Function test following assembly work
Installation Location
Note. A malfunction occurs only after the vehicle is locked for the first time. In other words: if a door handle was fitted incorrectly, the affected door can be opened and closed without difficulty until the vehicle is locked for the first time. After that, the door cannot be opened either from inside or outside. Given this, it is important to perform a function test before the door is closed.
1. Do not close vehicle door after installing door handle.
Scheme 107
2. With the door open -2-, use a screwdriver to engage the bolt in the door lock -1- fully in the second notch. (Scheme 107)
3. Lock vehicle with the remote control.
4. Unlock vehicle with the remote control.
5. Press door handle on open door.
Note. If the bolt in the door lock does not open, press the door button to make sure that the individual door opening function is deactivated. If the door lock still does not open, the door lock was assembled incorrectly.
1. Remove door handle. > 571119 Removing and installing door handle - chapter on "Removing"
2. Remove microswitch for window opening controls. Refer to 64 37 19 Removing and installing microswitch for window opening controls - as of MY 2005 (All Models) .
Scheme 108
1. Press out circlip -1-, pull pin -2- out of the handle and remove actuating shaft -3-. (Scheme 108)
2. Pull pin rod -4- out of the handle liner -9- and separate handle -8- from the handle liner. (Scheme 108)
3. Remove return spring -6-, eccentric -5- and sleeve -7-. (Scheme 108)
4. Pull buffer -10- out of the handle -8-, check it and replace if necessary. (Scheme 108)
