Porsche Cayman GTS 982 (2016-2024) w/o start/stop function w/ start/stop function wiring diagram
This page shows the only wiring diagram for the component.w/o start/stop function w/ start/stop function, which is found in the car Porsche Cayman GTS 982 (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
w/o start/stop function w/ start/stop function wiring diagram (1 of 1)
A/C CONTROL UNIT
BACKUP CAMERA
BASE
BLK/RED WIRE
BOSE AMPLIFIER
BRN WIRE
BURMESTER AMPLIFIER
BURMESTER SUBWOOFER AMPLIFIER
COUPLING ANTENNA
DISC CARD READER
DISPLAY CONTROL PANEL
DME RELAY 1
DRIVER'S DOOR OUTER HANDLE SENSOR
EMERGENCY POWER PIN
EMERGENCY VOLTAGE SUPPLY RELAY 1
FROM DC/DC CONVERTER (DIAGRAM 2 OF 5)
FROM FUSE (DIAGRAM 3 OF 5)
FROM MAIN FUSE BOX (DIAGRAM 2 OF 5)
FRONT BCM
FRONT PASSENGER DOOR OUTER HANDLE SENSOR
FUEL PUMP RELAY #1
FUSE 1
FUSE 10
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GP-20
GRN WIRE
HIGH MIB CENTRAL PROCESSOR
INSTRUMENT CLUSTER
LEFT FRONT FUSE BOX (ROW B)
MAIN FUSE BOX (RIGHT END OF DASH)
MIDI FUSE
MULTI- MODE COMPENSER
N/A
PREMIUM
RAIN SENSOR
RDK CONTROL UNIT
REAR BCM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT FUSE BOX (ROW B)
STEERING COLUMN SWITCHING MODULE
STOPWATCH
TO LEFT FRONT FUSE BOX (ROW A) (DIAGRAM 2 OF 5)
TO REAR FUSE BOX RELAY SUPPORT 2 (ROW B) (DIAGRAM 5 OF 5)
USB- HUB
W/ BURMESTER
W/ DISPLAY
W/O DISPLAY
W/O START/STOP FUNCTION W/ START/STOP FUNCTION
WHT WIRE
WLAN CU
Go to component -> Power distribution circuit (4 of 5) -> W/O START/STOP FUNCTION W/ START/STOP FUNCTION
