Installing frame for sunroof
Installation Location
Scheme 71
1. Put on frame for sunroof.
Scheme 72
1.1. Insert the sliding roof frame -1- with an assistant through the rear lid opening into the passenger compartment. (Scheme 70)
Note. The punches have a diameter of 10 mm or 12 mm.
1.2. Position frame for sliding door -1- on the roof frame and attach to the locating bores with punches -6 and 7-. (Scheme 71)
Scheme 73
1.3. Screw in fastening screws -4a, 4b- and -4c to 4e- and tighten so that the frame for the sliding roof can still be moved slightly. (Scheme 72), see scheme 82.
Scheme 74
Installation Location
Scheme 75
2. Tighten the fastening screws -4- in the sequence shown -4a, 4b- and -4c to 4e-. --> Tightening torque: 8 (6 ftlb.) Nm +/-0.5 (0.5 ftlb.) Nm. (Scheme 73), (Scheme 74), (Scheme 75).
Scheme 76
3. Push electric plug connection -5- onto sunroof drive until locking tabs audibly engage. see scheme 86
Scheme 77
4. Remove fixing devices.
4.1. Remove punch -6- and -7-. see scheme 87, (Scheme 76).
Scheme 78
Scheme 79
5. Connect water drain hoses -2- at the front. (Scheme 77)
Scheme 80
6. Connect water drain hoses -3- at the rear. (Scheme 78)
Designation Type Number Explanation hook VW-tool 3370
