Installing sun visor
Installation Location
1. Insert sun visor -3- into the mounting saddle. (Scheme 79)
2. Position sun visor -3- and screw down using the fastening screw -2-. (Scheme 79)
Scheme 78
3. Press in cover -1- until it engages. (Scheme 79)
Installation Location
Scheme 79
Scheme 80
1. Detach the sun visor -1- from the support -2- and pull it out of the mounting saddle -3- towards the center of the vehicle. see scheme 107
Installation Location
Scheme 81
1. Insert sun visor -1- into the mounting saddle -3- and then push it into the support -2-. (Scheme 82)
Remove sun visor. > 682319 Removing and installing sun visor - chapter on "removing" [987310 987311 987320 987321] > 682319 Removing and installing sun visor - chapter on "removing" [987120 987121]
Scheme 82
1. Insert a narrow screwdriver between the mirror insert -3- and mirror housing -2- at the bottom center, and unclip the mirror insert. (Scheme 83)
Scheme 83
2. Pull the mirror insert -3- upwards and remove from the mirror housing -2-. (Scheme 84)
Scheme 84
1. Remove bulb -5- from contact clips -4-. Take the contact clips upwards out of the holder. (Scheme 85)
Scheme 85
1. Insert a narrow plastic spatula between the mirror housing -2- and the sun visor -1- on the left and right and unclip the mirror housing. (Scheme 86)
Scheme 86
2. Take the electric lead out of the mirror housing -2- and detach the mirror housing from the sun visor. (Scheme 87)
Scheme 87
1. Insert electric lead into the mirror housing -2-. Position the mirror housing in the sun visor. (Scheme 88)
Scheme 88
2. Press the mirror housing -2- at all four corners until it locks into place. (Scheme 89)
Scheme 89
1. Position the contact clips -4- in the mirror housing and fit under the lug. Insert bulb -5-. (Scheme 90)
Scheme 90
1. Position the lugs on the right and left of the mirror insert -3- in the mirror housing. (Scheme 91)
Scheme 91
2. Clip the mirror insert -3- into the mirror housing -2- on the left, right and in the middle. (Scheme 92)
Install sun visor. > 682319 Removing and installing rear window - chapter on "installing" [987310 987311 987320 987321] > 682319 Removing and installing rear window - chapter on "installing" [987120 987121]
Scheme 92
1. Open the glove compartment.
2. Unscrew fastening screws -2- from cupholder -1-. (Scheme 93)
3. Take off the cup holder -1-. (Scheme 93)
Scheme 93
1. Push cup holder -1- into the shaft of the glove compartment. (Scheme 94)
2. Tighten fastening screws -2-. Tightening torque --> Final tightening: 7.2 ftlb. (Scheme 94)
Remove glove compartment. > 681519 Removing and installing glove compartment - chapter on "removing"
