SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Compressor Type | Nippondenso 7SB16 7-Cyl. | |
| Compressor Drive Belt Tension | (1) | |
| System Oil Capacity | (2) 4.9 ozs. | |
| Refrigerant (R-134a) Capacity | 33-34 ozs. | |
| System Operating Pressures (3) | ||
| High Side | (4) | |
| Low Side | 21.8-36.3 psi (1.5-2.6 kg/cm 2 ) | |
| (1) Belt tension is controlled by an automatic tensioner. Ensure mark on belt tension is between marks on tensioner mount. After applying 40 lbs. (178 N) to drive belt, tensioner should smoothly return to tensioned position. (2) Use ND8 SK-20. Compressor is shipped with 4.9 ounces of refrigerant oil. (3) Specification is with ambient temperature at approximately 68-77°F (20-25°C) and warm engine operating at 1500-2000 RPM. (4) High-side pressure varies depending on system load. | ||
| (1) | Belt tension is controlled by an automatic tensioner. Ensure mark on belt tension is between marks on tensioner mount. After applying 40 lbs. (178 N) to drive belt, tensioner should smoothly return to tensioned position. |
| (2) | Use ND8 SK-20. Compressor is shipped with 4.9 ounces of refrigerant oil. |
| (3) | Specification is with ambient temperature at approximately 68-77°F (20-25°C) and warm engine operating at 1500-2000 RPM. |
| (4) | High-side pressure varies depending on system load. |
SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Accelerator Pedal | 18 (24) |
| A/C Pressure Sensor | 13 (18) |
| Compressor Mounting Bolts | 18 (24) |
| Compressor Pressure Hose Connection | 15 (20) |
| Compressor Clutch Shaft Bolt | 10 (14) |
| Steering Wheel Center Nut | 29 (39) |
| Steering Column-To-Steering Gear Pinch Bolt | 22 (30) |
| Steering Column Mounting Bolts | 22 (30) |
| INCH Lbs. (N.m) | |
| Condenser Lines | 71 (8) |
| Expansion Valve-To-Evaporator Screws | 44 (5) |
| Expansion Valve Line Connection | 71 (8) |
| Receiver-Drier Line Connection | 71 (8) |
| Wiper Assembly Bolts | 71 (8) |
TORQUE SPECIFICATIONS
