Possible separation points Porsche Cayman 987

Rear 1 illustration

Possible separation points

WARNING

Possible separation points on inner front side member Danger of material damage and injury

> The possible separation points on the inner front side member are 30 mm in front of the tailored blanks (laser weld) against the direction of travel.

Scheme 1082

Scheme 1082

Scheme 1082

1. Possible separation points

1.1. In the rear side member

1.2. The joint on the inner side member must be located in front of the tailored blank weld (laser weld) X , area a or b at dimension Y = 30 mm .
