Tools
Designation Type Number Explanation assembly tool for spring-band clamps commercially available tool NR.72 Pliers for lug hose clamp commercially available tool NR.74 Torque wrench, signal-transmitting with changeover ratchet commercially available tool NR.90 Accessory for torque wrench: Open-jawed wrench insert, a/f 24 commercially available tool NR.95-1 Open-jawed wrench insert a/f 38 commercially available tool NR.95-2 Screwdriver special tool P 9546 Press-out tool VW-tool T10187
Scheme 194
Scheme 195
Scheme 196
Scheme 197
| Item | Designation | Source | Explanation |
|---|---|---|---|
| A-. (Scheme 194) | Press-out tool T10187 | See Workshop Equipment Manual, Chapter 2.2.3 | To press out the ball joint on the wheel carrier. |
| B-. (Scheme 194) | Screwdriver P 9546 | See Workshop Equipment Manual, Chapter 2.2.2 | To counter the ball joints (track rod) during assembly and disassembly. |
| C-. (Scheme 194) | Accessory for torque wrench: Open-jawed wrench insert, a/f 24 NR.95-1 | See Workshop Equipment Manual, Chapter 2.4 | To fit tie rod (lock nut). |
| D-. (Scheme 194) | Open-jawed wrench insert a/f 38 NR.95-2 | See Workshop Equipment Manual, Chapter 2.4 | To fasten tie rod to steering gear (steering rack). |
| E-. (Scheme 194) | Pliers for lug hose clamp NR.74 | See Workshop Equipment Manual, Chapter 2.4 | To fasten joint boot to steering housing. |
| F-. (Scheme 194) | Torque wrench, signal-transmitting with changeover ratchet NR.90 | See Workshop Equipment Manual, Chapter 2.4 | To adjust the tightening torque. |
