Connected components
| 1 | Battery |
|---|---|
| 382 | Control module, TC-ABS (signal ground) via crimp J4 |
| 547 | Control module, ABS (signal ground) via crimp connection J4 |
CONNECTED COMPONENTS
Scheme 90
Scheme 91
Location: In the engine bay on the side panel in front of the left-hand wheel housing
| G40 | Grounding point in cabin on left-hand side of knee protection bar (LHD) |
|---|---|
| G42 | Grounding point in cabin on right-hand side of knee protection bar (RHD) |
| 326 | Secondary air injection pump motor |
| Via crimp J2 | |
| 63a | Headlamp washer-fluid pump motor |
| 66FL | Headlamp wiper motor, LH |
| 119FL | Side reversing light, LH |
| 275 | Anti-theft alarm siren |
| 280FL | Headlamp beam adjustment motor, LH |
| 382 | TC/ABS control module |
| 432 | Washer fluid pump relay |
| 547 | Control module, ABS |
| Via crimp J3 | |
| 11FL | Main beam bulb, LH |
| 12FL | Dipped beam bulb, LH |
| 13FL | Front parking light bulb, LH |
| 27FL | Front direction indicator bulb, LH |
| 37LH | Left radiator fan motor (via relay 81) |
| 37RH | Right radiator fan motor |
| 40LH | Horn, LH |
| 40RH | Horn, RH |
| 63b | Windscreen washer fluid pump motor |
| 195 | Washer fluid level switch |
| 228b | Filament monitor relay |
| 234FL | Side marker light bulb, LH |
| 367 | 2-stage radiator fan resistor |
| Via crimp J137 , which is in turn connected to crimp J2 | |
| 85FL | Fog light lamp, LH |
| 85FR | Fog light lamp, LH |
CONNECTED COMPONENTS
Scheme 92
Scheme 93
Location: In passenger compartment on left-hand side of knee member.
