Preliminary work for disassembling engine
1. Remove engine. > 100119 Removing and installing V8 4.5 l engine - "Removing"
2. Remove engine from transmission. Refer to 34 35 27 Removing and refitting transmission - as of MY 2003 (Cayenne S MAN) or refer to 37 35 27 Removing and refitting transmission - as of MY 2003 (Cayenne S TIP, Cayenne Turbo, Cayenne Turbo S, Cayenne S TIO Titan) .
Note. The engine must be disassembled in accordance with the detailed descriptions in the article! This article does not provide details or further information. Further details can be found in the relevant individual descriptions.
3. Secure engine support P 9676 on engine --> Crankcase on engine support (shown with lower part of crankcase). To do this, use the four screws for mounting elements P 9590 and tighten them slightly. Secure engine on engine support. To do this, carefully guide the engine support axle into the take-up bore on the engine support and secure it. see scheme 472
4. Remove wire harness for engine. Refer to 97 52 19 Removing and installing wiring harness for engine - as of MY 2003 (Cayenne S TIP, Cayenne S MAN) . Refer to 97 52 19 Removing and installing wiring harness for engine - Cayenne Turbo (Type M48/50) - as of MY 2003 (Cayenne Turbo, Cayenne Turbo S) .
5. Remove the generator. Refer to 27 22 19 Removing and installing three-phase generator - as of MY 2003 (Cayenne S TIP, Cayenne S MAN, Cayenne S TIO Titan) . Refer to 27 22 19 Removing and installing the generator - as of MY 2006 (Cayenne S TIP, Cayenne S MAN) . Refer to 27 22 19 Removing and installing the generator - as of MY 2006 (Cayenne Turbo, Cayenne Turbo S) .
6. Remove power-steering pump. Refer to 48 98 19 Removing and installing hydraulic pump (Cayenne Turbo/Cayenne S) - as of MY 2003 (Cayenne S TIP, Cayenne S MAN, Cayenne Turbo, Cayenne Turbo S) .
7. Remove left additional assembly bracket -2- and right engine carrier -8-. There are also two dowel sleeves (not shown) on the additional assembly bracket. (Scheme 52)
Scheme 54
1 - Nut --> Tightening torque: 75 (56 ftlb.) Nm
2 - Additional assembly bracket, left
3 - Screw x 10 --> Tightening torque: 65 (48 ftlb.) Nm
4 - Hydraulic mount, left
5 - Engine carrier
6 - Screw x 4 --> Tightening torque: 60 (44 ftlb.) Nm
7 - Hydraulic mount, right
8 - Engine carrier
9 - Screw x 6 --> Tightening torque: 65 (48 ftlb.) Nm
