Power Windows - Service Information: Other RAM Pickup 3500

WINDOW MOTOR

Window motors use permanent type magnets. The B+ and ground applied at the motor terminal pins will cause the motor to rotate in one direction. Reversing current through the motor terminals will cause the motor to rotate in the opposite direction.

EXPRESS DOWN WINDOW FEATURE

This feature allows you to remotely lower both front door windows at the same time. To use this feature, press and release the UNLOCK button on the RKE transmitter and then immediately press and hold the UNLOCK button until the windows lower to the desired level or until they lower completely.

EXPRESS-UP/EXPRESS-DOWN POSSIBLE CONCERNS

Note. The battery must be fully charged or the vehicle running for proper calibration of the front door module.

Note. The following procedure must be performed anytime the power window system has been serviced in either front door or, there is a possible concern with a door module calibration.

1. Glass will not lower all the way down flush to the belt-line.
2. Glass will not raise fully; wind noise / water leak.
3. Glass will not raise automatically (expess-up) after lifting the switch to the second detent and releasing.

To clear/denormalize the door module memory, perform the following procedure

CLEAR/DENORMALIZE

1. Check and repair any door module Diagnostic Trouble Code (DTC) (s) before proceeding.
2. Using a scan tool, under the miscellaneous functions menu select (Denormalize Window/Reset ECU), and follow the directions to clear/denormalize the door module memory.

To relearn/normalize the door module memory, perform the following procedure

RELEARN/NORMALIZE

Note. The battery must be fully charged or the vehicle running before proceeding.

1. If needed, place the vehicle battery on charge or have the engine running.
2. To relearn/normalize the door module, start by raising the door glass to the full-up position by pulling up on the window switch to its second detent and hold the switch until the door glass is fully closed. Continue to hold the window switch up for two seconds after the door glass is full closed.
3. Lower the door glass to the full-down position by pushing down (depress) the window switch to its second detent and hold the switch until the door glass is fully open. Continue to hold the window switch down for two seconds after the door glass is fully open.
4. Check the operation of the express-up and express-down features.
5. If the express up does not work, repeat the procedure starting at step #2, waiting for three seconds after the window stops.
6. Check that the door glass reverses when in the express-up mode by holding a pen in the path of the glass.
7. Recheck and repair any door module DTC's as needed

Scheme 4

1. Disconnect and isolate the negative battery cable.
2. Remove door trim panel. Refer to «PANEL, Door Trim , Removal»(ref-457777-S23683841882012030200000) .
3. Remove fasteners from motor/regulator.
4. Disconnect electrical connector.
5. Remove motor/regulator from carrier plate.
