Starting - Non-Dtc Based Diagnostics: Other RAM Cab & Chassis 3500 HD

Starter 1 illustration ~348 words

REMOTE START INHIBITORS

  1. Using the scan tool, select ECU VIEW.
  2. Select the TIPM or FCM section.
  3. Select MORE OPTIONS
  4. Select SYSTEM TESTS
  5. Select REMOTE START INHIBIT DATA.

The following table below is a list of possible causes for the inoperative Remote Start System. If any of the following conditions exist, the Remote Start System will not work. Use this information as a guide to the diagnosis of the Remote Start System.

  1. ABORT
  2. BATTERY VOLTAGE HIGH
  3. BATTERY VOLTAGE LOW
  4. BRAKE PRESSED
  5. COOLANT TEMPERATURE HIGH
  6. CRANK NO START
  7. DRIVER DOOR AJAR
  8. PASSENGER DOOR AJAR
  9. LEFT REAR DOOR AJAR
  10. RIGHT REAR DOOR AJAR
  11. TRUNK/LIFTGATE AJAR
  12. HOOD AJAR
  13. NO HOOD SWITCH (INOPERATIVE)
  14. EXCESSIVE GLOW PLUG TIME (DIESEL ONLY)
  15. FAILED COUNTER REACHED (START)
  16. HAZARD LAMPS (SWITCH PRESSED)
  17. IGNITION IN RUN/START
  18. IGNITION NOT IN LOCK
  19. IGNITION SNA (SIGNAL NOT AVAILABLE FROM OTHER MODULE)
  20. INVALID KEY
  21. KEY IN IGNITION
  22. LOW RPM SHUTDOWN
  23. MIL ON
  24. NO AUTOMATIC TRANSMISSION
  25. NORMAL TIME OUT CUSTOMER ACCESS
  26. NORMAL TIME OUT RUN MODE (15 MINUTES)
  27. NOT CONFIGURED
  28. NOT ENABLED
  29. NOT IN PARK OR NEUTRAL
  30. NOT PROGRAMMED
  31. OIL PRESSURE LOW
  32. PANIC MODE (ACTIVATED)
  33. POWER LOSS
  34. RKE OFF MESSAGE
  35. RPM TOO HIGH (EXCEEDS 2500)
  36. START COUNTER REACHED
  37. VEHICLE SPEED HIGH
  38. VTA ALARMING

If all of the previous items checked OK, and the remote starting system will not operate, refer to the REMOTE START POOR PERFORMANCE diagnostic procedure. . Refer to DIAGNOSIS AND TESTING .

Scheme 21

Scheme 21: REMOTE KEYLESS ENTRY TRANSMITTER
Scheme 21: REMOTE KEYLESS ENTRY TRANSMITTER

Using special tool (special tool #9001, Rf Detector), first test to ensure that the transmitter is functioning. Typical testing distance is 2.5 centimeters (1 inch) for Asian transmitters and 30.5 centimeters (12 inches) for all others. To test, position the transmitter as shown in the illustration above. Press any transmitter button, then test each button individually. The tool will beep if a radio signal strength that lights five or more LED's is detected. Repeat this test three times. If transmitter fails any of the test. Refer to POWER LOCKS - DIAGNOSIS AND TESTING .

REMOTE START POOR PERFORMANCE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
