Installing front seat frame
| CAUTION | Risk of material damage to screw connections for seat and seat frame! |
> The fastening screws for seat and seat frame are coated and must be replaced after being unscrewed.
> Before screwing in the new fastening screws, clean the thread holes with an M10 x 1.5 tap!
| WARNING | Incorrect information for AWS control module. Passenger's airbag is triggered differently. |
> If the passenger's seat was removed and re-installed, the AWS control module must be calibrated.
> If the seat bracket was replaced, the AWS control module must be calibrated.
> If the AWS control module was replaced, the AWS control module must be calibrated.
Note. Calibration applies only for vehicles of MY '06 with country equipment (USA, Canada, Mexico).
1. Place front seat frame into position.
Scheme 59
2. Fold sections of carpet forward and screw in front fastening screws -1-. (Scheme 59)
3. Screw in rear fastening screws -2-. (Scheme 59)
4. Tighten fastening screws -1 and 2- to the specified tightening torque. --> Tightening torque: 45 (33 ftlb.) Nm. (Scheme 59)
Scheme 60
5. Position compressor connection -1- and tighten fastening screw -2- to the specified tightening torque. --> Tightening torque: 20 (15 ftlb.) Nm. (Scheme 60)
Scheme 61
6. Insert side trim -Arrow B-. (Scheme 61)
7. Clip front trim into place -Arrow A- until it can be felt to engage. (Scheme 61)
