Removing light frame (section) Porsche Cayman S 987

Removing light frame (section)

Installation Location

Scheme 1271

Scheme 1272

1. Cutting through light frame

1.1. Cut through the light frame of connection point -A- using the body saw. (Scheme 1247)

1.2. Cut through the light frame of connection point -B- using the body saw. (Scheme 1247)

Scheme 1273

2. Separating and milling off spotwelds

2.1. Separate spotwelds in areas -A- and -C- using a parting grinder. (Scheme 1248)

2.2. Mill off spotwelds in area -B- using a spotweld cutter. (Scheme 1248)

Scheme 1274

3. Milling off spotwelds

3.1. Mill off spotwelds in areas -A- and -C- using a spotweld cutter. (Scheme 1249)

3.2. Mill off spotwelds in areas -B- and -D- using a spotweld cutter (2 plate thicknesses). (Scheme 1249)

Scheme 1275

4. Milling off spotwelds

4.1. Mill off spotwelds in areas -A- and -B- using a spotweld cutter (2 plate thicknesses). (Scheme 1250)

Scheme 1276

5. Milling off spotwelds

5.1. Mill off spotwelds in areas -A- and -C- using a spotweld cutter. (Scheme 1251)

5.2. Mill off spotwelds in area -B- using a spotweld cutter (2 plate thicknesses). (Scheme 1251)

> Cover vehicle parts such as battery, fuel system, paintwork, glass and passenger compartment parts with fire-proof covers and, if necessary, remove batteries and fuel-carrying components.

> No other vehicles may be left unprotected in areas used for body repair!

Scheme 1277

1. Clean undersealing, adhesive residue and paint off the body connecting flanges in the marked areas -A, B, C, D- using a hot-air gun or rotary brush. Grind the connecting flanges until bare. (Scheme 1252)

2. Coating spot-weld flange areas with zinc powder paint

2.1. Coat spot-weld flange areas with zinc powder paint.

> Wear protective gloves when working in the area of sharp-edged body and unit parts!
