4. Activate the EVAP emission canister shut-off valve with the diagnostic tool. Select the "ACTIVATE" menu. Select "ACTIVATE SHUT-OFF VALVE".
5. Pressurize the system and test for leaks as described in the Kent-Moore manual.

Scheme 334

Procedure: Leak Detected (All Models)

1. The shut-off valve must still be activated.
2. Detach the line from the purge valve on the intake manifold.
3. Pressurize the system further as described in the Kent-Moore instruction manual.
4. Detect the leak with the Ultrasonic Leak Detector (J41416). Start from the line detached from the intake manifold and work through the lines and components in the system. Perform a visual inspection at the same time.
5. Adjust the sensitivity of the detector to filter out ambient, in many cases, interfering noise.
6. When the leak has been detected and rectified, check the integrity of the system again.
7. Restore the car to its original state.

Scheme 335

Scheme 336
