Scheme 22
| Callout | Component Name |
|---|---|
| 1 | Sunroof Air Deflector Retainer Screws (Qty: 3) Refer to CAUTION: RETAINER . Procedure Open the front sunroof window. Push down on the air deflector to expose the screws. Release sunroof air deflector from the retainer clips. Tighten 6 Nm(53 lb in) |
| 2 | Sunroof Air Deflector Bracket (Qty: 2) Procedure Rotate the entire air deflector to almost vertical position. Release the air deflector from the bracket and remove the air deflector. |
| 3 | Sunroof Air Deflector NOTE: Put the air deflector arms into the brackets first then install the front part of the air deflector to the clips. |
| NOTE |
|---|
| Put the air deflector arms into the brackets first then install the front part of the air deflector to the clips. |
