Installing ignition switch
1. Connect the connector to the ignition starter switch until it engages firmly.
2. Position ignition starter switch in the dashboard. Position union nut, re-adjust switch and tighten union nut using wrench T10152 . --> Tightening torque: 1 ftlb.
3. Check clips on the molding for the dashboard for damage and replace if necessary.
4. Position molding and press onto the dashboard until the clips engage.
1. Install cover under instrument panel on left. Refer to 70 22 19 Removing and installing cover under dashboard - as of MY 2003 (All Models) .
Designation Type Number Explanation Spark plug wrench VW-tool 3122 B Puller VW-tool T10095 A
Scheme 10
1. Pull engine cover vertically upwards and off.
Scheme 11
| Item | Designation | Source | Explanation |
|---|---|---|---|
| A-. (Scheme 11) | Puller T10095 A | > "See Workshop Equipment Manual, Chapter 2.2.3" | For removing securely seated ignition coils |
| B-. (Scheme 11) | Spark plug wrench 3122 B | > "See Workshop Equipment Manual, Chapter 2.2.3" | For installing and removing spark plugs |
