Installing actuating cable for lock
Installation Location
1. Install actuating cable on lock.
Scheme 374
1.1. Insert traction cable -6- through holder of actuating cable -13- on lock ( -arrow A- ). (Scheme 374)
1.2. Insert actuating cable -3- on holder -13- of lock ( -arrow A- ). The fastening clips -4- of the traction mounting must engage audibly into the lock holder. see scheme 42
Scheme 375
1.3. Attach cable -6- to the assembly opening of actuating lever -7- from above -arrow B- and swivel to the actuating cable holder -13- on the lock ( -arrow C- ). (Scheme 375)
Scheme 376
2. Install actuating cable on lock bolt.
2.1. Insert traction cable -6- through holder of actuating cable -14- on lock bolt ( -Arrow D- ). (Scheme 376)
2.2. Insert actuating cable -3- on holder -14- of lock bolt ( -Arrow D- ). The fixing clips -10- of the traction mounting must engage audibly into the lock bolt holder. (Scheme 376)
2.3. Turn actuating lever -12- to the stop in direction of actuating cable holder -14- ( -Arrow E- ). (Scheme 376)
2.4. Attach cable -6- to the assembly opening of actuating lever -12- from above and swivel to the actuating cable holder -14- on the lock bolt ( -Arrow F- ). (Scheme 376)
Scheme 377
3. Position cap -9- on the lock bolt -11- from above and press in. The fixing clips -9- of the cover must engage audibly. (Scheme 377)
4. Install glove compartment lock. > 681119 Removing and installing glove compartment lock - "installing"
5. Install glove compartment. > 681519 Removing and installing glove compartment - "Installing"
