Technical values
Note. For information on all tightening torques, see > Tightening torques for Cayenne S (M48/00) and Cayenne Turbo (M48/50) [9PAAF1 9PAAJ1 9PAAK1] or > Tightening torques for Cayenne S (M48/00) and Cayenne Turbo (M48/50) [9PAAE1 9PAAE7] or the corresponding individual articles.
1. Fit left additional assembly bracket -2- and right engine carrier -8-. There are still two dowel sleeves (not shown) on the additional assembly bracket. see scheme 520
1 - Nut --> Tightening torque: 75 (56 ftlb.) Nm
2 - Additional assembly bracket, left
3 - Screw x 10 --> Tightening torque: 65 (48 ftlb.) Nm
4 - Hydraulic mount, left
5 - Engine carrier
6 - Screw x 4 --> Tightening torque: 60 (44 ftlb.) Nm
7 - Hydraulic mount, right
8 - Engine carrier
9 - Screw x 6 --> Tightening torque: 65 (48 ftlb.) Nm
2. Fit power-steering pump. Refer to 48 98 19 Removing and installing hydraulic pump (Cayenne Turbo/Cayenne S) - as of MY 2003 (Cayenne S TIP, Cayenne S MAN, Cayenne Turbo, Cayenne Turbo S) .
3. Fit generator. Refer to 27 22 19 Removing and installing three-phase generator - as of MY 2003 (Cayenne S TIP, Cayenne S MAN, Cayenne S TIO Titan) . Refer to 27 22 19 Removing and installing the generator - as of MY 2006 (Cayenne S TIP, Cayenne S MAN) . Refer to 27 22 19 Removing and installing the generator - as of MY 2006 (Cayenne Turbo, Cayenne Turbo S) .
4. Fit wire harness for engine. Refer to 97 52 19 Removing and installing wiring harness for engine - as of MY 2003 (Cayenne S TIP, Cayenne S MAN) . Refer to 97 52 19 Removing and installing wiring harness for engine - Cayenne Turbo (Type M48/50) - as of MY 2003 (Cayenne Turbo, Cayenne Turbo S) .
5. Refit engine on transmission. Refer to 34 35 27 Removing and refitting transmission - as of MY 2003 (Cayenne S MAN) or refer to 37 35 27 Removing and refitting transmission - as of MY 2003 (Cayenne S TIP, Cayenne Turbo, Cayenne Turbo S, Cayenne S TIO Titan) .
6. Install engine. > 100119 Removing and installing V8 4.5 l engine - "Installing" .
Designation Type Number Explanation Suspending device VW-tool 3033 Transport eyebolt special tool P 9700
Scheme 192
| Item | Designation | Source | Explanation |
|---|---|---|---|
| A- see scheme 521 | Suspending device 3033 | See Workshop Equipment Manual, Chapter 2.2.3 | Only this tool is tested and approved by Porsche. It guarantees only vertical traction of the transport eyebolt with no side or transverse forces. |
| B- see scheme 521 | Transport eyebolt P 9700 | See Workshop Equipment Manual, Chapter 2.2.2 | The transport eyebolt can only bear vertical traction with no side or transverse forces. Side loads (e. g. from chains or cables) will damage the transport eyebolt, which must then be replaced. The transport eyebolt can be broken in extreme cases. |
Scheme 193
1. Remove design cover from cylinder bank 5-8. To do this, loosen the four fastening screws -arrows- on the design cover. see scheme 522
Scheme 194
2. Lift the cover slightly with both hands at the side pointing towards the intake system until it is released from its holder.
3. Lift the front of the design cover and remove it.
