AS68RC AUTOMATIC

CAUTIONIf replacing a engine mount/bracket, be certain to inspect all other engine mounts/brackets in the system. Failure to follow this caution may result in damage to the vehicle.

Scheme 649

Scheme 649
Scheme 649

Scheme 650

Scheme 650
Scheme 650

Scheme 651

Scheme 651
Scheme 651

Scheme 652

Scheme 652
Scheme 652
  1. Raise the vehicle on a hoist.
  2. Position a transmission jack in place.
  3. Remove the rear transmission mount to crossmember nuts (1).
  4. Remove nuts (4) securing the rear transmission mount.
  5. Using the transmission jack, raise the transmission.
  6. Remove the rear transmission mount (2).
  7. With the transmission raised, remove bolts (1) from the transmission mount support bracket to transmission.
  8. Remove the bolts (1) and the transmission support bracket (2).

Scheme 653

Scheme 653: G 56 MANUAL
Scheme 653: G 56 MANUAL
CAUTIONIf replacing a engine mount/bracket, be certain to inspect all other engine mounts/brackets in the system. Failure to follow this caution may result in damage to the vehicle.
  1. Raise the vehicle on a hoist.
  2. Position transmission jack in place.
  3. Remove nuts securing transmission mount to crossmember.
  4. Raise the transmission.
  5. Remove bolts (1) and the rear transmission mount (2).

Scheme 654

Scheme 654: 68RFE AUTOMATIC
Scheme 654: 68RFE AUTOMATIC

Note. 4x4 Models.

CAUTIONIf replacing a engine mount/bracket, be certain to inspect all other engine mounts/brackets in the system. Failure to follow this caution may result in damage to the vehicle.

Scheme 655

Scheme 655
Scheme 655

Scheme 656

Scheme 656
Scheme 656
  1. Raise the vehicle on a hoist.
  2. Position a transmission jack in place.
  3. Remove nuts securing transmission mount to crossmember.
  4. Raise the transmission.
  5. Remove bolts (1) and the rear transmission mount (2). NOTE: 4x2 Regular Cab Models. CAUTION: If replacing a engine mount/bracket, be certain to inspect all other engine mounts/brackets in the system. Failure to follow this caution may result in damage to the vehicle.
  6. Raise the vehicle on a hoist.
  7. Position a transmission jack in place.
  8. Remove nuts securing transmission mount to crossmember.
  9. Raise the transmission.
  10. Remove bolts (1) and the rear transmission mount (2). NOTE: 4x2 Crew and Mega Cab Models. CAUTION: If replacing a engine mount/bracket, be certain to inspect all other engine mounts/brackets in the system. Failure to follow this caution may result in damage to the vehicle.
  11. Raise the vehicle on a hoist.
  12. Position a transmission jack in place.
  13. Remove nuts securing transmission mount to crossmember.
  14. Raise the transmission.
  15. Remove bolts (1) and the rear transmission mount (2).
CAUTIONIf replacing a engine mount/bracket, be certain to inspect all other engine mounts/brackets in the system. Failure to follow this caution may result in damage to the vehicle.
  1. Position the transmission mount support bracket (2). Install bolts (1) finger tight.
  2. With the transmission raised, install the transmission mount support bracket to transmission bolts (1) and tighten to 54 N.m (40 ft. lbs.).
  3. Tighten the side support bracket bolts (1) to 55 N.m (41 ft. lbs.).
  4. Install the rear transmission mount (2). Tighten nuts (1) to 47 N.m (35 ft. lbs.).
  5. Using the transmission jack, lower the transmission onto the crossmember.
  6. Install the transmission mount to crossmember nuts (1) Tighten nuts (1) to 47 N.m (35 ft. lbs.).
  7. Remove the transmission jack.
  8. Lower the vehicle on a hoist.
