SPECIFICATIONS
| Description | Type | Part Number | Capacities | |
|---|---|---|---|---|
| U.S. | Metric | |||
| Cooling System | ||||
| Engine Coolant (3.7L and 4.7L Engines) | Mopar® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) | 1 Gallon - 05066386AA | 14 Quarts | 13 Liters |
| Engine Coolant (5.7L Engines) | Mopar® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) | 1 Gallon - 05066386AA | 16 Quarts | 15 Liters |
| Engine Coolant (6.7L HO Diesel Engines) | Mopar® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) | 1 Gallon - 05066386AA | 22.6 Quarts | 21.4 Liters |
| Engine Oil with Filter | ||||
| Engine Oil (3.7L Engines) | Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395. Refer to your engine oil filler cap for correct SAE grade. | 1 Quart - 04761872AC | 5 Quarts | 4.7 Liters |
| 5 Quarts - 04761851AD | ||||
| Engine Oil (4.7L Engines) | Mopar® API Certified SAE 5W-20 engine oil, meeting the requirements of Chrysler Material Standard MS-6395. | 1 Quart - 04761872AC | 6 Quarts | 5.7 Liters |
| 5 Quarts - 04761851AD | ||||
| Engine Oil (5.7L Engines) | Mopar® API Certified SAE 5W-20 engine oil, meeting the requirements of Chrysler Material Standard MS-6395. | 1 Quart - 04761872AC | 7 Quarts | 6.6 Liters |
| 5 Quarts - 04761851AD | ||||
| Engine Oil (6.7L HO Diesel Engines) | In ambient temperatures below 0°F (-18°C), 5W-40 synthetic engine oil that meets Chrysler Materials Standard MS-10902 and the API CJ-4 engine oil category is required. In ambient temperatures above 0°F (-18°C), 15W-40 engine oil that meets Chrysler Materials Standard MS-10902 and the API CJ-4 engine oil category is required. | 1 Quart -68024966AA | 12 Quarts | 11.4 Liters |
| 1 Gallon - 68024967AA | ||||
| Engine Oil Filter (3.7L Engine) | Mopar® Engine Oil Filter | 05184231AA | N/A | N/A |
| Engine Oil Filter (4.7/5.7L) | Mopar® Engine Oil Filter | 04884899AB | N/A | N/A |
| Engine Oil Filter (6.7L HO Diesel Engines) | Mopar® Engine Oil Filter | 05083285AA | N/A | N/A |
| Fuel (approximate) | ||||
| Fuel Selection (3.7L and 4.7L Engines) | 87 Octane Regular Cab Shortbed/Crew Quad Cab Models | N/A | 26 Gallons | 98 Liters |
| 87 Octane Regular Cab Longbed/Crew Quad Cab Models (Optional) | N/A | 32 Gallons | 121 Liters | |
| Fuel Selection (5.7L Engine) | 87 Octane Acceptable - 89 Octane Recommended Regular Cab Shortbed/Crew Quad Cab Models | N/A | 26 Gallons | 98 Liters |
| 87 Octane Acceptable - 89 Octane Recommended Regular Cab Longbed/Crew Quad Cab Models (Optional) | N/A | 32 Gallons | 121 Liters | |
| Fuel Selection (6.7L HO Diesel Engines) | 2500/3500 (Shortbed) Models | N/A | 34 Gallons | 129 Liters |
| 2500/3500 (Longbed) Models | N/A | 35 Gallons | 132 Liters | |
| Diesel Exhaust Fluid (DEF) | ||||
| 6.7L Diesel Engine | UREA | 1 Gallon - 68035704AA | 8 Gallons | 30 Liters |
| A/C Refrigerant System | ||||
| A/C Refrigerant Charge (3.7L/4.7L/5.7L Engines) | R-134a | 82300101AB | 1.624 Pounds | 0.737 Kilograms |
| A/C Refrigerant Charge (6.7L HO Diesel Engines) | R-134a | 82300101AB | 1.376 Pounds | 0.624 Kilograms |
| System fill capacity includes heater and coolant recovery bottle filled to MAX level. | ||||
| SAE 5W-30 engine oil approved to MB 229.31 or MB 229.51 may be used when SAE 5W-20 engine oil is not available. | ||||
| For 2500/3500 trucks operating under a gross combined weight rating greater than 14,000 lbs/(6,350 kg.) Use API Certified SAE 5W-30 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395. | ||||
| Use good quality diesel fuel from a reputable supplier in your vehicle. Federal law requires that you must fuel this vehicle with Ultra Low Sulfur Highway Diesel fuel (15 ppm Sulfur maximum) and prohibits the use of Low Sulfur Highway Diesel fuel (500 ppm Sulfur maximum) to avoid damage to the emissions control system. For most year-round service, No. 2 diesel fuel meeting ASTM specification D-975 Grade S15 will provide good performance. If the vehicle is exposed to extreme cold (below 20°F or -7°C), or is required to operate at colder-than-normal conditions for prolonged periods, use climatized No. 2 diesel fuel or dilute the No. 2 diesel fuel with 50% No. 1 diesel fuel. This will provide better protection from fuel gelling or wax-plugging of the fuel filters. This vehicle is fully compatible with biodiesel blends up to 5% biodiesel meeting ASTM specification D-975. | ||||
| CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. | ||||
| CAUTION |
|---|
| Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
ENGINE
| Description | Type | Part Number | Gap | |
|---|---|---|---|---|
| U.S. | Metric | |||
| Spark Plugs (3.7L Engine) | NGK R Nickel Spark Plug | 56028356AA (ZFR6F-11G) | 0.044 in | 1.10 mm |
| Spark Plugs (4.7L Engine) | BOSCH R Nickel Yttrium Spark Plug (intake side) | 05149050AB (FR9 TE2) | 0.039 in | 1.00 mm |
| BOSCH R Iridium / Platinum Spark Plug (exhaust side) | 05149888AA (FR8 T1332) | 0.050 in | 1.27 mm | |
| Spark Plugs (5.7L Engine) | NGK R Yttrium Spark Plug | 05149177AB (LZFR5C-11G) | 0.043 in | 01.10 mm |
SPARK PLUGS
| Description | Type | Part Number | Capacities | |
|---|---|---|---|---|
| U.S. | Metric | |||
| Automatic | ||||
| 42RLE - Service Fill | Mopar® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 4.0 Quarts | 3.8 Liters |
| 1 Gallon - 05013458AA | ||||
| 42RLE - Overhaul Fill | Mopar® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 8.8 Quarts | 8.3 Liters |
| 1 Gallon - 05013458AA | ||||
| 545RFE - Service Fill | Mopar® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 4X2 - 5.5 Quarts | 4X2 - 5.2 Liters |
| 1 Gallon - 05013458AA | ||||
| 1 Quart - 05013457AA | 4X4 -6.5 Quarts | 4X4 - 6.2 Liters | ||
| 1 Gallon - 05013458AA | ||||
| 545RFE - Overhaul Fill | Mopar® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 14.8 - 16.9 Quarts | 14-16 Liters |
| 1 Gallon - 05013458AA | ||||
| 68RFE - Overhaul Fill | Mopar® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 16.4 - 17.5 Quarts | 15.6-16.6 Liters |
| 1 Gallon - 05013458AA | ||||
| AS68RC - Service Fill (Ram Trucks only) | Mopar® AS68RC ATF Automatic Transmission Fluid | 1 Quart - 05189966AA | 7.2 Quarts | 6.8 Liters |
| 1 Gallon - 05189977AA | ||||
| AS68RC - Overhaul Fill (Ram Trucks only) | Mopar® AS68RC ATF Automatic Transmission Fluid | 1 Quart - 05189966AA | 13.74 Quarts | 13 Liters |
| 1 Gallon - 05189977AA | ||||
| Manual | ||||
| G56 | Mopar® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 5 Quarts | 4.7 Liters |
| 1 Gallon - 05013458AA | ||||
| GETRAG 238 | Mopar® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 4.6 Pints | 2.2 Liters |
| 1 Gallon - 05013458AA | ||||
| Dry fill capacity. Depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these figures may vary. Refer to the appropriate Service Information for the correct procedures. | ||||
| CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. | ||||
| CAUTION |
|---|
| Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
TRANSMISSION
| Description | Type | Part Number | Capacities | |
|---|---|---|---|---|
| U.S. | Metric | |||
| NV243 | Mopar® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 3.4 Pints | 1.6 Liters |
| 1 Gallon - 05013458AA | ||||
| NV271 | Mopar® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 4.0 Pints | 1.9 Liters |
| 1 Gallon - 05013458AA | ||||
| NV273 | Mopar® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 4.0 Pints | 1.9 Liters |
| 1 Gallon - 05013458AA | ||||
| BW 44-44 | Mopar® Transfer Case Lubricant | 1 Quart - 68089195AA | 3.0 Pints | 1.4 Liters |
| Approximate dry fill or fill to bottom edge of fill plug hole. | ||||
| CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. | ||||
| CAUTION |
|---|
| Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
TRANSFER CASE
| Description | Type | Part Number | Capacities | |
|---|---|---|---|---|
| U.S. | Metric | |||
| Corporate Axles | ||||
| C200F Front Axle | Mopar® Synthetic Gear Lubricant SAE 75W-140 | 1 Quart - 04874469AA | 3.5 Pints | 1.7 Liters |
| C200FE Front Axle (ANTI-SPIN) | Mopar® Synthetic Gear Lubricant SAE 75W-140 | 1 Quart - 04874469AA | 3.5 Pints | 1.7 Liters |
| C205F Front Axle | Mopar® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05010320AA | 3.4 Pints | 1.6 Liters |
| 8.25 Rear Axle | Mopar® Synthetic Gear Lubricant SAE 75W-140 | 1 Quart - 04874469AA | 4.39 Pints | 2.08 Liters |
| 8.25 Rear Axle (ANTI-SPIN) | Mopar® Synthetic Gear Lubricant SAE 75W-140 | 1 Quart - 04874469AA | 4.43 Pints | 2.1 Liters |
| 9.25 Rear Axle | Mopar® Synthetic Gear Lubricant SAE 75W-140 | 1 Quart - 04874469AA | 4.64 Pints | 2.2 Liters |
| 9.25 Rear Axle (ANTI-SPIN) | Mopar® Synthetic Gear Lubricant SAE 75W-140 | 1 Quart - 04874469AA | 4.43 Pints | 2.1 Liters |
| C213R Rear Axle | Mopar® Synthetic Gear Lubricant SAE 75W-140 | 1 Quart - 04874469AA | 4.37 Pints | 2.07 Liters |
| C213RE Rear Axle (ANTI-SPIN) | Mopar® Synthetic Gear Lubricant SAE 75W-140 | 1 Quart - 04874469AA | 4.73 Pints | 2.24 Liters |
| Dana Axles | ||||
| 186 FBI Front Axle | Mopar® Synthetic Gear Lubricant SAE 80W-90 | 1 Quart - 04874468AA | 2.11 Pints | 1.0 Liters |
| 186 FIA Front Axle | Mopar® Synthetic Gear Lubricant SAE 80W-90 | 1 Quart - 04874468AA | 2.26 Pints | 1.24 Liters |
| 216 FBI Front Axle (ANTI-SPIN) | Mopar® Synthetic Gear Lubricant SAE 80W-90 | 1 Quart - 04874468AA | 2.74 Pints | 1.3 Liters |
| 226 RBI Rear Axle | Mopar® Synthetic Gear Lubricant SAE 80W-90 | 1 Quart - 04874468AA | 4.75 Pints | 2.25 Liters |
| 226 RBI Rear Axle (ANTI-SPIN) | Mopar® Synthetic Gear Lubricant SAE 80W-90 | 1 Quart - 04874468AA | 4.75 Pints | 2.25 Liters |
| 226 RIA Rear Axle (ANTI-SPIN) | Mopar® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05010320AA | 2.85 Pints | 1.35 Liters |
| 302 RBI Rear Axle | Mopar® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05010320AA | 13.94 Pints | 6.6 Liters |
| 302 RBI Rear Axle (ANTI-SPIN) | Mopar® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05010320AA | 13.94 Pints | 6.6 Liters |
| American Axles | ||||
| 9.25 Front Axle | Mopar® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05102232AA | 4.64 Pints | 2.2 Liters |
| 9.25 Front Axle (ANTI-SPIN) | Mopar® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05102232AA | 4.22 Pints | 2.0 Liters |
| 10.5 Rear Axle | Mopar® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05102232AA | 5.28 Pints | 2.5 Liters |
| 10.5 Rear Axle (ANTI-SPIN) | Mopar® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05102232AA | 5.28 Pints | 2.5 Liters |
| 11.5 Rear Axle | Mopar® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05102232AA | 8.8 Pints | 4.2 Liters |
| 11.5 Rear Axle (ANTI-SPIN) | Mopar® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05102232AA | 8.45 Pints | 4.0 Liters |
| Magna Axles | ||||
| 275 FBI Front Axle | Mopar® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05010320AA | 10.77 Pints | 5.1 Liters |
| Chassis Systems | ||||
| Brake Master Cylinder | Mopar® Brake Fluid DOT 3, SAE J1703. | 12 oz. Bottle - 04318080AB | N/A | N/A |
| 32 oz. Bottle - 04318081AB | ||||
| Power Steering Reservoir | Mopar® Power Steering Fluid +4 | 1 Quart - 05013457AA | N/A | N/A |
| Limited-Slip Rear Axles require the addition of 118 ml (4 oz.) Mopar® Limited Slip Additive. | ||||
| If Mopar® Brake Fluid DOT 3 is not available, then Mopar® Brake and Clutch Fluid DOT 4 (P/N 04549625AC), is acceptable. | ||||
| If Mopar® Power Steering Fluid +4 is not available, then Mopar® ATF +4 Automatic Transmission Fluid (P/N 05166226AA), is acceptable. | ||||
| If equipped with Trailer Tow package use Mopar® Synthetic Gear Lubricant, SAE 75W-140 | ||||
| CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. | ||||
| CAUTION |
|---|
| Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
CHASSIS
Scheme 1
The Totally Integrated Power Module (TIPM) is located in the engine compartment near the battery. This center contains cartridge fuses and mini fuses. A description of each fuse and component may be stamped on the inside cover, otherwise the cavity number of each fuse is stamped on the inside cover that corresponds to the following chart.
| CAVITY | CARTRIDGE FUSE | MINI FUSE | DESCRIPTION |
|---|---|---|---|
| J01 | 30 Amp Pink | Bat - Presafe #1 | |
| J02 | 30 Amp Pink | Bat - Trailer Tow Main | |
| J03 | 25 Amp Natural | Bat - Passenger Door Node | |
| J04 | 40 Amp Green | Bat - ABS Pump | |
| J05 | 30 Amp Pink | Bat - ABS Valve | |
| J06 | 30 Amp Pink | Bat - H/Lamp Wash/MTV/CM2200/Elec Vac Pump | |
| J07 | 25 Amp Natural | Bat - Driver Door Node | |
| J08 | 30 Amp Pink | Bat - DTCM/Axle Locks | |
| J09 | 30 Amp Pink | Bat - Plg/Electric Brake | |
| J10 | 40 Amp Green | Bat - L/Bar/Off-Road | |
| J11 | 30 Amp Pink | Bat - Sway/Thatchum/Rear Doors | |
| J12 | 40 Amp Green | Starter Solenoid | |
| J13 | 60 Amp Yellow | Bat - Rad Fan #1/#2/SSR | |
| J14 | 40 Amp Green | Bat - Folding Seat/PZEV | |
| J15 | 60 Amp Yellow | Bat - IOD Main | |
| J16 | 40 Amp Green | Frt HVAC Motor | |
| M17 | 25 Amp Natural | Bat - Sunroof/Skylight | |
| M18 | 25 Amp Natural | TCM/Trans Range | |
| M19 | 5 Amp Tan | Ign R/ACC - Sunroof/Window Sw Illum | |
| M20 | 25 Amp Natural | Frt Wiper | |
| M21 | 25 Amp Natural | Door Locks | |
| M22 | 20 Amp Yellow | Fuel Pump | |
| M23 | 20 Amp Yellow | Bat - Trlr Light/Pre-Safe #2 | |
| M24 | 20 Amp Yellow | Bat - Trlr Tow BUX/HGM | |
| M25 | 10 Amp Red | Bat - J1962 Diag/Mirrors | |
| M26 | 10 Amp Red | Bat - Ign Sw, WIN, PASS | |
| M27 | 15 Amp Blue | Bat - CHMSL/Brake Sw | |
| M28 | 10 Amp Red | Bat - Corax TPM/PEM/HVAC Htr Pump | |
| M29 | 15 Amp Blue | Bat - Folding Mirror | |
| M30 | 25 Amp Natural | Bat - Inverter | |
| M31 | 20 Amp Yellow | Bat - Pwr Out #1 | |
| M32 | 20 Amp Yellow | Fr/Rr Washer | |
| M33 | 15 Amp Blue | Bat - NGC/EATX/PCM | |
| M34 | 15 Amp Blue | Bat - CCN/Interior Light/SCM/Sw Bank | |
| M35 | 20 Amp Yellow | Ign R-Frt Seat/Vent | |
| M36 | 20 Amp Yellow | Ign R-Rear Seat/Steer Wheel | |
| M37 | 10 Amp Red | Horn #1 | |
| M38 | 20 Amp Yellow | IOD-CCN/Interior Mods | |
| M39 | 30 Amp Green | IOD-Amp/Radio | |
| M40 | 25 Amp Natural | Rear Wiper | |
| M41 | 15 Amp Blue | IOD-SDARS/VES 2 - 3/DVD/HFM/ UGDO/Vanity Lamp | |
| M42 | 10 Amp Red | IOD-HVAC, U/Hood Lamp | |
| M43 | 10 Amp Red | Horn #2 | |
| M44 | 10 Amp Red | IGN R/S-ORC/OCM | |
| M45 | 10 Amp Red | IGN R-ORC/Trail Tow (BUX) Sense | |
| M46 | 20 Amp Yellow | IGN R-Trail Tow (BUX) | |
| M47 | 10 Amp Red | IGN R-H/Lamp Wash/HVAC/Park Assist/Ir Sns | |
| M48 | 20 Amp Yellow | IGN R/ACC-Pwr Outlet #2 | |
| M49 | 20 Amp Yellow | IGN R/ACC/Bat-Pwr Outlet #3 | |
| M50 | 25 Amp Natural | ASD #1, #2 | |
| M51 | 20 Amp Yellow | ASD #3 | |
| M52 | 10 Amp Red | IGN R/S-SWAY/TCASE/DTCM/FAD | |
| M53 | 15 Amp Blue | IGN R/S-MFSW/CNN/SCM/TPM/RR View | |
| M54 | 20 Amp Yellow | IOD - Spare | |
| CB1 | 25A Circuit Breaker - Bat - Memory Seat | ||
| CB2 | 25A Circuit Breaker - IGN R/ACC-Power Window | ||
| W01 | Relay - ASD #1, 2, 3 | ||
| W02 | Relay - Starter Solenoid | ||
| W03 | Relay - Frt Wiper On/Off | ||
| W04 | Relay - Radiator Fan #1 | ||
| W05 | Relay - Radiator Fan #2 |
| CAUTION | When installing the Integrated Power Module cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the Integrated Power Module, and possibly result in a electrical system failure. When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
Scheme 2
The Upfitter Power Distribution Center (PDC) is located in the engine compartment near the TIPM. This center contains fuses and relays. A description of each fuse and component may be stamped on the inside cover, otherwise the cavity number of each fuse is stamped on the inside cover that corresponds to the following chart.
| CAVITY | CARTRIDGE FUSE | RELAY | DESCRIPTION |
|---|---|---|---|
| 2 | Mini ISO | Line Heaters | |
| 7 | Mini ISO | Fuel Heater | |
| 15 | Mini ISO | NOX Sensors | |
| 8 | 20 Amp Blue | Fuel Heater | |
| 10 | 20 Amp Blue | Line Heaters | |
| 11 | 25 Amp Natural | DCU B+ | |
| 14 | 40 Amp Green | NOX Sensors |
| CAUTION | When installing the PDC cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the PDC, and possibly result in a electrical system failure. When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
