Wheel & Tires: Overview Saab 9-4X I

Tire Pressure Monitor Description and Operation

The tire pressure monitor (TPM) system warns the driver when a significant loss, or gain of tire pressure occurs in any of the 4 tires. It allows the driver to display the individual tire pressures and their locations on the driver information center.

The system uses the body control module (BCM), driver information center (DIC), instrument cluster, a radio frequency (RF) transmitting pressure sensor in each wheel/tire assembly, and the serial data circuit to perform the system functions. Each sensor has an internal power supply with an approx. 10 year service life.

When the car is stationary, every sensor's internal accelerometer is inactive, which sets the sensors to sleep mode. In this mode, the sensors read the pressure every 30 seconds and do not transmit signals unless the pressure changes. When the car then starts, the internal accelerometers are activated by centrifugal force and the sensors switch to Drive mode. In this mode, the sensors sample tire pressure once every 30 seconds and transmit in Drive mode once every 60 seconds. The BCM receives and translates the data contained in each sensors RF transmission into sensor presence, sensor mode, and tire pressure. The BCM sends the tire pressure and tire location data to the driver information center via the serial data circuit where they are displayed.

The sensors continuously compare their last pressure sample to their current pressure sample and will transmit in re-measure mode if a 8.3 kPa (1.2 psi) change in tire pressure has been detected in either a stationary state or Drive mode. When the tire pressure monitoring system detects a significant loss, or gain of tire pressure, the tire pressure monitor indicator icon is illuminated on the instrument cluster and if equipped, a check tire pressure type message is displayed on the driver information center. Both the indicator icon and the message can be cleared by adjusting the tire pressures to the recommended kPa/psi and driving the vehicle above 40 km/h (25 mph) for at least 2 minutes.

If power is disconnected from the BCM or if the vehicle battery is disconnected each TPM sensor ID is retained but all of the tire pressure information is lost. Under these circumstances the BCM cannot assume that the tire pressures were maintained over an unknown period of time. If equipped, the driver information center will display all dashes and the scan tool will indicate a default tire pressure value of 1020 kPa (148 psi) for each tire. Driving the vehicle above 40 km/h (25 mph) for at least 2 minutes will activate the sensors causing the driver information center to display the current tire pressures. The special tool EL-46079/J-46079 or EL-50448 activation tool for tire pressure sensors may also be used to activate the sensors.

The BCM can record faults in the tire pressure monitoring system. If a DTC is recorded, the control lamp symbol for tire pressure monitoring in the instrument cluster flashes for 1 minute and then stays on once the ignition has been switched ON and the instrument cluster's bulb check has been completed. Any malfunction detected will cause the driver information center to display a service tire monitor system type message. For more information on other functions of the BCM, refer to KEYLESS ENTRY SYSTEM DESCRIPTION AND OPERATION (WITHOUT ATH) and KEYLESS ENTRY SYSTEM DESCRIPTION AND OPERATION (WITH ATH) .

Scheme 1

Most GM vehicles are equipped with steel belted all-season radial tires as standard equipment. These tires qualify as snow tires, with a higher than average rating for snow traction than the non-all season radial tires previously used. Other performance areas, such as wet traction, rolling resistance, tread life, and air retention, are also improved. This is done by improvements in both tread design and tread compounds. These tires are identified by an M + S molded in the tire side wall after the tire size. The suffix MS is also molded in the tire side wall after the TPC specification number.

The optional handling tires used on some vehicles now also have the MS marking after the tire size and the TPC specification number.

General Description

The factory installed tires are designed to operate satisfactorily with loads up to and including the full rated load capacity when these tires are inflated to the recommended pressures.

The following factors have an important influence on tire life

1. Correct tire pressures
2. Correct wheel alignment
3. Proper driving techniques
4. Tire rotation

The following factors increase tire wear

1. Heavy cornering
2. Excessively rapid acceleration
3. Heavy braking

Metric Wheel Nuts and Bolts Description

Metric wheel/nuts and bolts are identified in the following way

1. The wheel/nut has the word Metric stamped on the face.
2. The letter M is stamped on the end of the wheel bolt.

The thread sizes of metric wheel/nuts and the bolts are indicated by the following example: M12 x 1.5.

1. M = Metric
2. 12 = Diameter in millimeters
3. 1.5 = Millimeters gap per thread

Scheme 2

Replacement tires should be of the same tire performance criteria (TPC) specification number. This will ensure the same size, the same load range, and the same construction as those originally installed on the vehicle.

Replacement Wheels Description

Replace the wheel if any of the following conditions exist

1. The wheel exhibits excessive runout.
2. The wheel is bent.
3. The wheel is cracked.
4. The wheel is severely corroded.
5. NOTE: Air leaks caused by porosity on aluminum wheels are repairable. The wheel leaks air. WARNING: If you are replacing the wheel(s), the wheel stud(s), the wheel nut(s) or the wheel bolt (s), install only new GM original equipment parts. Installation of used parts or non-GM original equipment parts may cause the wheel to loosen, loss of tire air pressure, poor vehicle handling and loss of vehicle control resulting in personal injury.

Replace the wheel, the wheel studs and the wheel/nuts, or the wheel bolts if applicable, if any of the following conditions exist

1. The wheel has elongated bolt holes.
2. The wheel/nuts, or bolts if applicable, loosen repeatedly.

Aluminum wheel identification is cast into the inboard side of the wheel.

Tire Inflation Description

This vehicle has been engineered to operate up to the stated load capacity with wheel and tire assemblies of the type, size, construction, and configuration as originally installed. Maintenance of the tire inflation pressures is critical to the continued satisfactory performance, handling, and operating economy of the vehicle. Operation with incorrectly or improperly inflated tires can adversely affect vehicle performance and may contribute to the following

1. Reduced fuel economy
2. Tire overloading
3. Shortened tire life
4. Excessive tire wear
5. Uneven tire wear
6. Vehicle handling concerns

Inspect the tire pressures when the vehicle has not been driven for at least 3 hours or not more than 1.6 km (1 mi) and when the tires are cool to the touch.

Tire inflation pressures should be inspected monthly and before an extended trip and adjusted to meet the specifications listed for the particular vehicle. Replace any missing or damaged tire valve stem extensions and/or caps to prevent the intrusion of water and contaminates.

One pound per square inch (psi) equals 6.9 Kilopascals (kPa). The following table illustrates the conversion of Kilopascals to pounds per square inch

Lead/Pull Description

At a constant highway speed on a typical straight road, lead/pull is the amount of effort required at the steering wheel to maintain the vehicle's straight path.

Lead/pull is usually caused by the following factors

1. Road slope
2. Variability in tire construction
3. Wheel alignment (front cross caster and camber)
4. Unbalanced steering gear
5. Electronic Power Steering (EPS) steering position and torque sensors not calibrated correctly, if equipped.

Memory Steer Description

Memory steer is when the vehicle wants to lead or pull in the direction the driver previously turned the vehicle. Additionally, after turning in the opposite direction, the vehicle will want to lead or pull in that direction.

Scrub Radius Description

Ideally, the scrub radius is as small as possible. Normally, the SAI angle and the centerline of the tire and the wheel intersect below the road surface, causing a positive scrub radius. With struts, the SAI angle is much larger than the long arm/short arm type of suspension. This allows the SAI angle to intersect the camber angle above the road surface, forming a negative scrub radius. The smaller the scrub radius, the better the directional stability. Installing aftermarket wheels that have additional offset will dramatically increase the scrub radius. The newly installed wheels may cause the centerline of the tires to move further away from the spindle. This will increase the scrub radius.

A large amount of scrub radius can cause severe shimmy after hitting a bump. Four-wheel drive vehicles with large tires use a steering damper to compensate for an increased scrub radius. Scrub radius is not directly measurable by the conventional methods. Scrub radius is projected geometrically by engineers during the design phase of the suspension.

Scheme 3

The front wheels aim or steer the vehicle. The rear wheels control tracking. This tracking action relates to the thrust angle (3). The thrust angle is the path that the rear wheels take. Ideally, the thrust angle is geometrically aligned with the body centerline (2).

In the illustration, toe-in is shown on the left rear wheel, moving the thrust line (1) off center. The resulting deviation from the centerline is the thrust angle.

If the thrust angle is not set properly the vehicle may "dog track", the steering wheel may not be centered or it could be perceived as a bent axle. Thrust angle can be checked during a wheel alignment.

Positive thrust angle means the thrust line is pointing to the right hand side (RHS) of the vehicle.

Negative thrust angle means the thrust line is pointing to the left hand side (LHS) of the vehicle.

If the thrust angle is out of specification, moving the axle to body relationship will change the thrust angle reading.

If the vehicle is out in the Positive (+) direction-moving the RHS forward and/or LHS rearward will move the thrust angle towards zero degrees.

If the vehicle is out in the Negative (-) direction-moving the RHS rearward and/or LHS forward will move the thrust angle towards zero degrees.

Scheme 4

Toe is a measurement of how much the front and/or rear wheels are turned in or out from a straight-ahead position. When the wheels are turned in, toe is positive (+). When the wheels are turned out, toe is negative (-). The actual amount of toe is normally only a fraction of a degree. The purpose of toe is to ensure that the wheels roll parallel.

Toe also offsets the small deflections of the wheel support system that occur when the vehicle is rolling forward. In other words, with the vehicle standing still and the wheels set with toe-in, the wheels tend to roll parallel on the road when the vehicle is moving.

Improper toe adjustment will cause premature tire wear and cause steering instability.

Scheme 5

A vehicle pulls or leads in one direction during hard acceleration. A vehicle pulls or leads in the other direction during deceleration.

The following factors may cause torque steer to be more apparent on a particular vehicle

1. A slightly smaller diameter tire on the right front increases a right torque lead. Inspect the front tires for differences in the brand, the construction, or the size. If the tires appear to be similar, change the front tires from side-to-side and retest the vehicle. Tire and wheel assemblies have the most significant effect on torque steer correction.
2. A large difference in the right and left front tire pressure
3. Left-to-right differences in the front view axle angle may cause significant steering pull in a vehicle. The pull will be to the side with the most downward sloping axle from the differential to the wheels. Axles typically slope downward from the differential. The slope of the transaxle pan to level ground may be used as an indication of bias axle angles. The side with the higher transaxle pan (shown on the left side of the illustration) has the most downward sloping axle angle.

Wander Description

Wander is the undesired drifting or deviation of a vehicle to either side from a straight path with hand pressure on the steering wheel. Wander is a symptom of the vehicle's sensitivity to external disturbances, such as road crown and crosswind, and accentuated by poor on-center steering feel.

Scheme 6

1. Under-Inflation, Hard Cornering, Lack of Regular Rotation
2. Incorrect Wheel Alignment, Hard Cornering, Lack of Regular Rotation
3. Incorrect Wheel Alignment
4. Over-Inflation, Heavy Acceleration, Lack of Regular Rotation
5. Normal Wear to the Wear Indicator

Circuit/System Description

If the tire type and pressure selection information is not entered with the scan tool during the body control module (BCM) setup, the tire pressure monitor indicator icon on the instrument panel cluster (IPC) will flash for 1 minute and then remain illuminated after the ignition switch is cycled ON and the IPC bulb check is complete. If equipped, the driver information center (DIC) will also display a service tire monitor type message. Under these circumstances, DTC C0569 will be set and the tire type and pressure information will need to be entered for the system to function correctly.

Description and Operation

TIRE PRESSURE MONITOR DESCRIPTION AND OPERATION

The tire pressure monitor (TPM) system has a radio frequency (RF) transmitting pressure sensor in each wheel/tire assembly. As vehicle speed increases, centrifugal force closes the sensors internal roll switch, which puts the sensor into Rolling mode. The body control module (BCM) receives and translates the data contained in the tire pressure sensor RF transmissions into sensor presence, sensor mode, and tire pressure. Once vehicle speed is greater than 40km/h (25 mph), the BCM waits for the first sensor to go into Rolling mode, then checks if all sensors have gone into Rolling mode. If one or more sensors do not go into these modes, or do not transmit at all, the BCM will set DTC C0750, C0755, C0760, or C0765 respectively.

TIRE PRESSURE MONITOR DESCRIPTION AND OPERATION

If the tire pressure sensor learn procedure has not been performed, the tire pressure monitor indicator icon on the instrument panel cluster (IPC) will flash for 1 minute and then remain illuminated after the ignition switch is cycled ON and the IPC bulb check is complete. If equipped, the driver information center (DIC) will also display a service tire monitor type message. Under these circumstances, DTC C0775 will be set and the tire pressure sensor learn procedure will need to be performed for the system to function correctly.

TIRE PRESSURE MONITOR DESCRIPTION AND OPERATION

The body control module (BCM) receives a radio frequency (RF) transmission from each tire pressure sensor. Each sensor has its own unique identification (ID) code, which it transmits as part of each RF message, that must be learned into the BCM memory. Once all 4 IDs have been learned and vehicle speed is greater than 40 km/h (25 mph), the BCM continuously compares IDs in received transmission to its learned IDs to determine if all 4 sensors are present. If the BCM detects a low tire pressure condition or a malfunction in the system, it will send a serial data message to the instrument panel cluster (IPC) requesting the appropriate tire pressure monitor indicator illumination and also to display the appropriate data message on the driver information center (DIC), if equipped.

TIRE PRESSURE MONITOR DESCRIPTION AND OPERATION

Relearn Mode Description

The tire pressure monitoring system (TPM) uses the instrument panel cluster (IPC), the body control module (BCM), 4 pressure sensors transmitting on radio frequency and the serial data circuit to execute the functions in TPM relearn mode. Sensor relearning must be executed after each tire change, BCM change or sensor change. When relearn mode has been enabled, the respective sensors' unique identification codes can be learned in the BCM memory. When a sensor ID has been learned, the BCM sounds a horn chirp indicating the sensor has transmitted its ID and the BCM has received and learned it. The BCM must learn the sensor IDs in the proper sequence to determine correct sensor location. The first learned ID is assigned to the left front location, the second to right front, the third to right rear and the fourth to left rear. The turn signals will individually illuminate indicating which location is to be learned in the proper sequence.

SYMPTOM DESCRIPTION

Customer complaints of leaking tires/rims, regardless of whether a tire repair kit is used or not.
