SPECIAL TOOLS
C-4755 - Trim Stick (Originally Shipped In Kit Number(s) 9299, 9299CC, 9299CC, 9300A-CAN.)
Scheme 1
| CALL OUT | DESCRIPTION | QUANTITY |
|---|---|---|
| 1 | Hood Switch Harness | 1 |
| 2 | Wireless Ignition Module (WIN) | 1 |
| 3 | FOBIK | 2 |
| 4 | WIN Antenna | 1 |
| 5 | Hood Latch Assembly | 1 |
| 6 | Zip Ties | 10 |
| CAUTION | XBM remote start can ONLY be installed on vehicles that have the following factory options: Automatic Transmission, Remote Keyless Entry and Immobilizer. WinFobik based vehicles, the sales code must be added to the database and the Restore Vehicle Configuration (using a diagnostic scan tool) must be performed prior to installing the new WIN module. Failure to do so will render the WIN module's remote start function inoperative. The technician should wait 1/2 hour between adding XBM sales code in DealerConnect before installing the WIN module & restoring vehicle configuration. In the interim, the technician can install all other components except the WIN module. |
Note. Prior to installation, obtain the four digit PIN from the dealership's parts department.
