Preliminary work for line condenser-fluid tank
Removing left front wheel. Refer to 44 05 19 Removing and installing wheel - as of MY 2005 (All Models) .
Remove front left wheel housing liner. Refer to 50 56 19 Removing and installing front wheel housing liner - as of MY 2005 (All Models) .
Draining refrigerant. > 870317 Draining and filling in refrigerant - chapter on "draining"
Removing the condenser-fluid tank line
Installation Location
Scheme 104
Note. When loosening or tightening the M8 refrigerant lines on the condenser, always counter with a 21-mm open-ended wrench.
Scheme 105
1. Unscrew the fastening screw -1- for the line condenser and pull the line out of the condenser. (Scheme 106)
2. Pull the line out of the line holder.
Scheme 106
3. Counter the fastening nuts -2- and open carefully. (Scheme 107)
Note. Before re-installing the component, check the O-rings of the refrigerant lines for damage and replaced them if necessary. Wet the O-rings of the refrigerant lines with refrigerant oil. Do not open the plugs for the lines and connections until shortly before installation. Close off all lines and connections using suitable plugs during removal.
Scheme 107
4. Pull the line and the rubber sleeve out of the passage to the plenum panel over the wheel housing.
Scheme 108
1. Push line into the plenum panel via the wheel housing and press rubber sleeve into place. Ensure that rubber sleeve is fitted correctly.
Note. When loosening or tightening the M8 refrigerant lines on the condenser, always counter with a 21-mm open-ended wrench.
Scheme 109
2. Clip line into the line holder at the top, insert line into the condenser and screw down with -2- fastening screw. --> Tightening torque: 14 (10.5 ftlb.) Nm. (Scheme 110)
Note. Before re-installing the component, check the O-rings of the refrigerant lines for damage and replaced them if necessary. Wet the O-rings of the refrigerant lines with refrigerant oil. Do not open the plugs for the lines and connections until shortly before installation. Close off all lines and connections using suitable plugs during removal.
Scheme 110
3. Push together line in plenum panel and screw on with the -1- fastening screws. --> Tightening torque: 20 (15 ftlb.) Nm. (Scheme 111)
Subsequent work for line condenser-fluid tank
Filling in refrigerant. > 870317 Draining and filling in refrigerant
Install front left wheel housing liner. Refer to 50 56 19 Removing and installing front wheel housing liner - as of MY 2005 (All Models) .
Installing front wheel. Refer to 44 05 19 Removing and installing wheel - as of MY 2005 (All Models) .
Preliminary work line condenser-fluid tank
Draining refrigerant. > 870317 Draining and filling in refrigerant - chapter on "draining"
Removing cowl panel cover. Refer to 50 87 19 Removing and installing cowl panel cover - as of MY 2005 (All Models) .
Removing the battery. Refer to 27 06 19 Removing and installing battery - as of MY 2005 (All Models) .
Note. Before re-installing the component, check the O-rings of the refrigerant lines for damage and replaced them if necessary. Wet the O-rings of the refrigerant lines with refrigerant oil. Do not open the plugs for the lines and connections until shortly before installation. Close off all lines and connections using suitable plugs during removal.
Installation Location
Scheme 111
Scheme 112
1. Unscrew fastening nut -1-. (Scheme 113)
2. Remove the holder for the two refrigerant lines and pull the refrigerant line condenser-fluid tank out of the expansion valve.
Scheme 113
3. Unscrew the fastening nut -2- for the refrigerant line condenser-fluid tank in front of the fluid tank, detach the line from the holder and pull out from under the water hoses for the heat exchanger. (Scheme 114)
Installing the condenser-fluid tank line
Note. Before re-installing the component, check the O-rings of the refrigerant lines for damage and replaced them if necessary. Wet the O-rings of the refrigerant lines with refrigerant oil. Do not open the plugs for the lines and connections until shortly before installation. Close off all lines and connections using suitable plugs during removal.
Scheme 114
1. Lay the refrigerant line under the heat exchanger hoses and screw down on line to fluid tank -2- with fastening nut. --> Tightening torque: 20 (15 ftlb.) Nm. (Scheme 115)
2. Clip line into the holder.
Scheme 115
3. Position holder for refrigerant lines and secure with the fastening nut -1-. --> Tightening torque: 6 (4.5 ftlb.) Nm. see scheme 155
Subsequent work line condenser-fluid tank
Installing battery. Refer to 27 06 19 Removing and installing battery - as of MY 2005 (All Models) .
Filling in refrigerant. > 870317 Draining and filling in refrigerant
Installing cowl panel cover. Refer to 50 87 19 Removing and installing cowl panel cover - as of MY 2005 (All Models) .
Removing desiccator (fluid tank)
Installation Location
Installation position. Scheme 116
The desiccator (fluid tank) is located under the left plenum chamber cover.
1. Unscrew the fastening nuts -1- on the fluid tank. (Scheme 117)
2. Undo fastening screws -2-. (Scheme 117)
3. Unscrew the fastening clamp -3- and remove the fluid tank upwards. (Scheme 117)
4. In any case, replace the desiccator.
Installing desiccator (fluid tank)
In any case, replace O-rings for the refrigerant lines and wet the new rings with refrigerant oil.
Only install a new desiccator.
Scheme 117
1. Position the fluid tank, connect the refrigerant lines and secure with the fastening screws -2-. --> M6: 4.5 ftlb.. see scheme 165
2. Connect the air-conditioning line -1- and tighten with fastening nut. see scheme 165
3. Tighten the hose clamp -3-. see scheme 165
4. Determine the quantity of refrigerant oil. --> Technical data for air-conditioning system , volume removed by suction + 30 cm 3 .
